FIGURE 2-26. TANKS INSTALLATION

FIGURE 2-26. TANKS INSTALLATION

FIGURE 2-26. TANKS INSTALLATION

ITEM PART NUMBER QTY DESCRIPTION REV

Ref TANKS INSTALLATION 0239417 Ref FUEL AND HYDRAULIC TANKS INSTALLATION (STANDARD) C 0250231 Ref FUEL AND HYDRAULIC TANKS INSTALLATION (WITH

HEATERS)

B 0253822 Ref HYDRAULIC TANK INSTALLATION (LP ONLY MACHINES) 1 3311501 4 Nut 5/16in-18NC 2 4761500 4 Lockwasher 5/16in 3 4751500 4 Flatwasher 5/16in 3 4300073 4 Stud (Welded on Part) 4 4070410 AR Shim (1/16in) 4 4070411 AR Shim (1/8in) 4 4070412 AR Shim (3/16in) 4400264 1 Fuel Tank Assembly 2 5 4400263 1 Fuel Tank Weldment 6 1120314 1 Cap 7 2180467 2 Fitting, 90 7 0100020 AR Sealant 8 1320022 2 Clamp 9 4562516 26 in Tube, Sight 10 2200222 1 Plug, Pipe - 1/4in 11 3311501 4 Nut 5/16in-18NC 12 4761500 4 Lockwasher 5/16in 13 4751500 4 Flatwasher 5/16in 13 0641516 4 Bolt 5/16in-18NC x 2in 14 4070410 AR Shim (1/16in) 14 4070411 AR Shim (1/8in) 14 4070412 AR Shim (3/16in) 4400266 1 Hydraulic Tank Assembly (Standard) C 4400291 1 Hydraulic Tank Assembly (With Heater) B 15 4400265 1 Hydraulic Tank Weldment (Standard) 15 4400290 1 Hydraulic Tank Weldment (With Heater) 16 1670468 1 Lid 17 3311401 14 Nut 1/4in-20NC 18 4761400 14 Lockwasher 1/4in A 19 4751400 14 Flatwasher 1/4in 20 3960371 1 Gasket 21 2120103 1 Filter, Return (Includes Item 26) 21 7004244 1 Gauge, Sight 21 7012559 1 Gasket (Located Between Filter and Tank) 21 7016333 1 O-Ring (Located Under Cap) 22 0641612 4 Bolt 3/8in-16NC x 1 1/2in 23 4761600 4 Lockwasher 3/8in 24 4740322 4 Washer, Sealing 25 3311601 4 Nut 3/8in-16NC 26 2120107 1 Element (Part of Item 26) 27 1340045 1 Filler, Strainer 27 4740338 6 Washer, Sealing 28 2180467 2 Fitting, 90 28 0100020 AR Sealant 29 1320022 2 Clamp

ITEM PART NUMBER QTY DESCRIPTION REV

30 4562516 26 in Tube, Sight 31 2120104 1 Filter, Suction 31 0100020 AR Sealant 32 3520022 1 Plug - 3/4in 32 0100020 AR Sealant 33 2180527 1 Plug - 1/16in 33 0100020 AR Sealant 34 2200268 1 Fitting, Coupling 34 0100020 AR Sealant 35 2180711 1 Pipe, Return 36 1600043 1 Controller, Thermostat (With Heater Only) 37 2580018 1 Heater, Immersion (With Heater Only) 38 1340046 1 Breather 39 4060695 1 Filler/Shield (Standard) 39 4060849 1 Filler/Shield (LPG Only) 40 0721005 6 Screw, Machine #10-24NC x 5/8in 41 4751000 12 Flatwasher #10 42 4761000 6 Lockwasher #10 43 3311001 6 Nut #10-24NC 44 3311401 6 Nut 1/4in-20NC 45 4761400 6 Lockwasher 1/4in 46 4751400 6 Flatwasher 1/4in 0252300 Ref COLD WEATHER PACKAGE INSTALLATION - FORD B 0252301 Ref COLD WEATHER PACKAGE INSTALLATION - DEUTZ B 0252302 Ref COLD WEATHER PACKAGE INSTALLATION - KUBOTA B 47 0231756 1 JUNCTION BOX ASSEMBLY C 47 1670199 1 Cover 47 4460049 3 Connector, Strain Relief 48 3311401 4 Nut 1/4in-20NC 49 4761400 4 Lockwasher 1/4in 50 3251837 1 Decal - Battery and Oil Tank Heaters 50 3251243 1 Decal - 120V/60HZ 0250149 Ref LP TANK AND BRACKETS INSTALLATION D 51 1320126 1 Bracket 51 1320127 1 Clamp, Latch 52 1320023 1 set Bracket 53 3311601 4 Nut 3/8in-16NC 54 4761600 4 Lockwasher 3/8in 55 4751600 4 Flatwasher 3/8in 56 4400164 2 Tank, LP (20 Lb) 56 4400040 2 Tank, LP (33.5 Lb) 56 4400275 2 Tank, LP (43.5 Lb) 58 4751800 6 Flatwasher 1/2in (Not Shown - Located between clamp and turntable)
