7.8.2 DANGER
WARNING
Fuel prefilter – Differential pressure check and adjustment of gauge Unguarded rotating and moving engine components. Risk of serious injury – danger to life! • Take special care when working on a running engine.
Engine noise above 85 dB (A). Risk of damage to hearing! • Wear ear protectors.
Differential pressure gauge adjustment 1. 2.
When installing the new filter element: align adjustable pointer (2) with pressure-indicat‐ ing pointer (3) of pressure gauge (1). Verify that differential pressure is within the limit.
Fuel prefilter – Checking differential pressure With the engine running at full load or rated power, read off pressure at gauge (1). If differential pressure as indicated between position of adjustable pointer (2) and pressure indicator of pressure gauge (3) is ≥ 0.3 bar, flush filter element of the cut-in filter (→ Page 87).
TIM-ID: 0000004926 - 003
1. 2.
MS150062/01E 2012-01 | Task Description | 85 Downloaded from www.Manualslib.com manuals search engine
