Troubleshoot Reading Flow Charts Diagnostic Trouble Code Number and Problem The diagnostic trouble code number and problem are listed above the flow chart.
How to proceed and go to the next
AL
• Continue with either the YES or NO branch for the inspection and measurement result in .
contains inspection and measurement methods and values.If there is agreement with the values and question in , then the result is YES. The result is NO if there is no agreement.
Electrical wiring colors
TE RN
•
See the table below for electrical wiring colors in measurement locations when doing troubleshooting.
B
W
Br
P
Color
Black
White
Brown
Pink
Symbol
R
Y
Lg
Sb
Color
Red
Yellow
Light green
Sky blue
V
G
O
Violet
Green
Orange
L
Gr
Blue
Gray
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
Symbol
IN
Electrical wiring color distinctions
"ab" indicates there is a color "b" stripe on the electrical wire color "a" base. Ex.) BR: Red stripe on black base color.
