FIGURE 6-1. AXLE LOCKOUT HYDRAULIC DIAGRAM - 2WD

FIGURE 6-1. AXLE LOCKOUT HYDRAULIC DIAGRAM - 2WD

FIGURE 6-1. AXLE LOCKOUT HYDRAULIC DIAGRAM - 2WD

ITEM PART NUMBER QTY

DESCRIPTION

Ref AXLE LOCKOUT HYDRAULIC DIAGRAMS 2792356 Ref 2WD 1 2220502 1 Fitting, 45 2 2220415 3 Fitting, Straight 3 2220603 1 Fitting, Straight 4 2220579 1 Fitting, Tee 5 2220635 1 Fitting, Tee 6 2220582 3 Fitting, Straight 8 2220371 2 Fitting, Straight 9 2750895 1 Hose 10 2751026 1 Hose 11 2750888 2 Hose 12 2753070 2 Hose 13 2752648 1 Hose 14 2220619 1 Fitting, Reducer 15 2220861 1 Fitting, Tee

REV

2-B
