FIGURE 4-1. STANDARD PLATFORM AND FOOTSWITCH INSTALLATION
ITEM PART NUMBER QTY DESCRIPTION REV
0238727 Ref FIXED SUPPORT INSTALLATION (STANDARD BANG-BANG
AND PROPORTIONAL CONTROLS)
E
0251037 Ref FIXED SUPPORT INSTALLATION (HYDRAULIC CONTROLS) B 1 4842978 1 Support Weldment 1 0961257 2 Bushing, Bronze 2 4761500 2 Lockwasher 5/16in 3 0681610 8 Bolt 3/8in-16NC x 1 1/4in (Grade 8) 4 4751600 16 Flatwasher 3/8in 5 3300143 8 Locknut 3/8in-16NC 6 2160002 1 Fitting, Grease 7 0641522 2 Bolt 5/16in-18NC x 2 3/4in 8 3421490 1 Pin, Nose 9 1681866 1 Platform Level Cylinder Assembly (Machines Built Prior to January 1990) (See CYLINDER SECTION for Breakdown) 9 1682178 1 Platform Level Cylinder Assembly (Machines Built January 1990 to October 1992) (See CYLINDER SECTION for Breakdown) 9 1682793 1 Platform Level Cylinder Assembly - TUV (Machines Built October 1992 to Present) (See CYLINDER SECTION for Breakdown) 10 3421491 1 Pin, Attach (Lower) 11 3421494 1 Pin, Attach (Upper) 12 3532054 1 Plate, Retainer 13 0641506 2 Bolt 5/16in-18NC x 3/4in 14 4060804 10 in/26cm Shield, Hose (1/2in Flex-Guard) 15 3311505 2 Locknut 5/16in-18NC 16 4340596 1 Support, Hose (Hydraulic Controls Only) 16 4300031 2 Stud (Welded on Part) 16 4751400 2 Flatwasher 1/4in 16 3311405 2 Locknut 1/4in-20NC 0238568 Ref ROTATING SUPPORT INSTALLATION DOMESTIC
(STANDARD BANG-BANG AND PROPORTIONAL CONTROLS)
M 0252220 Ref ROTATING SUPPORT INSTALLATION (CSA STANDARD
BANG-BANG AND PROPORTIONAL CONTROLS)
5 0251038 Ref ROTATING SUPPORT INSTALLATION (DOMESTIC
HYDRAULIC CONTROLS)
D 0252404 Ref ROTATING SUPPORT INSTALLATION (CSA HYDRAULIC
CONTROLS)
4 101 4843636 1 Support Weldment 101 0961259 2 Bushing, Bronze 102 0238540 1 Pivot Attach Weldment (Machines Built Prior to October 1992) 102 0253730 1 Pivot Attach Weldment (TUV Cylinders) (Machines Built October 1992 to Present) 102 0961257 2 Bushing, Bronze 103 1120299 1 Cap 104 4842915 1 Shaft Weldment (Standard) 104 4842915 1 Shaft Weldment (C.S.A.) (was p/n 4040220) 105 0235238 1 Rotator Assembly (See Items 201-225 for Breakdown) 106 0361675 1 Block, Stop 107 4070705 AR Shim 1/8in 108 4070706 AR Shim 1/16in 109 4751500 2 Flatwasher 5/16in 110 4761500 4 Lockwasher 5/16in
ITEM PART NUMBER QTY DESCRIPTION
111 3311501 2 Nut 5/16in-18NC 112 3340454 2 Pad, Brake 113 4160026 8 Washer, Bellville 114 2880404 1 Key, Square 115 0652014 1 Bolt 5/8in-18NF x 1 3/4in 116 4752000 1 Flatwasher 5/8in 117 0681610 8 Bolt 3/8in-16NC x 1 1/4in 118 4751600 16 Flatwasher 3/8in 119 3300143 8 Locknut 3/8in-16NC 120 0641836 1 Bolt 1/2in-13NC x 4 1/2in 121 4751800 1 Flatwasher 1/2in 122 3311805 1 Locknut 1/2in-13NC 123 2160002 4 Fitting, Grease 124 0641522 2 Bolt 5/16in-18NC x 2 3/4in 125 3421490 1 Pin, Attach (Standard) 125 3421968 1 Pin, Attach (C.S.A.) 126 4740158 1 Washer, Thrust 127 1670451 1 Cover, Rotator 128 4300038 2 Stud (Welded on Part) 129 1681866 1 Slave Cylinder Assembly (Machines Built Prior to January 1990) (See CYLINDER SECTION for Breakdown) 129 1682178 1 Slave Cylinder Assembly (Machines Built January 1990 to October 1992) (See CYLINDER SECTION for Breakdown) 129 1682793 1 Slave Cylinder Assembly - TUV (Machines Built October 1992 to Present) (See CYLINDER SECTION for Breakdown) 130 3421491 1 Pin, Attach (Lower) 131 3421494 1 Pin, Attach (Upper) 132 3532054 1 Plate, Retainer 133 0641506 2 Bolt 5/16in-18NC x 3/4in 134 4060804 10 in/2.6cm Shield, Hose (Flexguard) 135 4070707 AR Shim 1/32in 136 3520035 1 Plug 137 0641816 2 Bolt 1/2in-13NC x 2in 138 4761800 2 Lockwasher 1/2in 139 3311505 2 Locknut 5/16in-18NC 140 2160001 1 Fitting, Grease 141 4340596 1 Support, Hose (Hydraulic Controls Only) 141 4300031 2 Stud (Welded on Part) 141 4751400 2 Flatwasher 1/4in 141 3311405 2 Locknut 1/4in-20NC 0235238 Ref ROTATOR ASSEMBLY E
Ref Note: For Machines Built Prior to September 1991 refer to
Service Information Bulletin #91-5 for required upgrade.
201 3160083 1 Rotator Motor Assembly (See CONSOLE BOX ASSEMBLY (STANDARD BANG-BANG CONTROLS) for Breakdown) 202 0080099 1 Adapter, Motor 203 2760064 1 Housing, Gear 204 0440134 2 Bearing, Sleeve 205 4740199 4 Washer, Thrust 206 0440120 2 Bearing, Thrust 207 2440043 1 Gear, Worm 208 3440816 4 Rollpin 1/4in x 1in
REV
ITEM PART NUMBER QTY
DESCRIPTION
209 0080098 1 Adapter, Motor to Worm Gear 210 2440044 1 Gear, Worm 211 4740256 2 Washer, Thrust 212 0440135 1 Bearing, Sleeve 213 1760068 1 Disc, Brake 215 3931010 5 Bolt, Socket Head #10-24NC x 5/8in 216 3441228 2 Rollpin 3/8in x 1 3/4in 217 3931620 2 Bolt, Socket Head 3/8in-16NC x 1 1/4in 218 4761600 6 Lockwasher 3/8in 219 3931612 4 Bolt, Socket Head 3/8in-16NC x 3/4in 220 4070585 AR Shim .010 221 4070586 AR Shim .005 222 4070587 AR Shim .002 223 0100019 AR Loctite #271 (Not Shown) 224 0100021 AR Primer (Not Shown) 225 2160001 1 Fitting, Grease - 90 226 3020025 AR Grease (Not Shown) Ref PLATFORM WELDMENTS Ref Note: Replacement Decals Must be Ordered Separately - See
DECALS SECTION.
301
Ref Standard Platform Options: 301 Ref 30in x 48in Platforms: 301 3510176 1 Platform for Machines Built Prior to October 1990 (Use 3510236) 301 3510236 1 Platform for Machines Built October 1990 to Present 301 Ref 30in x 60in Platforms: 301 3510170 1 Platform for Machines with Standard Bang-Bang and Proportional Controls Built Prior to October 1990 (USe 3510237) 301 3510237 1 Platform for Machines with Standard Bang-Bang and Proportional Controls Built October 1990 to Present 301 3510406 1 Platform with Slide Bar Gate 301 3510483 1 Platform for Machines with Standard Bang-Bang and Proportional Controls with Mesh from Bottom to Top Rail 301 3510247 1 Platform for Machines with Hydraulic Controls 301 3510307 1 Platform for Machines with Hydraulic Controls with Mesh to Mid-Rail Built April 1991 to Present 301 3510481 1 Platform for Machines with Hydraulic Controls with Mesh from Bottom Rail to Midrail Built April 1991 to Present 301 3510386 1 Platform for Ford Spec Machines with Hydraulic Controls 301 Ref 30in x 72in Platforms: 301 3510177 1 Platform for Machines with Standard Bang-Bang and Proportional Controls Built Prior to October 1990 (Use 3510238) 301 3510238 1 Platform for Machines with Standard Bang-Bang and Proportional Controls Built October 1990 to Present 301 3510656 1 Platform for Machines with Standard Bang-Bang and Proportional Controls with Mesh from Bottom to Top Rail 301 3510356 1 Platform for Machines with Hydraulic Controls 301 Ref 30in x 96in Platforms: 301 3510253 1 Platform for Machines with Standard Bang-Bang and Proportional Controls 301 Ref Standard Platform Components 302 2600143 2 Pin, Hinge
REV
ITEM PART NUMBER QTY DESCRIPTION
303 3311805 2 Locknut 1/2in-13NC 304 2160006 2 Fitting, Grease 305 1780224 Door Weldment (Machines Built Prior to October 1990) 305 1780250 Door Weldment (Machines October 1990 to Present) 306 2940006 1 Latch, Door 307 2560010 1 Handle 0237963 Ref FOOTSWITCH INSTALLATION 401 0641408 3 Bolt 1/4in-20NC x 1in 401 3311405 3 Locknut 1/4in-20NC 401 4740362 3 Washer, Fender 401 4360031 1 Footswitch 401 7000625 2 Block, Contact 401 4460071 1 Connector, Strain Relief
REV
7
