5
1100 Series, 4 cylinder engines
11 Fit the connecting rod caps, see Operation 4-2. Rotate the crankshaft two turns to ensure free movement. 12 Fit the lubricating oil pump, see Operation 10-10, or fit the balancer unit, see Operation 5-15. 13 Fit the rear end oil seal housing, see Operation 5-2. 14 Fit the flywheel housing, see Operation 13-3, and the flywheel, see Operation 13-1. 15 Fit the timing case and the timing gears, see Chapter 6, Timing case and drive assembly. 16 Fit the timing case cover, see Operation 6-2. 17 Fit the exhauster if removed, see Operation 15-5. 18 Fit the alternator and its mounting bracket, see Operation 14-4. 19 Fit the crankshaft pulley, see Operation 5-1. 20 Fit the fuel injection pump: l For Bosch VP30 fuel injection pumps, see Operation 11-10. l For Bosch EPVE fuel injection pumps, see Operation 11-12. l For Delphi DP210 fuel injection pumps, see Operation 11-14. 21 Fit the coolant pump, see Operation 12-5, the fan drive pulley and housing, see Operation 12-9, the drive belts, see Operation 14-3, and the fan, see Operation 12-8. 22 Fit the lubricating oil sump, see Operation 10-5. 23 After the engine has been installed, fill the lubricating oil sump to the correct level with an approved oil, refer to Chapter 5 in the User’s Handbook. 24 Fill the cooling system.
92
Workshop Manual, TPD 1487E, Issue 1
