Figure 344 Install capscrew and washers. Tighten to specified torque. See torque chart. Figure 347 Install reverse and forward clutch shaft rear bearing in transmission case.
REASSEMBLY OF TRANSMISSION (See Cleaning and Inspection Page)
Figure 345 Install forward-reverse oil distributor sleeve in transmiision case with inside diameter chamfer out, (toward front of transmission), and the notch in the distributor aligned up with the retaining set screw hole in the transmission case.
Figure 348 Install rear output bearing locating ring in transmission case.
Figure 346 Apply Loctite #243 and install set screw in transmission case and in oil distributor sleeve. Install set screw plug.
Figure 349 Install output bearing against locating ring.
- 60 -
