System Operation
Figure 2-3
The compressor inlet is low pressure and the outlet is high pressure. The reed valves are one way. They open to allow refrigerant gas to enter the compressor on the down stroke and exit on the upstroke. Note the open valves in the illustrations.
The clutch is mounted on the shaft of the compressor and is engaged by electromagnetic action. Part of the clutch assembly is an electromagnetic wire coil. The coil is energized through a thermostat that senses the temperature in the evaporator coil. If the evaporator is too warm the electrical contacts close and allows power to flow to the clutch. The compressor shaft is engaged and moves the refrigerant around inside the system. Figure 2-4 is a cutaway view of the clutch mounted on the compressor.
Figure 2-4
The clutch shown here has its electromagnetic coil mounted on the compressor body. When the coil is energized, magnetic force pulls the clutch drive plate into the pulley. This action locks the pulley to the compressor drive shaft and drives the compressor.
2. Condenser The refrigerant gas leaves the compressor and moves through a high pressure hose to the condenser. Inside the condenser the gas “changes state” and becomes a liquid. It is still hot and under pressure. Remember in Chapter 1 when we talked about water at 212 degrees Fahrenheit? Heat energy was involved in the “change of state,” but the temperature did not change. The same kind of action happens inside the AC system. The refrigerant gas gives up a lot of heat energy to the outside air as it “changes state” in the condenser. Figure 2-5 illustrates a condenser. Air moving through the condenser absorbs heat from the refrigerant. The amount of air flow through the condenser is the major factor in how well the condenser functions.
