Two-stage swing-away lattice extension 3.1 Operating and display elements
3.1.2
Operating elements on two-stage swing-away lattice extension
Switch unit
1
Raise lattice extension push-button
2
Lower lattice extension push-button
à p. 3 - 75 à p. 3 - 75
Functional description Raise lattice extension push-button (additional equipment) To raise the lattice extension when rigging. The lattice extension is raised when the push-button is pressed or until the end position or a switch-off point is reached.
Lower lattice extension push-button (additional equipment)
04.08.2004
To lower the boom the lattice extension when rigging. The lattice extension is lowered when the push-button is pressed or until the end position or a switch-off point is reached.
Operating instructions lattice extension GMK 5200/6220-L
2 084 906 en
3-3
