IV. INSPECTION AND MAINTAINANCE OF MAJOR PARTS
IV. INSPECTION AND MAINTAINANCE OF MAJOR PARTS 1. INSPECTION OF CYLINDER
(1) lock nut (2) adjust adapter a. Cylinder of collector(SBC550X-L) can be adjusted its length. b. Adjust the lengh of cylinder so that its length is the shortest with collector located lowest position.
Caution: ･ Container would be damaged by making length of cylinder too longer. Be careful to adjust its length. 2. INSPECTION OF HYDRAULIC HOSES a. When operating the collector, be sure to confirm that hydraulic hose is not pulled and interfered. b. When the hydraulic hose is damaged, exchange it as soon as possible.
Danger: It is danger to operate the lawn mower with damaged hydraulic hose. It may cause that collector falls or hydraulic hose burst suddenly.
83
