Page 48

OPERATING CONTROLS AND PROCEDURES Item

Description

TMS700E OPERATORS MANUAL Item

Description

1

Dual Air Pressure Gauge

38

Throttle Pedal

2

Tachometer

39

Transmission Range Control Switch

3

Left Turn Signal Indicator

40

Transmission Shift Lever

4

Speedometer

41

Not Used

5

Gauge Cluster (Fuel, Temperature, Oil, Volts)

42

Not Used

6

Right Turn Signal Indicator

43

Fire Extinguisher

7

Heater Air Temperature Control

44

Cab Dome Light

8

Heater Fan Switch

45

Steering Wheel

9

12 Volt Accessory Outlet

46

Horn Button

10

Not Used

47

Headlight Dimmer/Turn Signal Lever

11

Trailing Boom Trailer Emergency Brake Control

48

Windshield Wiper

12

Parking Brake Control

49

Not Used

13

Windshield Wiper/Washer Switch

50

Cab Circulating Fan

14

Ignition Switch

51

Not Used

15

Inter-Axle Differential Lock Control

52

Clutch Pedal

16

Not Used

53

Not Used

17

Cross-Axle Differential Lock Control

54

Circuit Breaker and Relay Panel

18

Tire Inflator Control Switch

55

Hazard Light Switch

19

Beacon Light Switch

56

Steering Column Tilt/Telescope Lever

20

Engine Brake High/Low Switch

57

Hydraulic Pump Engaged Indicator

21

Headlights Switch

58

Hydraulic Pump Switch

22

Engine Brake On/Off Switch

59

Transmission Deep Reduction Switch

23

Engine Stop Indicator

60

Seat Adjustment Lever

24

Engine Warning Indicator

61

Seat Tilt Lever

25

Regen Exhaust Filter Indicator

62

Not Used

26

Cross-Axle Differential Locked Indicator

63

High Exhaust Temp Light

27

Air Pressure Low Indicator

28

High Beam Indicator

Craning Controls and Indicators

29

Park Brake On Indicator

30

Swing Brake On Indicator

31

Tire Inflator On Indicator

32

Inter-Axle Differential Locked Indicator

33

Suspension Deflated Indicator

34

Suspension Control

The SWING BRAKE ON indicator (30) is located at the top of the front console. The red indicator lights to warn the operator that the swing brake release pressure is not enough to hold the swing brake disengaged during trailing boom operation. In addition to illuminating the SWING BRAKE ON indicator, the pressure switch also energizes a warning buzzer.

35

Engine Diagnostics Idle Switch

Hydraulic Pump Engaged Indicator

36

Engine Diagnostics Test/Regeneration Switch

37

Brake Pedal

The PUMP ENGAGED indicator (57) is located on the right side console. The amber indicator lights when the hydraulic pumps are engaged.

3-6

Swing Brake On Indicator (Optional)

Published 10-05-2010, CTRL # 102-06
