1100 Series, 4 cylinder engines
4
7 Clean the connecting rod cap and the lower half of the bearing. Fit the bearing to the cap; ensure that the bearing is fitted correctly, see Operation 4-2. Lubricate the bearing with clean engine lubricating oil. Fit the cap and ensure that the assembly number is the same as that on the connecting rod and that the numbers are on the same side. Tighten the fasteners gradually and evenly, see Operation 4-2. 8 Check that the crankshaft will rotate freely. 9 Check the piston height above the top face of the cylinder block, see Operation 4-6. 10 Fit the lubricating oil pump, see Operation 10-10 or fit the balancer unit, see Operation 5-15. 11 Fit the lubricating oil sump, see Operation 10-5 12 Fit the cylinder head assembly, see Operation 3-10. 13 Fill the sump to the correct level with lubricating oil of an approved grade, refer to Chapter 5 in the User’s Handbook. 14 Fill the cooling system.
Workshop Manual, TPD 1487E, Issue 1
67
