► FILLING DIAGRAM & CAPACITY TABLE
No.
Filling point
Fillings
Quantity Liter (gal) 2545Shuttle/ Shuttle Cab
MODEL RADIATOR
Fresh clean water(L.L.C) with an antifreeze, mixed in ratio of minimum 50%
7ℓ (1.85 US gal)
2
ENGINE
API : CJ-4 grade Above:25°C(77°F)…SAE30 or 10W-30 0°C to 25°C(32°F to 77°F)…SAE20 or 10W30 Below 0°C(32°F)…SAE 10W or 10W-30 MAHINDRA HEAVY DUTY SAE 15W-40
7.5 ℓ ( 1.98US gal)
3
TRANSMISSION CASE
(API GL-4 Grade, Gear Oil 80W)
35ℓ(9.25 US gal)
4
FRONT AXLE
5
FINAL DRIVE CASE(B)
6
BALL JOINT
Grease
As required
7
FUEL TANK
Diesel fuel
34ℓ(9.0 US gal)
1
(API GL-4 Grades)Gear oil #80 or #90 MAHINDRA EP GEAR OIL SAE 80W-90 (API GL-4 Grades) Gear oil #80 or #90 MAHINDRA UNIVERSAL TRACTOR FLUID
56
8.2ℓ(2.17US gal)
