NOTICE Use only brake fluid DOT 4. The hydraulic clutch is pumped only "bottom", that is pumped through the valve. For this purpose the device is used to remove air from the hydraulic brakes. NOTICE Manual pumping not allowed. Follow production Ying-tion at use aspirations STVA for delete air of Tormo-call. Device for delete air to ha of Brakes should ensure pressure approximately 2 bar. Hardware Installation Connect the device to remove air from the hydraulic drive. To do so, attach the adapter device for removing air from the brakes to Backa hydraulic brake system. Install special tool IMC-6174-2 on the adapter. Lower the end of the hose into a suitable container. Remove the valve cap from the valve pumping and attach a special tool IMC-6174-1 to the valve pumping (Fig. 3.2). Remove air from the clutch. Turn on the device for removing air from the hydraulic drive. Open the valve pumping (2-3 overleaf). Pump to release the brake fluid without bubbles. Close (by hand) valve pumping. Removing device Unplug the device for removing air from the hydraulic drive. Disconnect the adapter device for removing air from the hydraulic drive. NOTICE Must follow following operations for fill gall-ment pipeline Carter co-shy Transmission Desktop cylinder clutch. When pumping certifying believe that tank hydraulic brake system filled. Remove air from the discharge line of the working cylinder clutch. Install special tool IMC-6174-2 on MCM-6174-1 on the valve pumping, lower the free end in a suitable container Press and hold the clutch pedal. Open the valve pumping. Open the valve before pumping air and / or a mixture of air / brake fluid. Close (by hand) valve pumping. Slowly release the clutch pedal and wait approximately 5 seconds. Repeat the procedure four times. Tighten the valve point pumping 5 N-m. Remove the special tools IMC-6174-1 and IMC-6174-2. Remove the cap from the valve pumping. Fill the tank hydraulic clutch brake fluid to the mark "MAX". Close the tank hydraulic brake system. Check the opening pressure of the clutch pedal. Check to include all gear with the engine running and clutch depressed. NOTE Make trial trip, something would ensure clear work si-tem Clutch and inhibition. Travel spend with different velocities and frequent switch-em transfers to reach work-chih temperatures.
2.3 Clutch - Removal, inspection and installation of hard plates and the driven clutch plate (without SAC) NOTE To prevent damage to the petals spring thrust plate use a special device KM-6263 after removal and installation. NOTE Note the different length brackets for joining the CM 6263 at lowering engine block. Withdrawal Remove the gearbox
111
