For operations planning 2.1 Notes
2
For operations planning
2.1
Notes The following section contains information on the following subjects: – Assembly – Identification – Transport dimensions and weights – Slinging points – Transport
Assembly
The length dimensions correspond to the respective distances between the centre of the locking pin (on the main boom head) and the front edge of the head sheave. Therefore, the length dimensions of the individual parts from Transport dimensions and weights and their sum do not agree with the lengths specified there.
Identification
S Transport dimensions and weights
Risk of accidents if not adjusted properly The lattice extension is designed for the truck crane with which it was delivered. If a lattice extension is to be used on several truck cranes, it must be adjusted to the truck crane and marked with the serial number. Have the lattice extensions only adjusted by CraneCARE. You can prevent malfunctions and damage in this way.
Observe the weight specifications and the dimensions of the lattice extensions in the respective sections. The dimensions specified here and their sums do not correspond to the specifications in the section titled Assembly.
05.11.2008
s
Lattice extension operating instructions GMK 5170
3 112 568 en
2-1
