Display assembly Description
Spare part number
14.1-inch, WXGA AntiGlare display assembly for use only with computer models with wireless LAN capability (includes wireless antenna transceivers and cables)
438550-001
14.1-inch, WXGA AntiGlare display assembly for use only with computer models without wireless LAN capability
438549-001
14.0-inch, WXGA AntiGlare display assembly for use only with computer models with wireless LAN capability (includes wireless antenna transceivers and cables)
438548-001
14.0-inch, WXGA AntiGlare display assembly for use only with computer models without wireless LAN capability
438547-001
Before removing the display assembly, follow these steps: 1.
Shut down the computer. If you are unsure whether the computer is off or in hibernation, turn the computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power cord.
4.
Remove the battery (see Battery on page 28).
5.
Remove the memory/Mini PCI card module compartment cover (see Memory module on page 31) and disconnect the wireless antenna cables from the Mini PCI card module (see Mini PCI card module on page 33).
6.
Remove the following components: a.
Switch cover (see Switch cover on page 37)
b.
Keyboard (see Keyboard on page 39)
Remove the display assembly:
ENWW
1.
Close the computer and turn it upside down with the rear panel toward you.
2.
Remove the two Phillips PM2.0×7.0 screws that secure the display assembly to the computer.
