FIGURE 8-1. DECALS INSTALLATION
FIGURE 8-1. DECALS INSTALLATION
FIGURE 8-1. DECALS INSTALLATION
ITEM PART NUMBER QTY
DESCRIPTION
Ref COMMON DECALS INSTALLATION 0257201 Ref Australian Spec 80HX With Brown Decals 0257200 Ref Australian Spec 80HX With Black Decals 0257203 Ref Australian Spec 80HX+6 With Brown Decals 0257202 Ref Australian Spec 80HX+6 With Black Decals 0252146 Ref CE Spec 80HX With Brown Decals 0252147 Ref CE Spec 80HX With Black Decals 0252140 Ref CE Spec 80HX+6 With Brown Decals 0252138 Ref CE Spec 80HX+6 With Black Decals 1 Not Available 1 Nameplate - Serial Number 2 1700584 1 Decal - Patent 3 1701509 1 Decal - Manual 4 Ref Decal - Manual Descent Options: 4 1701745 1 Decal - Manual Descent (Prior to SN 25609) 4 1703480 1 Decal - Manual Descent (SN 25609 to Present) 12 Ref Decal - Extend-A-Reach Options: 12 Not Required 0 Decal - Extend-A-Reach 80HX 12 1701375 2 Decal - Extend-A-Reach 80HX+6/86HX Brown 12 1701431 2 Decal - Extend-A-Reach 80HX+6/86HX Black 13 1701518 AR Decal - Crushing 14 1701501 4 Decal - Arrow 16 Ref Decal - Fuel Options: 16 1701542 1 Gas 16 1701505 1 Diesel 17 1701504 1 Decal - Hydraulic 18 1701500 8 Decal - Tie-Down/Lid-up 19 Ref Decal - Fuel LP Gas Options: 19 Not Required 0 Without Dual Fuel 19 1701543 1 With Dual Fuel 20 Ref Stripe Options: 20 Ref Stripe 80HX: 20 1700431 40 ft/12.2m Brown (Prior to August 1995) 20 1701703 40 ft/12.2m Brown (August 1995 to Present) 20 1701334 40 ft/12.2m Black
20 Ref Stripe 80HX+6/86HX 20 1700431 41 ft/12.5m Brown (Prior to August 1995)
20 1701703 41 ft/12.5m Brown (August 1995 to Present)
20 1701334 41 ft/12.5m Black
22 3820001 AR Rivet 27 Ref Decal - Model Designation Options: 27 1700639 2 Decal - Model Designation 80HX Brown (Prior to March 1992) 27 1701741 2 Decal - Model Designation 80HX Brown (March 1992 to Present) 27 1701026 2 Decal - Model Designation 80HX Black (Prior to March 1992) 27 1701747 2 Decal - Model Designation 80HX Black (March 1992 to Present)
REV
7-4 7-4 8-4 8-3 8-3 8-3 9-1 9-3
ITEM PART NUMBER QTY
DESCRIPTION
27 1701379 2 Decal - Model Designation 80HX+6 Black 28 Ref Decal - JLG Lift or JLG Options: 28 1700422 1 JLG Lift - 80HX Brown (Prior to April 1992) 28 1701684 1 JLG Lift - 80HX Brown (April 1992 to Present) 28 1700349 1 JLG Lift - 80HX Black (Prior to April 1992) 28 1701685 1 JLG Lift - 80HX Black (April 1992 to Present) 28 1701376 1 JLG - 80HX+6/86HX Brown 28 1701548 1 JLG - 80HX+6/86HX Black 29 Ref Decal - JLG Lift or JLG Options: 29 1700422 2 JLG Lift - 80HX Brown (Prior to April 1992) 29 1701684 2 JLG Lift - 80HX Brown (April 1992 to Present) 29 1700349 2 JLG Lift - 80HX Black (Prior to April 1992) 29 1701685 2 JLG Lift - 80HX Black (April 1992 to Present) 29 Not Required 0 Decal - JLG Lift or JLG 80HX+6/86HX Brown 31 Ref Decal - LP Gas Caution Options: 31 Not Required 0 Without Dual Fuel 31 3252345 1 With Dual Fuel 33 0961127 1 Bushing, Snap 34 0100010 AR Loctite, Adhesive (Not Shown) 35 1701502 1 Decal - Hydraulic Oil High 36 0860520 1 Box, Manual Storage 37 3311405 5 Locknut 1/4in-20NC 38 4751400 6 Flatwasher 1/4in 39 1060279 1 Cable, Lanyard 40 0641408 1 Bolt 1/4in-20NC x 1in 43 3251813 1 Decal - USA (Prior to August 1995 Only) 44 Ref Decal - JLG Options: 44 1700981 1 Decal - JLG (Brown) 44 1701321 1 Decal - JLG (Black) 46 Ref Decal - JLG Options: 46 Not Required 0 Decal - JLG 80HX 46 1701110 2 Decal - JLG 80HX+6/86HX Brown 46 1701433 2 Decal - JLG 80HX+6/86HX Black 47 1701503 1 Decal - Hydraulic Oil Low 48 1701499 2 Decal - Lift Here/Tiedown 49 1701555 4 Decal - Tire Pressure (Prior to August 1995 Only) 54 4420052 6.1 ft/1.9m Tape, Safety 57 Not Available 1 Decal - Bar Code (August 1995 to Present) 0251685 Ref LIFTING DIAGRAM INSTALLATION -
REV
101 3252095 2 Decal - Lifting Diagram 101 3820001 8 Rivet Ref DECAL INSTALLATION (VARIABLE PARTS) 0252150 Ref Decal Installation 80HX Australian Spec (Prior to SN 25609) 6 0257200 Ref Decal Installation 80HX Australian Spec (SN 25609 to Present) 3 0257201 Ref Decal Installation 80HX Australian Spec (SN 25609 to Present) 3 0252156 Ref Decal Installation 80HX+6/86HX Australian Spec (Prior to SN
25609)
7 0257202 Ref Decal Installation 80HX+6/86HX Australian Spec (SN 25609 to
Present)
1 0257203 Ref Decal Installation 80HX+6/86HX Australian Spec (SN 25609 to
Present)
3
ITEM PART NUMBER QTY DESCRIPTION REV
0254406 Ref Australian Spec Only (Prior to SN 25609) 0252908 Ref Decal Installation 80HX Dutch Spec 0252912 Ref Decal Installation 80HX+6/86HX Dutch Spec 0252151 Ref Decal Installation 80HX French Spec 0252155 Ref Decal Installation 80HX+6/86HX French Spec
A 4 3 3 3 0252148 Ref Decal Installation 80HX German and Austrian Spec 3 0252139 Ref Decal Installation 80HX+6/86HX German and Austrian Spec 4 0252907 Ref Decal Installation 80HX Italian Spec 2 0252911 Ref Decal Installation 80HX+6/86HX Italian Spec 3 0253249 Ref Decal Installation 80HX Spanish Spec 2 0253275 Ref Decal Installation 80HX+6/86HX Spanish Spec 3 0252150 Ref Decal Installation 80HX UK English Spec 6 0252156 Ref Decal Installation 80HX+6/86HX UK English Spec 7 201 Ref Nameplate - Footswitch Warning Options: 201 3252347 1 Australian Spec 201 1703518 1 Dutch Spec 201 1693292 1 French Spec 201 1693294 1 German and Austrian Spec 201 1701600 1 Italian Spec 201 1701791 1 Spanish Spec 201 3252347 1 UK English Spec 202 Ref Decal - Ground Control Location Options: 202 1700037 1 Australian Spec 202 1701616 1 Dutch Spec 202 1701515 1 French Spec 202 1693285 1 German and Austrian Spec 202 1701599 1 Italian Spec 202 1701789 1 Spanish Spec 202 1700037 1 UK English Spec 203 Ref Nameplate - Axle Extend/Retract Options: 203 3251637 1 Australian Spec (Prior to May 1994) 203 1702301 1 Australian Spec (May 1994 to October 1995) 203 1702888 1 Australian Spec (October 1995 to Present) 203 1701533 1 Dutch Spec 203 1701534 1 French Spec 203 1701564 1 German and Austrian Spec 203 1701698 1 Italian Spec 203 1701797 1 Spanish Spec 203 3251637 1 UK English Spec (Prior to May 1994) 203 1702301 1 UK English Spec (May 1994 to October 1995) 203 1702888 1 UK English Spec (October 1995 to Present) 204 Ref Decal - Steer/Axle Select Options: 204 3251870 1 Australian Spec 204 1701531 1 Dutch Spec 204 1701506 1 French Spec 204 1701562 1 German and Austrian Spec 204 1701696 1 Italian Spec 204 1701795 1 Spanish Spec 204 3251870 1 UK English Spec 205 Ref Decal - Caution Options: 205 1690696 1 Australian Spec
ITEM PART NUMBER QTY DESCRIPTION
205 Not Required 1 Dutch Spec 205 1693286 1 French Spec 205 1693288 1 German and Austrian Spec 205 1701601 1 Italian Spec 205 1701794 1 Spanish Spec 205 Not Required 1 UK English Spec 206 Ref Decal - Caution Options: 206 1690697 1 Australian Spec 206 1701567 1 Dutch Spec 206 1701577 1 French Spec 206 1690697 1 German and Austrian Spec 206 1690697 1 Italian Spec 206 1690697 1 Spanish Spec 206 Not Required 1 UK English Spec 207 Ref Decal - Caution Options: 207 1691483 1 Australian Spec 207 1701596 1 Dutch Spec 207 1693289 1 French Spec 207 1693291 1 German and Austrian Spec 207 1701602 1 Italian Spec 207 1701798 1 Spanish Spec 207 Not Required 1 UK English Spec 208 Ref Decal Options: 208 1701818 1 Australian Spec 208 1701596 1 Dutch Spec 208 Not Required 1 French Spec 208 Not Required 1 German and Austrian Spec 208 Not Required 1 Italian Spec 208 Not Required 1 Spanish Spec 208 Not Required 1 UK English Spec 209 Ref Nameplate Options (Australian Spec Only): 209 3252197 1 Australian Spec (Prior to SN 27326) 209 1702958 1 Australian Spec (SN 27326 to Present) 209 Not Required 1 Dutch, French, German, Austrian, Italian, Spanish and UK English Specs 210 Ref Decal - Max Tire Load (SN 25609 to Present) 210 Not Required 1 Australian Spec 210 1703477 Dutch, French, German, Austrian Italian, Spanish and UK English Specs 211 Ref Nameplate - CE (SN 25609 to Present) 211 Not Required 0 Australian Spec 211 1702928 Dutch, French, German, Austrian, Italian, Spanish and UK English Specs 212 Ref Tape, Safety 212 4420052 14.7 ft/4.5 Australian Spec 212 4420052 14.7 ft/4.5 Dutch, French, German, Austrian, Italian, Spanish and UK English Specs (Prior to SN 25609) 212 4420051 14.7 ft/4.5 Dutch, French, German, Austrian, Italian, Spanish and UK English Specs (SN 25609 to Present) 213 Ref Decal - Safe Working Load Options 213 Not Required 0 Australian Spec (Prior to SN 34839) 213 1703677 1 Australian Spec (SN 34839 to Present)
REV
ITEM PART NUMBER QTY
DESCRIPTION
213 Not Required 0 Dutch, French, German, Austrian, Italian, Spanish and UK English Specs (Prior to SN 25609)
214
Ref Decal - Danger (Electrical Hazard) Options: 214 Not Required 0 Australian Spec (Prior to SN 34839) 214 1703665 2 Australian Spec (SN 34839 to Present) 214 Not Required 0 Dutch, French, German, Austrian, Italian, Spanish and UK English Specs (Prior to SN 25609) 215 Ref Decal - Maintenance Options: 215 Not Required 0 Australian Spec (Prior to SN 34839) 215 1703663 1 Australian Spec (SN 34839 to Present) 215 Not Required 0 Dutch, French, German, Austrian, Italian, Spanish and UK English Specs (Prior to SN 25609) 216 Ref Decal - Caution (Safety Harness) 216 Not Required 0 Australian Spec (Prior to SN 34839) 216 1703664 1 Australian Spec (SN 34839 to Present) 216 Not Required 0 Dutch, French, German, Austrian, Italian, Spanish and UK English Specs (Prior to SN 25609) Ref Decal Kit Options: 2900994 1 Decal Kit 80HX Australian Spec with Brown Decals (Includes Items 2, 3, 13, 14, 17, 18, 27, 28, 29, 35, 44, 48, 54 & 202-206) 2900995 1 Decal Kit 80HX+6 Australian Spec with Brown Decals (Includes Items 2, 3, 4, 12, 13, 14, 17, 18, 27, 28, 35, 44, 46-49, 54 & 202-207) 2900981 1 Decal Kit 80HX Dutch Spec (Brown Decals) (Includes Items 24, 13, 15, 17, 18, 35, 47, 48, 81, 82, 86, 87, 201-204, 206-208, 210 & 211) 2900982 1 Decal Kit 80HX+6 Dutch Spec (Brown Decals) (Includes Items 2-4, 13, 15, 17, 18, 35, 47, 48, 82-84, 87, 201-204, 206-208, 210 & 211) Not Available Ref Note: All other specs and colors are not available.
