Swing-away lattice 3.4 Description of rigging work
Transport condition with folded swing-away lattice
The transport condition is established when all of the following connections have been made.
Check the connections and establish them if necessary. If section 1 and section 2 are folded: – In the Front area, section 1 must be engaged at the slewing axis (5) on the main boom and the slewing axis must be secured with the pin (6); Establishing a connection, p. 3 - 50.
à
– In the Middle area, the connection (4) is in the position Section 1/ p. 3 - 54. Section 2;
à
– In the rear area, the connection (2) between section 2 and the main boom is established; p. 3 - 56.
à
– In the Rear area, the connection (3) between section 1 and section 2 is p. 3 - 60. established; The unneeded pin (1) is secured in the retaining sheet.
à
05.11.2008
– The pins (7) on section 1 are secured with retaining pins.
3 - 42
3 112 568 en
Lattice extension operating instructions GMK 5170
