OPERATING CONTROLS AND PROCEDURES
37
TMS700E OPERATORS MANUAL
38
40
39
41
FIGURE 3-3 continued Item
45
44
46
FIGURE 3-3 continued
3-14
Description
25
Engine Stop Indicator
26
Front Stabilizer Overloaded Indicator
27
Tachometer
28
Hourmeter
29
Gauge Cluster (Fuel, Temperature, Oil, Volts)
30
LMI Panel
31
Hand Throttle Switch
32
Ignition Switch
33
Air Conditioning Control Switch (Optional)
34
Heat Control Knob
35
12 VDC Accessory Outlet
36
Fan Switch
37
Crane Function Power Switch
38
Windshield Wiper/Washer Switch
39
Panel Light Control Dimmer
40
Work Lights Switch
41
Boom Lights Switch (Optional)
42
Positive Swing Lock Release Lever
43
Positive Swing Lock Foot Pedal
44
Outrigger Extension/Retraction Switch
45
Center Front Stabilizer Control Switch
46
Outrigger Selector Switches
47
Wait to Start Indicator
48
Engine Warning Indicator
49
Regen Exhaust Filter Indicator
Published 10-05-2010, CTRL # 102-06
