BLEEDING THE FUEL SYSTEM
1) Fuel filter cock 「 ON 」 2) Open the cock on the fuel injection pump. 3) Fill the tank with fuel and turn the ignition key to on. 4) Start the engine and allow it to run for a while. 5) Close the fuel injection pump cock. 6) The bleeding of the system is now finished. CHANGING THE OILS IN THE TRACTOR
Fuel Filter
Always use quality oils as engine or transmission oil (refer to page 63, 64) Refer to the table on page 57,58 and 59 for the change frequency. ▶ Changing engine oil. Park the tractor on a level surface, shut-off engine. Remove sump plug & drain oil. Replace and check the sump plug and refill the engine with oil to the correct level on the dipstick (approx. 1.85 gal). The grade of oil to be used will depend on the ambient temperature. (API CJ-4 grade) The tractor is shipped from the factory with 10W/30 For summer use over 77℉ use SAE 30 For temperatures from 32℉-77℉ use SAE20 or 10W/30 For temperatures below 32℉ use SAE 10W
Engine Oil Filler Engine Oil Filter Engine Level Gauge
61
