SCMA40
II. ATTACHING AND DETACHING MOWER DECK ■ INSTALLATION OF MOWER DECK
WARNING: When attaching or detaching the mower deck to the machine: • Place the machine on level, hard ground. • Apply the parking brake securely. • Shift the PTO lever to the STOP ( ) position.
a. • Remove the joint cover, (12). The lift lever (1) to raise the mower link in the highest position. • Set the height adjust dial, (9) to the most lowest position.
1. ATTACHING THE MOWER DECK
b. Set the gauge wheels (3) of the mower deck in the lowest position (Refer to page 70).
Attach the mower deck first to the machine and then connect the drive shaft.
c. Before installing the mower deck, set the rear gauge wheels (3) sideways.
(1) Lift lever (2) Mower discharge cover (3) Gauge wheel
(4) Rear link (5) Front link (6) Lock nut
(7) Ring clip (8) Front wheel (9) Height adjust dial
68
(10) Chute (11) Drive shaft (12) Joint cover (13) Joint cover/mower
