SXG
VII. OPERATION 1. BEFORE STARTING THE ENGINE
Caution: ･ Before starting the engine, be sure to carry out the pre-operation inspection in accordance with the periodical inspection table on page 49. ･ Follow instructions given in "I. FOR SAFFETY OPERATION." ･ Observe instructions given on the caution labels on the lawn mower and mower deck. 2. STARTING THE ENGINE
Monitor array (1) Overheat warning
(2) Oil pressure lamp (3) Charge lamp
f. Turn the throttle lever to the high speed position (
).
Warning: ･ Never attempt to start the engine in an enclosed place with poor ventilation. Be sure to provide sufficient ventilation, for exhaust fumes can be lethal. Important: Before starting the engine, sit down in the operator's seat properly, depress the brake pedal, and shift the PTO lever to the OFF position ( ), or the engine cannot be started. (1) Throttle lever
(A) High speed
(B) Low speed
g. Turn the key to the pre-heating position (G) and hold it there about five to ten seconds. Important: Never keep on pre-heating more than 10 seconds, or the glow plugs may burn out. When the engine fails to start, wait at least 20 seconds before the next attempt. (1) Operator's seat (2) PTO lever
(3) Brake pedal
a. Sit in the operator's seat properly. b. Apply the parking brakes securely (UGE) c. Shift the PTO lever to the OFF position ( ). d. Depress the brake pedal fully. e. Insert the starter key into the starter switch and turn the key to the ON position ( ). Make sure that the charge lamp and oil pressure lamp are both lit.
30
