OPERATING INSTRUCTIONS _______________________________________________
DRAWBAR Your tractor is equipped with a drawbar. Use the drawbar for connecting all pull-behind implements. DRAWBAR OPERATING POSITION
DRAWBAR HITCH CONNECTING PIN HOLE STORAGE PIN HOLE WITHOUT MID PTO
IMPLEMENT CONNECTING PIN HOLE
The drawbar must be in the storage position when using the three-point hitch.
STORAGE POSITION (WITH MID PTO)
STORAGE POSITION (WITHOUT MID PTO)
WITHOUT MID PTO
WITH MID PTO
Try to balance the load primarily on the implement wheels - as in loading a trailer or spreader. Avoid overloading the drawbar. Add front end weights for improved stability. Engage the clutch smoothly, avoid jerking and use the brakes cautiously to avoid jackM117 knifing. Rear upset can result if pulling from wrong location on tractor. Hitch only to the drawbar. Use 3 point hitch only with the implements deM119 signed for its use - not as a drawbar. 60
16 Series, Model - 2816 HST
