Replacing fuel filter with the engine stopped 1.
2. 3. 4. 5. 6. 7. 8. 9.
Cut out the filter to be replaced. A Both filters cut in (operating position) B Left filter cut out C Right filter cut out Unscrew cut-out easy-change filter with oil filter wrench. Clean sealing face on filter head. Check sealing ring on new easy-change fil‐ ter and moisten with fuel. Fit SOLAS shield (→ Page 19). Screw on easy-change filter and tighten by hand. Set three-way cock to operating position for both filters (normal position). Replace other fuel filters in the same way. Vent fuel system (→ Page 101).
Replacing fuel filter with the engine running 1. 2. 3. 4. 5. 6. 7. 8. 9.
TIM-ID: 0000004911 - 005
10.
Cut out the filter to be replaced. Open threaded vent plugs at filter head of cut-out filter and ensure that fuel filter is not under pressure. Close threaded vent plugs. Unscrew cut-out easy-change filter with oil filter wrench. Clean sealing face on filter head. Check sealing ring on new easy-change fil‐ ter and moisten with fuel. Fit SOLAS shield (→ Page 19). Screw on easy-change filter and tighten by hand. Set three-way cock to operating position for both filters (normal position). Replace other fuel filters in the same way.
104 | Task Description | MW15407/14E 2012-02
