Fig. 7.32. Connector wiring high-frequency loudspeaker: 1 - connector wiring, 2 - speaker Installation is performed in reverse order of removal. Loudspeaker on dashboard Using a plastic wedge poddente and separate the cover from the loudspeaker of the instrument panel (Figure 7.33). With the appropriate configuration disconnected the wiring connector and remove the sensor of sunlight on the back side of the cover.
Fig. 7.33. Withdrawal loudspeaker with pa-nonlinear devices: 1 - cover the loudspeaker, 2 - sensor sunlight; 3 - speaker 4 - fixing screw; 5 - Deflection blowing the windscreen NOTE Not miss cable in hole pa-nonlinear devices. Separate deflectors blowing the windscreen of the dashboard and remove the fixing screw located beneath them. Remove the mounting screw, remove the speaker and disconnected the wiring harness connector. Installation is performed in reverse order of removal.
331
