OPERATION
Main Menu
CAUTION! The operator accepts all liabilities associated with automatic drive trim control. Ensure vessel is at proper water depth before engaging Planing Assist. Failure to do so could result in accidents that could cause injury or damage to equipment.
Press the Ilmor Logo (Home) button to go to the main menu. It displays the following functions: • • • • •
PROPULSION JOYSTICK ANCHOR FUEL UTILITIES
Utilities page
JOYSTICK Press JOYSTICK to open the One-Touch joystick screen. Press Home button to return to main menu. Main menu
• Disable or enable PLANING ASSIST, if equipped. 1. Press any trim indicator on the One-Touch joystick screen to start Planing Assist.
ANCHOR Press ANCHOR to open the ANCHOR ASSIST screen. Press Home button to return to main menu. UTILITIES Press UTILITIES/OWNER SETUP button to adjust the following:
2. Press either drive trim button on the twin engine throttle control panel (see Twin Engine Throttle Control section in the Operation chapter) to override Planing Assist. During Planing Assist, drives will trim down under acceleration and trim up once vessel comes on plane. Trim will adjust while on plane to achieve best fuel economy. Drives may trim down when better handling is required. • • • •
Turn JOYSTICK PAGE POPUP on or off. Use BRIGHTNESS to adjust screen illumination. Use TIMEZONE OFFSET to adjust Merlin Display Time. Press Home Button to return the Main Menu.
