Swing-away lattice 3.3 Checklists for rigging work
18. Install the anemometer and if necessary establish an electrical connection for the air traffic control light; Installing/removing the anemometer, p. 3 - 83, Air traffic control light – electrical connection, p. 3 - 85.
à à
19. Install the lifting limit switch; switch, p. 3 - 80.
à Installing/removing the lifting limit
20. In the case of the inclinable swing-away lattice, adjust the angle, if necessary; Setting the angle – with the auxiliary crane, p. 3 - 91. Setting the angle – without the auxiliary crane, p. 3 - 92.
à à
21. Reeve the hoist rope on the hook block; the swing-away lattice, p. 3 - 79.
à Possible reeving methods on
22. Attach the lifting limit switch weight and place it around the hoist rope; Operating instructions GMK 5170, section 2 Superstructure – Rigging work.
à
05.11.2008
23. Check the horizontal alignment of the truck crane and correct, if necessary.
3 - 18
3 112 568 en
Lattice extension operating instructions GMK 5170
