OPERATION One-Touch Joystick screen
Joystick direction control
CAUTION! Practice operating the One-Touch joystick in an open area prior to first use in a congested area. Failure to do so could result in collision with other vessels or obstacles and could cause injury or damage to equipment.
Operate One-Touch Joystick 1. To advance the vessel, push forward on the joystick. An arrow appears on the vessel graphic indicating direction of travel. The arrow length extends when throttle is applied to the vessel, and speed is indicated in the top left corner of the display. 2. Tilt or twist joystick in desired direction to move vessel. •
Tilt joystick to move vessel sideways, forward diagonally, and reverse.
•
Twist the top of the joystick to rotate the vessel clockwise and counterclockwise.
•
Adjust movement speed by increasing pressure on the joystick.
