OPERATING INSTRUCTIONS _______________________________________________
Mid PTO The Mid PTO has a 25.4 mm (1 inch) diameter 15 spline output shaft. ENGAGE THE MID PTO AS FOLLOWS: 1. Push the clutch pedal fully.
MID PTO SHAFT
2. Move the Mid PTO control lever forward. 3. Release the clutch pedal slowly. DISENGAGE THE MID PTO AS FOLLOWS:
CLUTCH PEDAL
1. Push the clutch pedal fully. 2. Move the Mid PTO control lever to the OFF (Engine Start) slot. NOTE: Keep the Mid PTO control lever in the OFF (Engine Start) slot when starting the engine and when the PTO is not being used.
MID PTO LEVER
3. Release the clutch pedal. The following table shows the required engine speed to get the required Mid PTO output shaft speed. MID PTO Output Shaft Speed
Required Engine Speed
2000 RPM
2632 RPM
57
16 Series, Model - 2816 HST
