PL/RL / BEAM (SHEAR BOLT) PosNo. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
Part No. KK015830 KK016022 KK016045 KK016049 KK032762 KK032807 KK032845 KK032865 KK035060R KK035072R KK035215 KK061515 KK062020 KK071270R KK071271R KK071272R KK071273R KK071274 KK071275 KK074910R KK074911R
© Kverneland Group
Qty.
Description NUT M20 FLANGE NUT M30 10 KEY36 FLANGE NUT M30 LEFT KEY 36 FLANGE NUT M20 WITH LOCK HEX BOLT M16X60 12.9 HEX BOLT M20X100 10.9 HEX BOLT M20X45 10.9 HEX BOLT M20X65 10.9 SHEARBOLT M20X60 SHEAR BOLT M20X88 W/NUT HEX BOLT M20X80 W/NUT BUSHING D20.5-D28X35.2 WASHER D20-D35X14 CONVEX CENTER SECT. SHEARBOLT BEAM H=800 CENTER SECT. SHEARBOLT BEAM H=700 RIGHT SECTION SHEARBOLT BEAM LEFT SECTION SHEARBOLT BEAM BOLT M30 R.HAND THREAD L=84 BOLT M30 L.HAND THREAD L= 84 PLATE FOR SHARE BOLT BEAM PLATE FOR BEAM H=800
PL467, < Mach. ID <= RL161->
Remark
