Description of maintenance work on the carrier 7.11 Carrier hydraulic system
Hydraulic oil filter for control circuit The hydraulic oil filter control circuit (1) is located on the right side of the superstructure, behind the covering.
• Switch off the diesel engine and secure it against being started by unauthorized persons (sign in the driver’s cab).
• Remove the ring (1). • Take off the filter can (2). • Remove the filter from the filter can. • Insert the new filter into the filter can. • Fill the filter can up to the edge with hydraulic oil.
• Screw the filter can on again. • Start the diesel engine and let it run in
14.01.2002
neutral gear for 3 minutes in order to bleed the system.
