PRIMARY FUEL FILTER COMPONENTS
The high risk of refuelling with fuel that is polluted by foreign bodies and water makes it advisable to carry out this control every time you refuel.
FILTER HEAD
ENGLISH
CHECK FOR WATER IN FUEL FILTER/WATER SEPARATOR
Only proceed with the engine stopped. FOR PROCEDURE ON CHECKING AND CHANGING THE PRIMARY FUEL FILTER/WATER SEPARATOR, PLEASE REFER TO YOUR MACHINE’S OPERATOR’S MANUAL.
TEMPERATURE SENSOR
NOTE: The components of the common rail system can be damaged very quickly by the presence of water or other impurities within the fuel.
FILTER
WARNING
HEATER ELEMENT
Drain fuel filter into a container and dispose of all fluids properly. IMPORTANT !
Filters that are an integral part of the engine (fuel and lubricating oil) should be serviced and replaced according to the MAINTENANCE SCHEDULE in this manual.
33
