Tigercat® TRANSPORTING INSTRUCTIONS
The machine may be transported with the wheels on or off. With wheels on:•
DO NOT remove air from tires, this will result in damage to the tires!
With wheels off:•
•
The articulation lock bar must be installed.
•
Additional chains may be installed on the two tow lugs (front of unit) and on the bottom cab access steps.
Do not secure the machine to the truck ANYWHERE near the center joint area as this can seriously damage the center joint.
With the wheels on or off:The dozer blade must be down on the truck bed.
The machine must be cross chained (side to side) at both the front and rear axle area.
IMPORTANT ! When transporting the machine, chains must be used to prevent forward, reverse and side to side movement of the machine.
If the wheels are removed the machine must be blocked so that the center joint is one inch or more above the truck bed.
•
•
Use only transport regulation chains for this purpose, example; 5/16” grade 7 with a tensile strength of 43500kg(96,000lb)/chain. Using inferior or damaged chains could cause the load to shift.
RETAINING BOLT
ARTICULATION LOCK F610C-02
16
