OPERATING INSTRUCTIONS _______________________________________________
POWER TAKEOFF (PTO) PTO driven machinery can cause serious injury or death, usually due to wrapped clothing. When required by the job to be in the drive shaft area, stay clear of rotating parts. Before working on the drive shaft, or servicing or clearing the driven machine, where applicable on this tractor, put the PTO clutch lever in the DISENGAGE position, the PTO lever in the NEUTRAL or OFF, and STOP the engine. M125A
Rear PTO
REAR PTO SHAFT
The rear PTO is a 540 RPM with a 34.9 mm (1 3/8 inch) diameter 6 spline output shaft. ENGAGE THE REAR PTO AS FOLLOWS: 1. Push the clutch pedal fully. 2. Move the PTO control lever forward or rearward. 3. Release the clutch pedal slowly.
CLUTCH PEDAL
DISENGAGE THE REAR PTO AS FOLLOWS: 1. Push the clutch pedal fully. 2. Move the PTO control lever to the N (Engine Start) Slot. NOTE: Keep the PTO control lever in the OFF position when starting the engine and when the PTO is not being used. REAR PTO CONTROL LEVER
3. Release the clutch pedal slowly.
The following table shows the required engine speed to get the required Rear PTO output shaft speed. PTO Output Shaft Speed
Required Engine Speed
540 RPM
2356 RPM
54
16 Series, Model - 2816 HST
