FIGURE 6-16. HYDRAULIC DIAGRAM - SWING

from JLG 80HX 80HX+6 Parts Manual (3120800) -PDF Download En

FIGURE 7-1. ELECTRICAL DIAGRAM LIST

FIGURE 6-16. HYDRAULIC DIAGRAM - SWING

ITEM PART NUMBER QTY

DESCRIPTION

2791285 Ref HYDRAULIC DIAGRAM - SWING 1 2220577 2 Fitting, Straight 2 2750785 2 Hose 3 2220497 2 Fitting 5 2220635 2 Fitting, Tee 6 2220609 2 Fitting, Reducer 7 2750900 3 Hose 8 2220466 1 Fitting, 90 12 2220414 2 Fitting, Straight 13 4640013 1 Valve, Shuttle 14 2220416 2 Fitting, 90 0100011 AR Loctite 0100020 AR Sealant

FIGURE 6-16. HYDRAULIC DIAGRAM - SWING
