SERVICE MANUAL
Attachments
ME2503 - 3703
BUCKET LIST 303/353/373 BUCKET
With
Volume
Part No.:
TILTING BUCKET hydraulic 303/353/373
39.4" (1000 mm)
3.9 cu. ft. (111 L)
3026401
55.1" (1400 mm)
5.6 cu. ft. (158 L)
3026402
TILTING BUCKET hydr. For quick hitch coupler 272/342
39.4" (1000 mm)
3.9 cu. ft. (111 L)
3006189
55.1" (1400 mm)
5.6 cu. ft. (158 L)
3006190
Usable for...
303 353 373
303/353/373 272/342
NOTICE: Gehl 253: Usability: + Buckets OLD (see A) >> for >> excavator - 03 Model: It is possible to use the buckets from excavator models (A)170/190/191/192/220/221/ 222 for the new Gehl 253. + Buckets 03-Gen. >> for >> excavator OLD (see A) : Can be assembled, but collision bucket/boom possible! Gehl 303/353/373: Usability: + Bucket OLD (see B) >> for>> excavator - 03 Model: Older buckets, which were used by the models (B>) 260/272/280/292/300/320/ 342/362/380/382 can also be used for the: 303/353/373 Therefore, the bucket connecting link must be changed from the original to a modified version. (See Part No. in the lists) + Bucket 03-Gen. >> for >> excavators OLD (see B): It is not possible to use this 03-Generation ("new") buckets on the old models of excavators listed (B)!
Id.No.: 918148 Edition: Mar 05
Page G4
