Installation
of Arm Cylinder
Hoses
(1) Remove the blind plug from the piping at the arm cylinder end, then replace the O-rings (07OOO13038 x 4) with new parts, and connect the arm cylinder hoses (PC600: 07074-01215 x 2, PC650: 07074-01211 x 2). Use the split flange, bolt, and other blind parts again.
Precautions 1. Becareful nottoietthearmcylinderrod jump out during operation. 2. After removing the flanges, O-rings, and heads, keep them in a safe place so that they can be used again. 3. When installing the hoses, be extremely careful not to get the O-rings caught. 4. When installing the hoses, be extremely careful not to let dirt or dust get into the circuit.
42
-
No.
Parts sent individually Part No. Part Name Hose 07074-01215 O-ring 07000-13038 Above parts are for PC600 Hose O-ring
07074-01211 07000-13032 Above parts are for PC650
Q’ty 2 4
2 4
