III. COLLECTOR OPERATION
III. COLLECTOR OPERATION 1. BEFORE OPERATION
3. Inspection before operation ･ Before operating, inspect the points that follow.
Caution: ･ Become familiar with how to operate the lawn mower and understand safety instructions by reading this manual carefully. ･ Make sure that all safety covers and guards are installed in position. ･ Before operating the collector, be sure to confirm that collector move up and down smoothly. ･ When operating the collector, be sure to confirm that hydraulic hose is not pulled and interfered.
(1) safety switch
2. Adjusting the grass limit sensor
a. Be sure to confirm that the engine stops as soon as operator start the mower deck with lifted container (SBC550X-H) or dumpped container(SBC550X-L).
Danger: Safety switch prevents the blades from starting with lifted container (SBC550X-H) or dumpped container(SBC550X-L) to keep operator's safety. Be sure to check that the safety system is normal.
(1) adjuster bolt (2) adjustment position label a. Filler rate of container is changed with adjusting the adjuster bolt(1). b. Check the buzzer of grass limit sensor. Set the starter switch ON position (Don't start engine) and set the PTO lever on. Check that buzzer sounds by pushing the sensor plate(3).
(1) dump lever (2) rod
Caution: After checking the buzzer, be sure to turn starter switch and PTO lever off.
(3) container
b. Collector (SBC550X-H) has a control of dump lever. Be sure to check that dump lever wouldn't be moved backward with container located at the lowest position. Important: Be sure to confirm that the control of dump lever(SBC550X-H) is normal. 81
