DESCRIPTION AND OPERATION Automatic Transmission Fuse 2 of the passenger compartment fuse box (C0580) provides an ignition feed to the reverse lamp relay (C0935) on a G wire. When reverse gear is selected, the Electronic Automatic Transmission (EAT) ECU (C0932) provides a feed to the reverse lamp relay coil (C0935) a feed on an NG wire. The relay coil (C0935) is earthed on a B wire. The energised reverse lamp relay (C0935) is now able to provide a feed to the RH (C0455) and LH (C0472) reverse lamps on GN wires. Both lamps are earthed on B wires. For more information on EAT operation, refer to the Electronic Automatic Transmission (EAT) – 01MY , or Electronic Automatic Transmission (EAT) – 02MY section of this manual. + ELECTRONIC AUTOMATIC TRANSMISSION (EAT) – 01MY. + ELECTRONIC AUTOMATIC TRANSMISSION (EAT) – 02MY.

Land Rover Freelander 2001 MY ON Electrical Library Manual - PDF DOWNLOAD

Articles inside

FUEL PUMP .................................................................................................. 4

AUDIO SYSTEM – HIGH RANGE (02MY) .................................................... 4

AUDIO SYSTEM – MID RANGE (02MY) ...................................................... 4

AUDIO SYSTEM – LOW RANGE (02MY) ..................................................... 4

AUDIO SYSTEM – 01MY .............................................................................. 4

ACCESSORY SOCKET ................................................................................ 4

CIGAR LIGHTER .......................................................................................... 4

REMOTE DISPLAY / CLOCK ....................................................................... 4

HORNS ......................................................................................................... 4

INSTRUMENTS ............................................................................................ 4

HEAD, SIDE AND TAIL LAMPS – CANADA ................................................. 4

INTERIOR ILLUMINATION ........................................................................... 4

INTERIOR LAMPS ........................................................................................ 4

HEAD, SIDE AND TAIL LAMPS .................................................................... 4

FOG LAMPS ................................................................................................. 4

DIRECTION INDICATOR/HAZARD WARNING LAMPS ............................... 4

BRAKE AND REVERSE LAMPS .................................................................. 4

WIPERS AND WASHERS ............................................................................ 4

HEATED FRONT SCREEN (HFS) ................................................................ 4

HEATED REAR WINDOW (HRW) ................................................................ 4

HEATER BLOWER ......................................................................................... 4

COOLING FANS ............................................................................................. 4

FUEL BURNING HEATER (FBH) .................................................................... 4

AIR CONDITIONING (A/C) – K SERIES AND KV6 ......................................... 4

AIR CONDITIONING (A/C) – KV6 (NORTH AMERICA) ................................. 4

AIR CONDITIONING (A/C) – Td4 ................................................................... 4

SUPPLEMENTARY RESTRAINT SYSTEM (SRS) ......................................... 4

ANTI-LOCK BRAKING SYSTEM (ABS) – 02MY ............................................ 4

ELECTRONIC AUTOMATIC TRANSMISSION (EAT) – 01MY ....................... 4

CRUISE CONTROL – KV6 ............................................................................. 4

ANTI-LOCK BRAKING SYSTEM (ABS) – 01MY ............................................ 4

CRUISE CONTROL – TD4 (02MY) & KV6 (NORTH AMERICA) .................... 4

ELECTRONIC AUTOMATIC TRANSMISSION (EAT) – 02MY ....................... 4

CRUISE CONTROL – Td4 (01MY) ................................................................. 4

CHARGING AND STARTING – KV6 (NORTH AMERICA) ............................. 4

DIAGNOSTIC SOCKET .................................................................................. 4

ENGINE IMMOBILISATION .............................................................................. 4

HEATED SEATS ............................................................................................. 4

DOOR MIRRORS ............................................................................................ 4

CHARGING AND STARTING – KV6 .............................................................. 4

CHARGING AND STARTING – K SERIES ..................................................... 4

CHARGING AND STARTING – Td4 ............................................................... 4
