INSTRUMENTS/CONTROLS _____________________________________________ a
1. RANGE SHIFT LEVER — Move the range shift lever forward to place the transmission in L range. Move the lever to the rearward to place the transmission in M or H range. The center position between M and L or H and M places the transmission in N. NOTE: Be sure the range shift lever is In N (Engine start) slot when starting the engine. 2. REAR PTO CONTROL LEVER – Move the lever forward to engage the REAR PTO. Move the lever rearward to disengage the Rear PTO. NOTE: Be sure the Rear PTO control lever is in OFF slot when starting the engine
3. MID PTO CONTROL LEVER (IF EQUIPPED) — Move the lever forward to engage the MID PTO. Move the lever rearward to disengage the Mid PTO. NOTE: Be sure the Mid PTO control lever is in OFF slot when starting the engine.
NOTE: 1. The Rear and Mid PTO shaft can be operated at the same time. 2. When not using the Mid PTO shaft, cover the shaft with the Mid PTO cover. 36
16 Series, Model - 2816 HST
