FIGURE 2-6. CONTROL VALVE ASSEMBLY - BANG-BANG WITH DUMP SECTION
ITEM PART NUMBER QTY
DESCRIPTION
Ref CONTROL VALVE ASSEMBLY - BANG-BANG 4640941 Ref VALVE ASSEMBLY - 3 SECTION 4640909 Ref VALVE ASSEMBLY - 4 SECTION Ref DUMP SECTION ASSEMBLY 1 7002447 1 Dump Section - Complete 2 7002448 1 Cartridge 2 7002449 1 Seal Kit - 7002448 Cartridge 3 7002450 1 Coil 4 7002451 1 Cartridge without Coil 4 7011118 1 Seal Kit - 7002451 Cartridge 7000448 2 O-Ring (Square Cut) (Between Sections) Ref WORKING SECTIONS (STANDARD PARTS) 101 7004859 2 Solenoid Assembly 102 7003825 1 Washer 103 7002348 1 Spring 104 7002305 1 Guide Tube Assembly 105 7002345 1 Cone, Female 105 Kit 1 O-Ring 105 Kit 1 O-Ring 106 7002346 1 Pin, Push 107 7002344 1 Plunger 108 7000470 1 Tube, Guide 109 7002341 1 Pin Actuator 109 Kit 1 Ring, Quad 110 7002340 1 Guide, External Push Pin 110 Kit 1 O-Ring 111 7002333 1 Sleeve, Inner Flux 112 7002334 1 Spring 113 7002336 1 Sleeve, Outer Flux 114 7000418 1 Coil 115 7002335 1 Case, Solenoid 116 7002338 1 Plate, End 116 7002327 1 Nameplate 117 7002339 4 Screw 7000414 2 Seal Kit - Working Section (1 Per Section) Ref WORKING SECTIONS - COMPLETE (INCLUDES ITEMS 101-
117 AND BLOCK VALVE ASSEMBLY WHEN EQUIPPED)
151 Ref Section #1 Options: 151 7002315 1 Steer Section (4640941 Valve) 151 7002317 1 Rotate Section (4640909 Valve) 152 Ref Section #2 Options: 152 7002316 1 Level Section (4640941 Valve) (Prior to SN 27357) 152 7011183 1 Level Section (4640941 Valve) (SN 27357 to Present) 152 7002315 1 Steer Section (4640909 Valve) 153 Ref Section #3 Options: 153 7002315 1 Tele Section (4640941 Valve) 153 7002316 1 Level Section (4640909 Valve) (Prior to SN 27357) 153 7011183 1 Level Section (4640909 Valve) (SN 27357 to Present) 154 Ref Section #4 Options: 154 7003855 1 Tele Section (4640909 Valve Only)
REV
B A
ITEM PART NUMBER QTY DESCRIPTION
155 Ref Relief Valve Options: 155 7000468 AR Crossover Relief Valve Assembly - 7002315 Steer/Tele and 7003855 Tele Sections (Due to various suppliers - internal components are no longer field serviceable) 155 7002262 AR Dual Pilot Check Valve Assembly - 7002316 Level Sections (Due to various suppliers - internal components are no longer field serviceable) (Prior to SN 27357) 155 7011183 AR Dual Pilot Check Valve Assembly - 7011182 Level Sections (Due to various suppliers - internal components are no longer field serviceable) (SN 27357 to Present)
