1100 Series, 4 cylinder engines To fit the oil seal with the timing case removed 1 Clean the oil seal housing and check for damage, renew if necessary. 2 Check the crankshaft pulley for damaged. To repair the pulley, see Operation 6-15. 3 Check that the new oil seal has the sleeve protector fitted. 4 Align the oil seal to the oil seal housing. Do not lubricate the oil seal or the housing. 5 With a suitable tool, press the oil seal into the housing until contact is made with the bottom face of the housing. 6 Fit the timing case, see Operation 6-17.
7 When the front timing case cover is fitted, turn and pull the sleeve protector counter clockwise, to remove the sleeve from the seal. 8 Fit the crankshaft pulley immediately, see Operation 5-1.
