1750RT - TRACKS TRACK DRIVE MOTOR AND SPROCKET
IMPORTANT: Early- and late series track drive motors are not interchangeable and must be installed with the identical track drive motor on the opposite side. If ordering only one drive motor, be sure to refer to the ID plate that is fastened to the face of the drive motor. The part number for the drive motor is stamped in the "CUST.COD" box; be sure to order the same track drive motor already on the machine. If ordering both drive motors, be sure to order the same part number for both sides.
The part number for the drive motor is located in the "CUST.COD" box on the ID Plate
1
2
3
7
6
4
FYI:
50960115/DP0219
5
1750RT (T4) S/N 811221 and up and 1750RT (iT4) S/N 10802-131000 were originally equipped with track drive motor P/N 50305572. Units previous to the serial numbers listed were originally equipped with track drive motor P/N 273269.
