FIGURE 2-4. SWING MOTOR ASSEMBLY
FIGURE 2-4. SWING MOTOR ASSEMBLY
FIGURE 2-4. SWING MOTOR ASSEMBLY
ITEM PART NUMBER QTY
DESCRIPTION
3160182 Ref SWING MOTOR ASSEMBLY 1 See Note NSS Seal, Dust (Note: Use Item 51) 2 See Note NSS Ring, Retaining (Note: Use Item 51) 3 See Note NSS Shim, Back-Up (Note: Use Item 51) 4 See Note NSS Seal, Housing (Note: Use Item 51) 5 See Note NSS Seal, Body (Note: Use Item 51) 6 See Note NSS Seal, Shaft (Note: Use Item 51) 6 See Note NSS Ring, Teflon Back-Up (Note: Use Item 51) 6 See Note NSS Shim, Back-Up (Note: Use Item 51) 7 See Note NSS Washer, Thrust (Note: Use Item 51) 8 7005809 1 Bearing, Thrust 9 7005812 1 Plate, Wear 10 7005874 1 Cover, End 11 See Note AR Ball (Part of Item 10) (Use p/n 7005874) 12 7005876 1 Plug, Cooling 13 7005804 1 Housing 14 7005811 1 Link, Drive 15 7005877 1 Rotor Set Assembly 16 7005878 AR Pin, Drive Link 17 7005821 4 Bolt 18 7005879 1 Shaft 19 7005880 1 Key 51 7005881 1 Seal Kit (Includes Items 1-6)
