▶Telescopic stabilizers adjustment The stabilizers are intended for limiting or preventing implement side movement. There should be no clearance(Position A) during implement transport and when working with grades,rollers mowers,seeders,drills and similar implements.However,a slight play is necessary(Position B) when working with ploughs,Harrows,ditchers,cultivators and the like:that is when working with “draft control”.The length of stabilizers is adjusted by removing the pin and rotating the turn buckle barrel by which the threaded ends are interconnected.
▶ADJUSTMENT OF THE TOP LINK Lengthening or shortening the top link will change the angle of the implement. The locating hole of the top link varies with the type of implement used. The most common locations are the 1st and 2nd hole from the top
1) For general implement :Use the Pin to “A: point 2) For Draft control
:Use the Pin to “B”point
▶ADJUSTMENT OF LOWER LINK The adjustment is done with the adjusting handle on the Right hand yoke rod To shorten it wind the handle clockwise and to lengthen it wind it anti-clockwise. When adjusted correctly hold the turn buckle with the stopper provided.
