642 / 842 / 844 Telehandler
Hydraulic Components Main Valve
Ref. No.
Part No.
00 01a
102356 103054
02h 03h 04 05b
103051 103050 103049 103055
06g 07h 08c
103053 103052 103056
09g 10h 11h 12h 13d
103053 103048 103052 103046 103057
14g 15h 16h
103053 103046 103052
Description
Qty. Req.
Ref. No.
Part No.
COMPLETE ASY. . . . . . . . . . . . . . .1 INLET SECTION . . . . . . . . . . . . . . .1 (includes items 1-4) PLUG KIT 1-5/16” UNF . . . . . . . . . .1 PLUG KIT . . . . . . . . . . . . . . . . . . . .1 PILOT OPERATED RELIEF VLV . . .1 WORK SECTION (Frame Level) . . .1 (includes items 5-7) HYD. CONTROL KIT . . . . . . . . . . . .1 CHECK VALVE . . . . . . . . . . . . . . . .1 WORK SECTION (Boom In/out) . . .1 (includes items 8-12) HYD. CONTROL KIT . . . . . . . . . . . .1 ANTISHOCK VALVE (140 BAR) . . .1 CHECK VALVE . . . . . . . . . . . . . . . .1 ANTICAVITATION VALVE . . . . . . . .1 WORK SECTION (Boom Up/Down) 1 (includes items 13-17) HYD. CONTROL KIT . . . . . . . . . . . .1 ANTICAVITATION VALVE . . . . . . . .1 CHECK VALVE . . . . . . . . . . . . . . . .1
17h 18e
103047 103058
19g 20h 21h 22h 23
103053 103045 103052 103045 103061
24h 25 26f
103068 103059 103062
a b c d e f g
Use seal kit #103063 for all related seals. Use seal kit #103075 for all related seals. Use seal kit #103065 for all related seals. Use seal kit #103066 for all related seals. Use seal kit #103067 for all related seals. Items included with seal kit are not shown in detail. Includes outer caps, orings, bolts, plug and internal spool spring for this work section; does not include orings for valves/plugs or the spool. Includes required seals/orings for this valve/plug. Seals/orings for this valve are not sold individually, however they are included with the work section seal kit where this valve is used.
h
PRINTED IN U.S.A.
203
Description
Qty. Req.
KIT PLUG . . . . . . . . . . . . . . . . . . . .1 WORK SECTION (Tilt) . . . . . . . . . .1 (includes items 18-22) HYD. CONTROL KIT . . . . . . . . . . . .1 COMBINATED VALVE . . . . . . . . . . .1 CHECK VALVE . . . . . . . . . . . . . . . .1 COMBINATED VALVE . . . . . . . . . . .1 OUTLET SECTION . . . . . . . . . . . . .1 (includes item 24) PLUG . . . . . . . . . . . . . . . . . . . . . .AR TIE ROD KIT (4 section valve) . . . .1 SEAL KIT . . . . . . . . . . . . . . . . . . . . .1
913289/BP0208
