FIGURE 2-19. 110 VOLT GENERATOR INSTALLATION (FORD
ITEM PART NUMBER QTY
DESCRIPTION
0250668 Ref 110 VOLT GENERATOR INSTALLATION 1 2460011 1 Generator Assembly with Control Box 1 7012558 1 Generator Assembly 1 7026199 1 Armature with Slip Rings 1 7012513 4 Holder, Brush 1 7012514 1 Fan 1 7020108 4 Brush 1 7020109 4 Holder, Brush 1 7020110 1 Bell, Front 1 7020111 1 Bell, Rear 1 7020190 2 Bearing 1 7020193 1 Cord, Power 1 7003657 1 Control Box Assembly Ref Note: Replacement 110V Control Box comes with 2 std
Receptacles p/n 4460190. Optional Industrial Twist Lock Receptacles p/n 4460027 must be ordered separately.
1 2420203 1 Voltmeter 1 3520028 1 Plug, Hole 1 4360542 1 Breaker, Circuit 1 2920162 1 Lamp Assembly 1 7020191 1 Switch, Toggle 2 0681610 2 Bolt 3/8in-16NC x 1 1/4in (Grade 8) 3 0641507 1 Bolt 5/16in-18NC x 7/8in 4 4761600 2 Lockwasher 3/8in 5 4751600 3 Flatwasher 3/8in 6 4340569 1 Support 7 0641511 1 Bolt 5/16in-18NC x 1 3/8in 8 4761500 2 Lockwasher 5/16in 9 4751500 2 Flatwasher 5/16in 10 0961247 1 Bushing 11 Ref Mounting Bracket Options: 11 0901650 1 Bracket (Prior to May 1991) 11 0901774 1 Bracket (May 1991 to Present) 12 3311601 2 Nut 3/8in-16NC 13 4761600 2 Lockwasher 3/8in 15 3580134 1 Pulley (Attaching Hardware Supplied With Generator) 16 2860012 1 Key, Woodruff 17 0480057 1 V-Belt 19 0721006 2 Bolt #10-24NC x 3/4in 20 4751000 2 Flatwasher #10 21 4761100 2 Lockwasher #10 22 3311001 2 Nut #10-24NC 23 0901633 1 Bracket, Mounting - Box 24 3311401 2 Nut 1/4in-20NC 25 4761400 2 Lockwasher 1/4in 26 4751400 2 Flatwasher 1/4in 26 4300068 2 Stud (Welded on Part) 27 3251476 1 Decal - Generator 28 4460027 1 Connector 28 4460023 1 Terminal
REV
G
ITEM PART NUMBER QTY
29 1060012 AR Cable - 12/4
