FIGURE 2-7. VALVE ASSEMBLY - GROUND CONTROL (HYDRAULIC CONTROLS
ITEM PART NUMBER QTY
DESCRIPTION
4640506 Ref VALVE ASSEMBLY - GROUND CONTROL (HYDRUALIC
CONTROLS)
1 7000585 6 Nut 2 7000586 2 Washer 3 7006052 3 Rod, Threaded 4 7006039 2 Bracket 5 7006040 1 Section, Valve - Inlet 5 7000588 1 O-Ring 5 7006050 2 O-Ring 6 7006046 4 Section, Valve - Lift, Articulate, Tele and Swing 7 7000589 20 O-Ring 8 N.S.S. 4 Spool 9 7006029 4 O-Ring 10 7000588 4 O-Ring 11 7006022 8 Guide 12 7006020 4 Spring 13 7006021 4 Shaft 14 7006019 4 Cap 15 7006012 4 Handle (With Linkage and Hardware) 16 7006041 1 Section, Valve with Coils - Steer 17 7000588 5 O-Ring 18 N.S.S. 1 Spool 19 7006037 2 Retainer 20 7006036 2 Spring 21 7006049 2 Tube Assembly 22 7006048 2 O-Ring 23 7006035 2 O-Ring 24 4640049 2 Coil, Solenoid 25 Ref Nameplate 26 7006033 2 Nut 27 7000596 2 O-Ring 28 7000600 1 Section, Valve - Outlet 29 7000588 5 O-Ring 30 7006053 1 Valve, Cartridge Relief 7006051 1 Seal Kit - Complete (Includes Qty 1 of 7000550, 7000549 & 7006047 Seal Kits & Qty 4 of 7000556 Seal Kit) 7000550 1 Seal Kit - Inlet Section (Includes O-Rings Listed in Item 5) 7000556 Seal Kit - Manual Valve Section (Includes Qty 5 of Item 7, 4 Qty 1 of Item 9 & Qty 1 of Item 10) 7000549 1 Seal Kit - Valve Section with Coils (Includes Qty 10 of Item 17, Qty 2 of Items 22, 23 & 27) 7006047 1 Seal Kit - Outlet Section (Includes Qty 5 of item 29)
