FIGURE 4-4. CONSOLE BOX ASSEMBLY (STANDARD BANG-BANG CONTROLS
ITEM PART NUMBER QTY
DESCRIPTION
Ref CONSOLE BOX ASSEMBLIES 0860622 Ref CONSOLE BOX ASSEMBLY - 2WS FORD/DEUTZ 0860660 Ref CONSOLE BOX ASSEMBLY - 2WS KUBOTA 0860714 Ref CONSOLE BOX ASSEMBLY - 4WS FORD/DEUTZ 0860715 Ref CONSOLE BOX ASSEMBLY - 4WS KUBOTA 1 4842892 1 Box, Console 2 Ref Lid Options: 2 3251909 1 Lid (Prior to May 1994) 2 3252362 1 Lid (May 1994 to November 1994) 2 1702399 1 Decal, Lid (November 1994 to Present) 2 3538389 1 Lid, Plate (November 1994 to Present) 2 4420008 52 in/1.3m Tape, Insulation 3 0751006 6 Screw, Pan Head #10-24NC x 3/4in 4 3300177 6 Nut, Tinnerman 5 2920015 1 Lamp (Out of Level) 6 4360199 1 Switch, Toggle (Ignition/Emergency Stop) 6 3790012 1 O-Ring 6 4360141 1 Guard, Switch 7 4360199 1 Switch, Toggle (High Engine) 7 3790012 1 O-Ring 8 4360199 1 Switch, Toggle (Drive Speed) 8 3790012 1 O-Ring 9 Ref Controller Options: 9 1600116 1 Controller (2WS) 9 7003783 1 Electrical Assembly 9 2560041 1 Knob (2WS) 9 1600135 1 Controller (4WS) 9 7003797 1 Electrical Assembly 9 7003789 2 Switch, Roller 10 4360274 1 Switch, Push Button (Horn) 10 3790015 1 O-Ring 11 4360274 1 Switch, Push Button (Start) 11 3790015 1 O-Ring 12 4360199 1 Switch, Toggle (Function Speed) 12 3790012 1 O-Ring 13 4360202 1 Switch, Toggle (Steer) 13 4060229 1 Guard, Switch 13 3790012 1 O-Ring 14 4360202 1 Switch, Toggle (Main Telescope) 14 4060229 1 Guard, Switch 14 3790012 1 O-Ring 15 4360202 1 Switch, Toggle (Swing) 15 4060229 1 Guard, Switch 15 3790012 1 O-Ring 16 4360202 1 Switch, Toggle (Platform Rotate) (With Rotating Platform Only) 16 4060229 1 Guard, Switch 16 3790012 1 O-Ring 17 4360202 1 Switch, Toggle (Platform Level) 17 4060229 1 Guard, Switch 17 3790012 1 O-Ring
REV
L I F F
ITEM PART NUMBER QTY
DESCRIPTION
18 4360202 1 Switch, Toggle (Main Lift) 18 4060229 1 Guard, Switch 18 3790012 1 O-Ring 19 4360202 1 Switch, Toggle (Tower Lift) 19 4060229 1 Guard, Switch 19 3790012 1 O-Ring 20 4360200 1 Switch, Toggle (Auxiliary Power) 20 4060229 1 Guard, Switch 20 3790012 1 O-Ring 21 Ref Rail Options: 21 3640500 1 Rail (2WS) 21 3640970 1 Rail (4WS) 21 3910606 2 Screw, Machine #6-32NC x 3/8in 21 4760600 2 Lockwasher #6 21 3310601 2 Nut #6-32NC 22 4460299 2 Stop, Terminal 23 4460298 Ref Block, Terminal 23 4460298 AR 2WS - Qty. 40 23 4460298 AR 4WS - Qty. 45 23 4460301 1 Strip, Marking 24 4460311 1 Bar, Buss - 5 Position 24 4460305 5 Screw 24 4460306 5 Washer 24 4460307 5 Sleeve 25 4460300 1 Barrier, Terminal 26 3740058 1 Relay 26 4120013 1 Socket, Relay 26 3740063 1 Spring, Relay 27 4360209 1 Breaker, Circuit - 20 Amp 27 3311001 1 Nut #10-24NC 27 4761000 1 Lockwasher #10 28 4460244 1 Connector 28 0960238 1 Bushing 28 3300048 1 Nut, Conduit 29 4460052 3 Connector 29 0960239 3 Bushing 29 3300047 3 Nut, Conduit 30 0860038 1 Box 30 4460190 1 Receptacle 30 4060092 1 Cover 30 3910608 4 Screw, Machine #6-32NC x 1/2in 30 4760600 4 Lockwasher #6 30 4460071 1 Connector 31 0140001 1 Horn 32 4360274 1 Switch, Push Button (Glow Plugs) (Kubota) 32 3520026 1 Plug, Hole (Ford and Deutz) 33 3740049 2 Relay (4WS Only) 33 4761000 2 Lockwasher #10 33 3311001 2 Nut #10-24NC 34 4740120 6 Washer, Nylon 57 0720804 4 Screw, Machine #8-32NC x 1/2 (October 1995 to Present)
REV
ITEM PART NUMBER QTY
DESCRIPTION
58 4750800 4 Flatwasher #8 (October 1995 to Present) 59 4760800 4 Lockwasher #8 (October 1995 to Present) Ref 110V POWER CORD INSTALLATIONS 0252405 Ref 110V POWER CORD INSTALLATIONS (PRIOR TO OCTOBER
1993)
0254438 Ref 110V POWER CORD INSTALLATIONS (OCTOBER 1993
PRESENT)
101 Ref Cable, Electrical - 12/3 Options: 101 1060300 32 ft/9.8m Cable, Electrical (Prior to October 1993) 101 1060514 70 ft/21.3m Cable, Electrical (October 1993 to Present) (was p/n 1060268)
101 4460205 1 Plug
REV
3
