Form No.

RS6-34

50960084 Revision A

September 2014

Telescopic Handler

Parts Manual

Equipped with Final TIER IV Engine For machines with SN 22451 and up

http://www.minnpartelehandlerparts.com/

Introduction

RS6-34 Telescopic Handler

When ordering service parts, specify the correct part number, full description, quantity required, the machine model number, and serial number. For your safety, and continued proper operation, use only genuine Manitou service parts.

The following icons shown on various pages provide important information or identify where additional information can be found.

“Right” and “left” are determined from a position sitting on the seat inside the cab and facing forward.

Gehl Company reserves the right to make changes or improvements in the design or construction of any part of the machine without incurring the obligation to install such changes on previously delivered machines.

NOTE: This parts manual identifies both standard and optional features for this model. Depending on the features of your machine, some of the items identified in the parts lists may, or may not, be included with your machine.

Tilt Cylinder parts are on page 247.

Identifies where additional pages for component parts, seals, and kits can be found.

Refer to page 126 for the warning decal.

Interior Cab Options are on page 18.

Identifies where additional information can be found.

Alerts and directs user to investigate more information.

SERIAL NUMBER NOTE: Hydraulic bulkhead fitting.

Warning or Important Information

Important information to follow

Identifies missing, hidden parts, or adds informational comments.

Seal Kit

Model

RS6-34

Engine

Unit Number

D F 00 00000

Year (F=14, G=15, etc.)

Month

Serial number breaks are indicated as follows: • (SN 999 and before) - indicates serial numbers up to and including 999.

• (SN 1000 - 2000) - indicates serial numbers from 1000 to 2000.

• (SN 999 and up) - indicates serial numbers including 999 and after.

NOTE: When ordering parts, be sure to identify the last five digits of the machine's serial number (Unit Number).

HYDRAULIC AND ELECTRICAL SCHEMATICS

Hydraulic and electrical schematics can be found in the Operator’s and Service Manuals for this machine; please refer to the information at the right for the correct manual.

A1

Repair Kit

Represents a port designation on hydraulic components (e.g., valves, cylinders, etc.)

SOME ABBREVIATIONS LISTED IN THIS MANUAL ASSY Assembly AR As Required CFPD Contact Factory Parts Department EU European Union (standards) HYD Hydraulic IN Inch(es) INC/INCL Included or includes LN Lock Nut MM/mm Millimeter NA Not Applicable or Not Available NPT National Pipe Thread NSS Not Sold Separately ORB O-Ring Boss REF Reference SN Serial Number W/ With W/O Without

MANUALS Operator's Manual: P/N 50960083 Engine Parts Manual: P/N 50960088

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Table of Contents

Page INTRODUCTION Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Filters and Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 CAB Cab and Covers (Standard) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Cab Mounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Front Work Lights and Strobe Light (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 Glass - Front and Rear Window Group (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 Wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Glass - Top and Left Window (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 Instruments, Switches and Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 Fuses, Relays, and Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 Steering Column and Shifter Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Steer Motor and Steer Select Valve Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 Brake and Accelerator Pedals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 Brake Valve Hydraulic Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 Cab Components - Tri-Function Controls (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 Heater (Option) - (No A/C) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34 A/C - Heater - (A/C - Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36 A/C Circuit (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38 Heater Circuit (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 A/C Condenser - (A/C Equipped - Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42 CHASSIS Hoods - Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44 Hoods - Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46 Hoods and Covers - Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48 Hydraulic Tank Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50 Fuel Tank Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52 Battery Group and ECU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54 Frame Level Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56 PERSONNEL WORK PLATFORM Boom Components - (Standard PWP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58 Level Sensor, Module, Chains, and Manifold (for Standard and Radio Remote) . . . . . . . . . . . . . . . . . . . .59 PWP Radio Remote (Option) - Transmitter and Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60 ENGINE External Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62 A/C Compressor Group - (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64 Fuel Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66 Radiator and Cooler Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68 Radiator and Cooler Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70 Air Intake Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72 Exhaust Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74

PRINTED IN U.S.A.

1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Table of Contents

RS6-34 Telescopic Handler

Page TRANSMISSION External Components (including driveshafts) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76 Drive (Flex) Plate Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78 Converter Housing Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79 Case and Plate Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80 Torque Converter Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82 Gear Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84 Drive Pump Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86 Charge Pump Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87 Output Shaft Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88 Reverse Idler Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89 Forward and Reverse Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90 Third Shaft Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92 First and Second Shaft Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94 Modulation Valve Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96 Control Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97 AXLE External Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98 Brake and Steering Circuit - Front Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100 Brake and Steering Circuit - Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102 Front Axle - Steer Cylinder and Tie Rods Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104 Rear Axle - Steer Cylinder and Tie Rods Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105 Front Axle - Differential Housing Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106 Rear Axle - Differential Housing Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107 Front Axle - Brake Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108 Rear Axle - Brake Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109 Front Axle - Outer End Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110 Front Axle - Differential Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112 Rear Axle - Outer End Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114 Rear Axle - Differential Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116 BOOM Outer Boom Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118 Intermediate Boom Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120 Inner Boom Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122 Dynattach Bracket Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124 BOOM HYDRAULICS Lift Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126 Tilt / Slave Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128 Boom Extend Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130 Auxiliary Hydraulics Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132 HYDRAULIC SYSTEMS Hydraulic Pump Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134 Hydraulic Control Valve and Hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .136 Dual Controls Circuit (Standard) Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138 Tri-Function Control (Option) - Standard Hydraulics Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .140 Tri-Function Control (Option) and Auxiliary Hydraulics Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142

50960084/AP0914

2

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Table of Contents Page

Radio Remote (Option) Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .144 Dual Controls - Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .146 Dual Controls with only Auxiliary Hydraulics (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148 Dual Controls with only PWP (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150 Dual Controls with PWP and Auxiliary Hydraulics (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152 Dual Controls with Radio Remote (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .154 Dual Controls with Radio Remote and Auxiliary Hydraulics (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . .156 Tri-Function Control (Option) with only PWP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .158 Tri-Function Control (Option) with PWP and Auxiliary Hydraulics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .160 Tri-Function Control (Option) with Radio Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .162 Tri-Function Control (Option) with Radio Remote and Auxiliary Hydraulics . . . . . . . . . . . . . . . . . . . . . . .164 HYDRAULIC COMPONENTS Hydraulic Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .166 Joystick Relief - Flow Divider . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167 Hydraulic Control Valve (including auxiliary hydraulics work section) . . . . . . . . . . . . . . . . . . . . . . . . . . .168 PWP Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170 Steer Select Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .171 Steer Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .172 Brake Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173 Pilot Apply Manifold - Tri-Function Controller (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174 Radio Remote (Option) Manifold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175 Controller - Tilt/Frame Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .176 Controller - Lift/Extend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178 Controller - Tri-Function (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .180 Controller - Auxiliary Hydraulics (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .182 Frame Level Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .184 Lift Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .186 Slave Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .188 Tilt Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190 Boom-Extend Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .192 Fork-Shift Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .194 Rotating-Carriage Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195 ATTACHMENTS Carriage Forks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .196 Standard Carriage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .198 Fork-Shift Carriage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200 Rotating Carriage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .202 Truss Booms and Bucket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .204 DECALS General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .208 New Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .208 Decal Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .209 INDEXES Numeric Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .212 Subject Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .220

PRINTED IN U.S.A.

3

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Maintenance

RS6-34 Telescopic Handler

Filters and Belts

5

2 1

Engine Oil

4 3

7

6

Secondary Fuel

Secondary Air

Primary Air

Fuel/Water Separator 8

Cab Air (Heater or A/C Option)

9

Transmission

10

11

13 12

Engine Belt

Hydraulic

Strainer (In Hydraulic Tank)

A/C Compressor Belt (A/C Option)

50960084/AP0914

4

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Maintenance Filters and Belts

Item No. 01 02 03 04 05 06 07 08

Part No. 132023 50303847 50220612 50220613 50302441 50352454 50352455 L99184

Description

Qty. Req.

Item No.

FILTER, ENGINE OIL . . . . . . . . . . . 1 FILTER, WATER SEPARATOR . . . . 1 WATER SENSOR (includes #4) . . . 1 SEALING RING . . . . . . . . . . . . . . . . 1 FILTER, FUEL (secondary) . . . . . . . 1 FILTER, ENGINE AIR (main). . . . . . 1 FILTER, ENGINE AIR (secondary) . 1 FILTER, TRANSMISSION . . . . . . . . 1

Part No.

09

211146

10 11

L97489 L49327

12 13

50220511 271491

Description

Qty. Req.

FILTER, RECIRCULATING . . . . . . . 1 (cab air; located in HVAC unit) FILTER, HYDRAULIC OIL. . . . . . . . 1 STRAINER, OIL SUCTION . . . . . . . 1 (located in hydraulic tank) BELT, ENGINE. . . . . . . . . . . . . . . . . 1 BELT, A/C COMPRESSOR (option) 1

Analysis Kits* Qty. 272806. . . . . . . . HYDRAULIC OIL ANALYSIS KITS (10) 272809 . . . . . . . . . . . ENGINE OIL ANALYSIS KITS (10) 272811 . . . . . . . . . . . . . BASIC FUEL ANALYSIS KIT (1) 272812 . . . . . . . . . . . . . COOLANT ANALYSIS KITS (10) 272813. . . . . . . . FIELD TEST COOLANT STRIP KIT (1) 272814 . . . . . . . . . . . . . . . . . . . OIL VACUUM PUMP (1) 272815 . . . . . . . . . . . . . COOLANT VACUUM PUMP (1) 272816 . . . . . 1/4” PLASTIC TUBING (100-FOOT ROLL) * For the analysis of fluids and lubricants used in this machine. Contact your dealer for more information.

PRINTED IN U.S.A.

5

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Cab and Covers (Standard) INSTRUMENT PANEL AND LOAD CHARTS

7

8

13

9 Instrument Panel and switches are on page 18.

Load Charts are listed on page 210.

18 14

UPPER SUPPORT

6

15 5

11

10

2

17

16

12 37

1 34

4

3

4 LEFT MIRROR

(OPTIONAL)

33 33 21 32

31 21 19

30 20 6

LOWER SUPPORT

21 14 29 21

15

22

35 28

17 16

23

36

18

27 24 SKID PLATE

25

25 26

26

50960084/AP0914

6

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab Cab and Covers (Standard)

Item No. 01 02 03 04 05 06 07 08a 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24

Part No. 50380734 L69297 L66011 L50417 651640 L50051 102692 105636 L50202 L63634 L69402 L63887 103022 103021 103675 L500057 102880 L50051 L500022 L500020 L500021 L52024 103023 103024 L50202 L50139 102881 067847

PRINTED IN U.S.A.

Description

Qty. Req.

Item No. 25 26 27 28 29 30 31b 32b 33 34

CAB (frame only) . . . . . . . . . . . . . . . 1 PLATE, INCLMT MOUNT . . . . . . . . 1 INDICATOR/FRAME LEVEL . . . . . . 1 #8-32X1” SCREW . . . . . . . . . . . . . . 2 5/16”-18X3/4” BUTT. HD BOLT . . . . 2 1/4”-20 WHIZ LOCK NUT. . . . . . . AR COVER, FUSE PANEL . . . . . . . . . . 1 PANEL, DASH . . . . . . . . . . . . . . . . . 1 BHSCS 1/4"x5/8" (not shown) . . . . . 6 LOAD CHART PLATE (metal) . . . . . 2 LOAD CHART PLATE (plastic). . . AR 1/4”-20 U-BOLT . . . . . . . . . . . . . . . . 1 BULB SEAL, RIGHT WINDOW . . . . 1 GLASS, RIGHT HAND . . . . . . . . . . 1 SCREEN (option - not shown) CLIP, WINDOW . . . . . . . . . . . . . . . . 2 MOUNT, REAR GLASS UPPER . . . 2 1/4”-20 WHIZ NUT. . . . . . . . . . . . . . 3 WASHER, FLAT (BLACK) . . . . . . . . 3 BUSHING, NYLON . . . . . . . . . . . . . 3 GROMMET, 1/2”ID X 1/4”GROOVE 3 1/4”-20X1” BUTT. HD BOLT . . . . . . 3 GLASS, REAR. . . . . . . . . . . . . . . . . 1 BULB SEAL, REAR WINDOW . . . . 1 1/4”-20X5/8” BUTTON HD . . . . . . AR 1/4” LOCK WASHER . . . . . . . . . . . . 2 MOUNT, REAR GLASS LOWER . . 1 HLN INST 3/8 CZY . . . . . . . . . . . . . 2

7

Part No.

Description

Qty. Req.

35 36 37

210-19470 650486 50380737 102778 102769 101550 102728 102727 L63813 219274 L50202 L50051 651640 210-19470 50302119

LN FL SERR 5/16 CZY . . . . . . . . . . 2 CS 5/16" X 3/4" C5ZY . . . . . . . . . . . 2 SKID PLATE . . . . . . . . . . . . . . . . . . 1 MASTER CYLINDER COVER. . . . . 1 COVER, HYD. CONTROLLERS . . . 1 1/4”-20 SELF THREADING BOLT. . 4 PANEL, HEATER. . . . . . . . . . . . . . . 1 PANEL, DASH COVER . . . . . . . . . . 1 HOLE PLUG, 2-1/2” DIA. . . . . . . . AR MIRROR (optional) . . . . . . . . . . . . . 1 1/4"-20x5/8" BUTT. HD. BOLT . . . AR 1/4"-20 FLANGE LOCK NUT . . . . AR BHSCS 5/16X3/4 C8 OCG . . . . . . . 2 LN FL SERR 5/16 CZY . . . . . . . . . . 2 SCREW, ST #1032x1-1/2 ZB . . . . . 4

----

L54002 L71305 104688

a

Refer to decal section (page 210) for load chart decals.

b

Used when not equipped with a heater or A/C.

-- ITEMS NOT SHOWN-TREAD STRIP, 6” WIDE (4 FT.) . . AR PLUG (top of cab) . . . . . . . . . . . . . . 2 PLUG, BLACK 5/8” . . . . . . . . . . . . AR

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Cab Mounts

4 2 7

1 2 4 3

5

6

Lockable storage shown on page 22.

7 7

2

2 4 4

Item No. 01 02 03 04 05 06

Part No. 102780 651151 102741 102781 101667 650491

50960084/AP0914

Description

Qty. Req.

1”-8X3” GR8 BOLT . . . . . . . . . . . . . 1 1” SAE FLAT WASHER . . . . . . . . . . 7 RETAINER, CANOPY NUT . . . . . . . 1 1”-8 CLASS C LOCK NUT . . . . . . . 4 WASHER, CANOPY NUT . . . . . . . 1 3/8”-16X1-1/4” BOLT . . . . . . . . . . . . 2

8

Item No.

Part No.

07

102780

--

L63813

Description

Qty. Req.

1”-8X3” GR8 BOLT . . . . . . . . . . . . . 3 -- ITEMS NOT SHOWN-HOLE PLUG, 2-1/2” DIA . . . . . . . . . 1 (plugs hole in cab where side bolt attaches)

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab

Front Work Lights and Strobe Light (Option) 5

Boom lights and harness are on page 119.

1

Strobe Light (option)

2 3 4

Rear lights are on page 48.

Front Work Lights (option)

Item No.

Part No.

01 02 03 04

L70039 654006 067847 101712

---

103192

--

Description

Qty. Req.

Item No.

HEAD LIGHT . . . . . . . . . . . . . . . . . . 2 3/8” FLAT WASHER . . . . . . . . . . . . 2 HLN INST 3/8 CZY . . . . . . . . . . . . . 2 GROMMET, 5/8” . . . . . . . . . . . . . . . 2

-- ITEMS NOT SHOWN -GROMMET 13/16”. . . . . . . . . . . . . . 2 (under dash for head light harness) L70241 WIRE HARNESS, HEAD LIGHT . . . 2 (from light switch behind dash, through cab frame posts, up to work light)

PRINTED IN U.S.A.

9

Part No.

05

104952

---

L63876

-----

104950 104951 653002 650936

Description

Qty. Req.

STROBE LIGHT . . . . . . . . . . . . . . . 1 -- ITEMS NOT SHOWN -GROMMET 9/32" ID x 3/8” OD . . . . 1 (under stobe light on top of cab) HARNESS, STROBE (upper) . . . . . 1 HARNESS, STROBE (in dash) . . . . 1 #8-32 HEX NUT . . . . . . . . . . . . . . AR #8-32x1/2" MACHINE SCREW . . AR

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Glass - Front and Rear Window Group (Option)

3 REAR WINDOW HINGE

1

2

FRONT WINDOW HINGE

7

6

1

5

5

4

8

1

2 4

6

3

12

9

11

10

13

18 14

17

14 15

16

16

16 19

20

50960084/AP0914

10

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab

Glass - Front and Rear Window Group (Option) Item No. 01 02 03 04 05 06 07 08 09 10 11 12 13 14

Part No. L500038 651639 651640 L500042 L500021 651641 L500111 L500024 103023 103024 103022 103019 101727 L500025

PRINTED IN U.S.A.

Description

Qty. Req.

5/16”-18 ACORN NUT . . . . . . . . . AR 5/16”-18X1” BUTTON HD BOLT . . . 4 5/16”-18X3/4” BUTTON HD BOLT . 8 BUSHING, STEEL . . . . . . . . . . . . . . 4 GROMMET, 1/2”IDX1/4”GROOVE . 6 5/16” FLAT WASHER (BLACK) . . . . 4 HINGE, FRONT WINDOW . . . . . . . 2 HINGE, PLASTIC (rear window) . . . 1 GLASS, REAR. . . . . . . . . . . . . . . . . 1 BULB SEAL, REAR GLASS . . . . . . 1 BULB SEAL, FRONT GLASS . . . . . 1 GLASS, FRONT . . . . . . . . . . . . . . . 1 HOLD OPEN, T-STYLE. . . . . . . . . . 1 PIN, QUICK DETACH . . . . . . . . . . . 4

11

Item No.

Part No.

Description

Qty. Req.

15a 16 17 18 19a 20a

104846 L500019 L500028 L500027 103029 102722

MOUNT, REAR WINDOW LATCH . 1 PIN, ROLL - 3/16”x1/2” . . . . . . . . . . 3 HOLD OPEN, L-STYLE. . . . . . . . . . 1 HOLD OPEN, L-STYLE. . . . . . . . . . 1 MOUNT, WIND. HOLD OPEN (RH) 1 MOUNT, WIND. HOLD OPEN (LH). 1

a ----

Use the parts 650863 654002 L50202

listed below to fasten mount to frame: 1/4” FLAT WASHER . . . . . . . . . . AR 1/4” LOCK WASHER. . . . . . . . . . AR 1/4”-20X5/8” BUTTON HD BOLT AR

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Wipers — Front and Top (with Enclosed Cab)

1

Hole not used

2

3

4

6 5

13

23 22

21

19

14

18

15

16

50960084/AP0914

20

17

12

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab

Wipers — Front and Top (with Enclosed Cab) Item No. 01 02 03 04 05 06 13 14 15 16 17 18 19

Part No. 50380577 50380576 50380682 50380579 50380583 L500706 L500700 L500696 L500718 L500001 139170 L500004 L500709 L500697

Description

Qty. Req.

WIPER BLADE, 16". . . . . . . . . . . . . 1 WIPER ARM, PANTOGRAPH . . . . . 1 Front Window Top Window PLATE, PANTO ARM MOUNT . . . . 1 PIN, PANTO ARM MOUNT . . . . . . . 1 M5, ACORN NUT . . . . . . . . . . . . . . 1 M8, ACORN NUT . . . . . . . . . . . . . . 1 COVER WIPER MOTOR. . . . . . . . . 1 BOLT / 10-24x1.25 HEX GR5 . . . . . 1 WASHER/BLK NYLON . . . . . . . . . . 1 WASHER, #10 WEATHERTITE . . . 2 NUT/ACORN #10-24 BLK . . . . . . . . 1 RAIN SHIELD . . . . . . . . . . . . . . . . . 1 M18, NUT . . . . . . . . . . . . . . . . . . . . 1

25

Item No.

Part No.

Description

Qty. Req.

20 21 22 23 24 25

L500701 L500708 L500695 L500099 101495 243063

---

-- ITEMS NOT SHOWN -(Windshield Wiper Harness) 103179 HARNESS, TOP WIPER . . . . . . . . . 1 103180 HARNESS, FRONT WIPER . . . . . . 1

---

(Windshield Washer System) 102925 HARNESS, WASHER BOTTLE . . . 1 103013 TUBING, WASHER (15-1/2’) . . . . . . 1

GASKET, PANTO ADAPTER . . . . . 1 TOWER SEAL, TRICO WIPER . . . . 1 WIPER MOTOR, TRICO . . . . . . . . . 1 ADAPTER/WET ARM . . . . . . . . . . . 1 BOTTLE, DUAL -PUMP WASHER . 1 CAP, WASHER BOTTLE . . . . . . . . 1 (included with item #24)

WASHER SYSTEM RESERVOIR LOCATED OUTSIDE CAB

-

UNDER RIGHT SIDE WINDOW

24

PRINTED IN U.S.A.

13

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Glass - Top and Left Window (Option)

1

4 2

5 6

3

7

3

10

10

8

9

50960084/AP0914

14

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab Glass - Top and Left Window (Option)

Item No.

Part No.

01a 02 03 04 05 06 07

103027 L500038 102711 L500021 L500042 651641 651639

PRINTED IN U.S.A.

Description

Qty. Req.

GLASS, TOP . . . . . . . . . . . . . . . . . . 1 5/16”-18 ACORN NUT . . . . . . . . . AR WINDOW MOUNT. . . . . . . . . . . . . . 2 GROMMET, 1/2”IDX1/4”GROOVE . 4 BUSHING, STEEL . . . . . . . . . . . . . . 4 5/16” FLAT WASHER (BLACK) . . . . 4 5/16”-18X1” BUTTON HD BOLT . . . 4

15

Item No.

Part No.

Description

08 09 10

103025 103026 102712

a

Use P/N L500607 Adhesive Kit to attach top glass to cab.

Qty. Req.

GLASS, LEFT REAR. . . . . . . . . . . . 1 BULB SEAL, LEFT GLASS . . . . . . . 1 WINDOW MOUNT. . . . . . . . . . . . . . 2

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Door (Option)

1 2 5 3 11 8 9 8

7

12 10

7 6

15 14

22

21

16 32 9

20

19

18

4

17 8

50960084/AP0914

16

7

6

5

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab Door (Option)

Item No.

Part No.

--

103014

01 02 03 04 05 06 07 08 09 10 11 12 14 15 16

102874 102705 102680 102681 651638 651641 L500042 L500021 L500038 651643 650730 102901 067847 102928 L500036

17 18

650588 NSS

19

101719

PRINTED IN U.S.A.

Description

Qty. Req.

CAB DOOR . . . . . . . . . . . . . . . . . . 1 (includes items 1-10, 12 and 15) WELDMENT, CAB DOOR FRAME . 1 BULB SEAL, DOOR FRAME . . . . . 1 GLASS, UPPER DOOR . . . . . . . . . 1 GLASS, LOWER DOOR . . . . . . . . . 1 5/16”-18X1-3/4” BUTTN HD BOLT . 5 5/16” FLAT WASHER (BLACK) . . . . 5 BUSHING, STEEL . . . . . . . . . . . . . . 8 GROMMET, 1/2”IDX1/4”GROOVE . 8 5/16”-18 ACORN NUT (BLACK) . . . 7 5/16”-18X2” BUTTON HD BOLT . . . 3 3/8”X5” BOLT. . . . . . . . . . . . . . . . . . 3 WELDMENT, DOOR HINGE . . . . . . 3 HLN INST 3/8 CZY . . . . . . . . . . . . . 3 BUMPER, DOOR . . . . . . . . . . . . . . 1 HOLD OPEN/DOOR (SET) . . . . . . . 1 (includes item #18—mounts to cab) 1/4”-20x1-1/2” BOLT . . . . . . . . . . . . 1 HOLD OPEN/DOOR STUD. . . . . . . 1 (included with item #16, as a set) GLASS MOUNT . . . . . . . . . . . . . . . 1

Item No.

Part No.

20

32

102948 101792 102886 651635 L50202 651636 L500022 L520003 L70069 101436 654028 654046 L50979 101746

--

L70069

21

22

17

Description

Qty. Req.

HANDLE, EXT. DOOR LOCKING . . 1 KEY ONLY . . . . . . . . . . . . . . . . . . . 1 LATCH RELEASE, INTERIOR . . . . 1 1/4-20X1-1/4” FLAT HD SCREW . . 2 1/4-20X5/8” BUTTON HD BOLT . . 1 M6-1X12 8.8 BOLT. . . . . . . . . . . . . 2 FLAT WASHER (BLACK) . . . . . . . . 1 1/4”-20 NYLON INSERT NUT . . . . 2 1/2” HOLE PLUG . . . . . . . . . . . . . . 2 STRIKER . . . . . . . . . . . . . . . . . . . . . 1 7/16” LOCK WASHER . . . . . . . . . . 1 7/16” FLAT WASHER . . . . . . . . . . . 1 7/16”-14 NUT . . . . . . . . . . . . . . . . . 1 COVER (included with #21) . . . . . . 1 -- ITEMS NOT SHOWN -1/2” PLUG . . . . . . . . . . . . . . . . . . . . 1 (access hole for door handle)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Instrument Panel and Dash Switches 1 3

6

5

4

2

9

8

7

11

12

10

14

13

12 VOLT POWER PORT 19

20

18

IGNITION SWITCH 16 15 17

50960084/AP0914

18

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab Instrument Panel and Dash Switches

Item No.

Part No.

01

50380306

02 03 04 05 06 07 08 09 10 11

50305161 L71075 L71086 101278 L71074 L71082 L71084 L71077 L71083 L71076

12

L71076

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

PANEL, DASH . . . . . . . . . . . . . . . . . 1 (does not include switches or display) DISPLAY, CAN & INSTRUMENTS . 1 SWITCH, STEER MODE. . . . . . . . . 1 SWITCH, CLUTCH CUT-OUT. . . . . 1 SWITCH, ENGINE FAULT. . . . . . . . 1 SWITCH, PARK BRAKE . . . . . . . . . 1 SWITCH, LIGHTS . . . . . . . . . . . . . . 1 SWITCH, TURN SIGNALS . . . . . . . 1 SWITCH, HAZARD LIGHTS . . . . . . 1 SWITCH, STROBE . . . . . . . . . . . . . 1 SWITCH, WIPER/WASHER . . . . . . 1 (front window) SWITCH, WIPER/WASHER . . . . . . 1 (top window)

Part No.

13 14

L71691 L71088

15

272578

16 17

50280186 50280187

18 19 20

50304708 137602 137603

Description

Qty. Req.

SWITCH, WORK PLATFORM. . . . . 1 HOLE PLUG, SWITCH . . . . . . . . . AR (used to plug empty switch hole) SWITCH, IGNITION w/KEY. . . . . . . 1 (includes items #16 and #17, does not include item #18) KEY (included with item #15) . . . . . 1 KEY COVER, RUBBER. . . . . . . . . . 1 (included with item #15) SPACER, KEY SWITCH . . . . . . . . . 1 CONNECTOR, 12V PWR. PORT . . 1 COVER, 12V POWER PORT . . . . . 1

NOTE: Switches shown in the Illustration or listed on this page are for reference purposes only, your machine may be configured differently than shown here.

19

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Fuses, Relays, and Modules 3

4

2 2

1 (Shift and brake modules are located inside the cab under the load chart panel on the dash.)

5

(Fuses and relays are located inside the cab under the load chart panel on the dash.)

Turn Signal Flasher

6 7 10

11

8 8 CAN-Terminate

5 9

CATHODE SIDE

14

13 15

CATHODE SIDE

103104 DIODE PACK

12

LOCATED UNDER TRANS. HOOD

(Diode wires for park brake; located on the park brake switch behind the switch panel.)

50960084/AP0914

20

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab Fuses, Relays, and Modules

22

20

24

Fuses and Relays

23

26

27

28

29

30

31

21 25

Item No. 01

Part No.

Description

Qty. Req.

Item No. 26

NSS

FUSE/RELAY BOX . . . . . . . . . . . . . 1 (included with canopy wire harness) 02 50380753 LATCH, FUSE/RELAY COVER . . . . 4 03 272648 COVER, RELAY BOX . . . . . . . . . . . 1 04 50380751 COVER, FUSE BOX . . . . . . . . . . . . 1 05 L50491 #8-32X5/8” SCREW . . . . . . . . . . . . 4 06 101877 MODULE, F-N-R SHIFTER . . . . . . . 1 07 210797 BRACKET, BRAKE MODULE . . . . . 1 08 L50538 #8-32 NUT . . . . . . . . . . . . . . . . . . . . 4 09 210614 MODULE, BRAKE WARNING. . . . . 1 10 L63894 TURN SIGNAL FLASHER . . . . . . . . 1 (Located inside joystick access cover) 11 106001 CAN, TERMINATE RECEPTACLE . 1 (Included with wire harness.)

12 103104 DIODE PACK, 4 DIODES . . . . . . . . 1 (Included with chassis wire harness.)

13 L500747 CLEAR COVER, DIODE PACK. . . . 1 DIODE WIRE (---->|--) . . . . . . . . . . 1 14a 50220757 DIODE WIRE (--|<----) . . . . . . . . . . 1 15a 105960 -----------------------------------------------------------------------------20 L70075 RELAY, 40A (ignition) . . . . . . . . . . . 1 21 L70075 RELAY, 40A (ignition) . . . . . . . . . . . 1 22 103100 RELAY, 20A (park brake). . . . . . . . . 1 23 103100 RELAY, 20A (front wiper). . . . . . . . . 1 24 103100 RELAY, 20A (lights) . . . . . . . . . . . . . 1 25 103100 RELAY, 20A (top wiper) . . . . . . . . . . 1

PRINTED IN U.S.A.

27 28 29 30 31

--a

21

Part No.

Description

Qty. Req.

103099 MINI FUSE, 15A . . . . . . . . . . . . . . . 1 (ignition, horn, brake light, clutch-cut out) 104769 MINI FUSE, 20A . . . . . . . . . . . . . . . 1 (transmission, park brake, PWP, steer-select, and backup alarm) 103099 MINI FUSE, 15A (lights) . . . . . . . . . 1 103221 MINI FUSE, 25A . . . . . . . . . . . . . . . 1 (heater and display) 103221 MINI FUSE, 25A (top wiper motor) . 1 103221 MINI FUSE, 25A (frnt wiper motor) . 1 -- WIRE HARNESS (NOT SHOWN)-50304281 WIRE HARNESS, CANOPY . . . . . . 1 (includes fuse/relay boxes with fuses and relays) 50304028 WIRE HARNESS, CHASSIS . . . . . . 1 Located under the dash; attaches to the park brake switch. Be aware there are two different diode wires (50220757 and 105960).Refer to the illustration on the facing page before ordering.

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Seat

1

2 4

5 3

3

4 6

5

4

7

8

2

9 5 8

9

22

11

9

4 5

8 9 11 8 9

3

3 4 12 6

4 5

SUSPENSION SEAT (OPTION)

14 21 19

18 19 20

20

15

17 16

50960084/AP0914

22

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab Seat

Item No. 01 02 03 04 05 06 07a 08 09 11 12a 13 14 15 16 17

Part No. 210170 L70634 650630 L50196 L50517 L70212 L70201 654004 L50056 L50823 10071 50380852 50380853 271869 50290081 651640 210-19470

Description

Qty. Req.

SEAT, OPERATOR’S (wo/armrest) . 1 SEAT BELT (includes tethers) . . . . . 1 7/16”-20X1” BOLT . . . . . . . . . . . . AR 7/16” FLAT WASHER . . . . . . . . . . AR 7/16”-20 NYLON INSERT NUT . . AR BRACKET, TETHER . . . . . . . . . . . . 2 MOUNT, SEAT BELT . . . . . . . . . . . . 1 5/16” FLAT WASHER . . . . . . . . . . AR 5/6”-18 NYLON INSERT NUT . . . AR 5/16”-18X1” BOLT . . . . . . . . . . . . AR SEAT RISER . . . . . . . . . . . . . . . . . . 1 SEAT RISER/TOOL BOX . . . . . . . . 1 DOOR/TOOL BOX. . . . . . . . . . . . . . 1 CAM LOCK (includes two keys) . . . 1 KEY (only) . . . . . . . . . . . . . . . . . . . . 1 BHSCS 5/16" x 3/4" C8 OCG . . . . . 2 LN FL SERR 5/16 CZY . . . . . . . . . . 2

Item No.

Part No.

Description

18 19 20 21 22b

650490 654006 067847 650533 L68496

23b 24b 25b

210403 210405 210404

a

Used only for standard seat—not used with suspension seat option.

b

Used only for suspension seat.

Qty. Req.

CS 3/8" x 1" C5ZY. . . . . . . . . . . . . . 2 FW 3/8" AWZY. . . . . . . . . . . . . . . . . 4 HLN INST 3/8" CZY. . . . . . . . . . . . . 4 CS 3/8" x 1-1/2" C5ZY. . . . . . . . . . . 2 BELLOWS, SUSPENSION SEAT . . 1 (includes seat belt tether bracket, and items 22, 23, and 24.)

BELLOWS, SEAT (boot only) . . . . . 1 ADJUSTMENT KNOB . . . . . . . . . . . 1 SHOCK, SUSP. SEAT . . . . . . . . . . . 1

SUSPENSION SEAT (OPTION)

25

23 24

PRINTED IN U.S.A.

23

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Steering Column and Shifter Group

1

3

2

8

Shifter module is on page 20.

7 6 5

4 11

9

10

LS

T

Axle hydraulic circuit is on page 100.

P STEER MOTOR PORTS

50960084/AP0914

24

L

R

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab Steering Column and Shifter Group

Item No.

Part No.

01 02 03 04

L69596 L41261 L69595 L68772

05 06

L99425 L50101

PRINTED IN U.S.A.

Description

Qty. Req.

CAP W/HORN BUTTON . . . . . . . . . 1 NUT, STEERING WHEEL . . . . . . . . 1 STEERING WHEEL . . . . . . . . . . . . 1 F-N-R/1-2-3 SHIFTER . . . . . . . . . . 1 (includes items 5-7) BOOT (included with item 4) . . . . . . 1 M5X.8X35mm HX SKTHD BOLT . . 2 (included with item 4)

25

Item No.

Part No.

07

105236

08 09 10 11

50380779 651625 101882 L63876

Description

Qty. Req.

CLAMP, SHIFTER . . . . . . . . . . . . . 1 (included with item 4) COLUMN, STEERING. . . . . . . . . . . 1 3/8”-16X1-1/4” BUTTON HD BOLT . 4 MOTOR, STEER . . . . . . . . . . . . . . . 1 GROMMET 0.28 ID x 0.38" OD . . . 1 (used to protect horn wire)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Steer Motor and Steer Select Valve Group 2 3

1 LS

L

13 17

R T

Axle hydraulic circuit is on page 100.

P

16

17

12

Steer Motor

14

15

Steer Select valve parts are on page 171.

5 6 P T

12

A

6

B

9 11

7

10

50960084/AP0914

26

Axle hydraulic circuit is on page 100.

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab

Steer Motor and Steer Select Valve Group Item No. 01 02 03 05 06 07 09

Part No.

Description

101882 137784 L63402 L69747 651089 L520003 079026 103319 054994

Qty. Req.

Item No.

STEER MOTOR . . . . . . . . . . . . . . . 1 ADAP., -4ORM -6JICM 90º . . . . . . . 1 HOSE, -4 A6/A6 48” . . . . . . . . . . . . 1 VALVE, STEER SELECT . . . . . . . . 1 CS 1/4 X3 C5ZY (not shown) . . . . . 2 NUT/.25-20 NYLON (not shown) . . 2 ADAP., -6ORM -6JICM 45º . . . . . . . 2 HOSE, -6 A8/A6 22” . . . . . . . . . . . . 1 ADAP., -6ORM -6JICM STR . . . . . . 2

10 11 12 13 14 15 16 17

Part No. 50304898 50304898 L63383 L63387 L68808 L68805 L64524 054626

Description

Qty. Req.

HOSE, -6 X115". . . . . . . . . . . . . . . . 1 HOSE, -6 X115". . . . . . . . . . . . . . . . 1 HOSE, -6 A6/DS8 52” . . . . . . . . . . . 1 HOSE, -6 A8/DS8 67” . . . . . . . . . . . 1 HOSE, -6 A8/DS8 48” . . . . . . . . . . . 1 HOSE, -6 A6/DS6 70” . . . . . . . . . . . 1 VALVE, CHECK, -8ORM . . . . . . . . . 1 ADAP., -8ORM -8JICM STR . . . . . . 3

HOSE LOCATOR 03 07 10 11 12 13 14 15

STEER STEER STEER STEER STEER STEER STEER STEER

MOTOR PORT “LS” SELECT VALVE PORT “T” SELECT VALVE PORT “B” SELECT VALVE PORT “A” MOTOR PORT “R” MOTOR PORT “L” MOTOR PORT “P” MOTOR PORT “T”

PRINTED IN U.S.A.

HYDRAULIC PUMP STEER CYLINDER, FRONT AXLE RIGHT SIDE STEER CYLINDER, REAR AXLE RIGHT SIDE STEER CYLINDER, REAR AXLE LEFT SIDE STEER SELECT VALVE PORT “P” STEER CYLINDER, FRONT AXLE LEFT SIDE HYDRAULIC PUMP HYDRAULIC TANK RETURN MANIFOLD

27

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Brake and Accelerator Pedals

2

1

3

25

26 27

2 3

24 23

19

20 22

19 4 18

21 17 4 16

5

15 14 13

11

9

12 9 8

8 10

6

7

50960084/AP0914

28

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab Brake and Accelerator Pedals

Item No. 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15

Part No. 50381115 654004 650485 L50202 105287 50380743 656009 650491 067847 50380894 651707 653010 50380841 656049 210328

PRINTED IN U.S.A.

Description

Qty. Req.

THROTTLE PEDAL. . . . . . . . . . . . . 1 FW 5/16 AWZY . . . . . . . . . . . . . . . . 2 CS 5/16" x 5/8" C5ZY . . . . . . . . . . . 2 BHSCS 1/4X5/8 C SS . . . . . . . . . . . 2 COVER, THROTTLE PEDAL . . . . . 1 BRAKE CYL., SINGLE TANDEM . . 1 CS M10-1.5X35 C8.8 ZY. . . . . . . . . 2 CS 3/8X1-1/4 C5ZY. . . . . . . . . . . . . 4 HLN INST 3/8 CZY . . . . . . . . . . . . . 4 BRACKET, BRAKE VLV. MOUNT . . 1 LN INST FL M10-1.5 C8.8. . . . . . . . 2 HN 3/8 C2ZY . . . . . . . . . . . . . . . . . . 1 LINKAGE . . . . . . . . . . . . . . . . . . . . . 1 HN M10-1.50 C8 . . . . . . . . . . . . . . . 1 YOKE, CLEVIS M10X1.5 . . . . . . . . 1

29

Item No.

Part No.

16 17 18 19 20

L44859 655006 L561004 654009 210608

21 22 23 24 25

102529 L50628 570019 650545 210609

26 27

210-19470 L63230

Description

Qty. Req.

PIN, CLEVIS 1/2"X27/64" . . . . . . . . 1 CP EPSC 1/8"XX1" Z . . . . . . . . . . . 1 SPRING, EXT. 13 GA. 73X6 . . . . . . 1 FW 1/2 AWZY . . . . . . . . . . . . . . . . . 2 BUSHING, BRONZE . . . . . . . . . . . . 1 (included with item 25) PIN, BRAKE LEVER PIVOT . . . . . . 1 ROLL PIN, 3/16"X1" . . . . . . . . . . . . 1 GREASE ZERK 1/4" TAPER . . . . . . 1 CS 5/16”-18X1-1/4” C5ZY . . . . . . . . 2 BRAKE LEVER ASSEMBLY . . . . . . 1 (includes item 20) LN FL SERR 5/16 CZY . . . . . . . . . . 2 PAD, BRAKE PEDAL . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Brake Valve Hydraulic Circuit Located behind joystick access panel.

Front Axle Service Brake (Right-Side Tee)

3 1 2

4

7

5

4

2 14

2 6

7 2 12 11

13

8

Rear Axle Service Brake (Left-Side Tee)

9

10 Located under cab floor

50960084/AP0914

30

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab Brake Valve Hydraulic Circuit

Item No. 01 02 03 04 05 06 07

Part No. 102842 230-32195 210828 210-19469 230-32364 102840 L70428

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

HOSE, -4 A4/A4 66" . . . . . . . . . . . . 1 ST MJ04-MORB04 . . . . . . . . . . . . . 4 PRESSURE SWITCH 150 P.S.I . . . 2 LN FL SERR 1/4" CZY . . . . . . . . . . 4 PLUG, MORB04 . . . . . . . . . . . . . . . 2 HOSE, -4 A4/A6 90” . . . . . . . . . . . . 1 MANIFOLD, BRAKE LINE. . . . . . . . 2

08 09 10 11 12 13 14

31

Part No. 104111 50381095 50380743 50380754 064260 650486 650706

Description

Qty. Req.

HOSE, -4 A4/A4 18" . . . . . . . . . . . . 2 ST MJ04-M12X1 DIN FL 74235 . . . 2 BRAKE CYL. SINGLE TANDEM . . . 1 MOUNT, BRAKE SWITCHES . . . . . 1 HLN INST 5/16 CZY . . . . . . . . . . . . 2 CS 5/16X3/4 C5ZY . . . . . . . . . . . . . 2 CS 1/4X2 C5ZY . . . . . . . . . . . . . . . . 2

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Cab Components - Tri-Function Controls (Option)

1 12

2

Controller parts on are page 180.

3

11 9

10

8

4

5

5

7 6 Controller parts are on page 182.

5

50960084/AP0914

32

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab

Cab Components - Tri-Function Controls (Option) Item No.

Part No.

01 02

L71346 104304

03 04 05 06 07

L50202 103582 L50051 104214 103264

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, 4 BTN/W TRIG . . . 1 BEZEL, JOYSTICK . . . . . . . . . . . . . 1 (included with item 1) 1/4”-20X5/8” BTN HD BOLT . . . . . AR JOYSTICK MOUNT. . . . . . . . . . . . . 1 1/4”-20 FLANGE LOCK NUT . . . . AR SPACER, LEVEL CONTROLLER . . 2 CONTROLLER, LEVEL. . . . . . . . . . 1

33

Item No.

Part No.

Description

Qty. Req.

08 09 10 11 12

104219 L52024 L52022 103708 L69756

1/4”-20X2-1/2” BTN HD BOLT. . . . . 2 1/4”-20X1” BTN HD BOLT . . . . . . . . 2 1/4”-20X5/8” BTN HD BOLT . . . . . . 2 BRACKET, ARM REST . . . . . . . . . . 1 PAD, ARM REST . . . . . . . . . . . . . . . 1

--

105580

-- ITEMS NOT SHOWN -TRI-FUNCTION WIRE HARNESS . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Heater (Option) - (No A/C)

1

2

6

3

4

5

2

7 13

12 14 11 10

18 8 9

19 17 18

15

16

12

50960084/AP0914

34

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab Heater (Option) - (No A/C)

Item No.

Part No.

01

102907

02 03 04 05

L63545 102944 102945 187841

06 07

273968 136305 50300066

Description

Qty. Req.

Item No.

HEATER ASSEMBLY . . . . . . . . . . . 1 (Includes items 5-11; 13-19) GRILL, DEFROSTER . . . . . . . . . . . 2 INSTRUMENT PANEL. . . . . . . . . . . 1 DECAL, HEAT CONTROL. . . . . . . . 1 CONTROL, TEMPERATURE . . . . . 1 (does not include knob) KNOB (not included with item 5) . . . 1 SWITCH, VARIABLE SPEED . . . . . 1 PANEL MOUNT NUT (included) . . . 2

(NOTE: switch includes knob; knob not sold separately)

08

L500163

PRINTED IN U.S.A.

VALVE, WATER . . . . . . . . . . . . . . . . 1

35

Part No.

09 10 11

NSS 50380847 103033

12 13 14 15 16 17 18 19

L50202 136310 NSS NSS 137503 NSS NSS NSS

Description

Qty. Req.

HOSE, 5/8" - FORMED . . . . . . . . . . 1 HEATER CORE . . . . . . . . . . . . . . . . 1 BLOWER MOTOR. . . . . . . . . . . . . . 1 (does not include fan/cage) 1/4”-20X5/8” BUTTN HD BOLT . . . 10 RESISTOR BLOCK . . . . . . . . . . . . . 1 GROMMET 5/8" OD X 3/8" ID. . . . . 2 HOUSING . . . . . . . . . . . . . . . . . . . . 1 LOUVER . . . . . . . . . . . . . . . . . . . . . 1 HOSE, 5/8" - FORMED . . . . . . . . . . 1 GROMMET 1-3/8" OD X 1" ID . . . . 2 HOSE COUPLER . . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

A/C - Heater - (A/C - Option)

12

13

11

15 14 9

8 10

16

7 17

5

1

6

18 4

16

3 2

50960084/AP0914

36

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab A/C - Heater - (A/C - Option)

Item No.

Part No.

01

210796

02 03 04 05 06 07 08 09

211147 211145 211146 211149 137503 211148 138623 242145 242875

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

HVAC ASSEMBLY . . . . . . . . . . . . . . 1 (Includes items 2-9) FAN ASSEMBLY (only) . . . . . . . . . . 1 FILTER COVER. . . . . . . . . . . . . . . . 1 FILTER, CAB AIR . . . . . . . . . . . . . . 1 EVAPORATOR/HEATER COIL . . . . 1 LOUVER . . . . . . . . . . . . . . . . . . . . . 1 EXPANSION VALVE . . . . . . . . . . . . 1 COLD CONTROL SWITCH . . . . . . . 1 RELAY . . . . . . . . . . . . . . . . . . . . . . . 1 RECTIFIER PACK . . . . . . . . . . . . . . 1

10 11 12 13 14 15 16 17 18

37

Part No. 420-36290 189049 136305 50300066 139279 189033 L63545 L50202 211023 201179

Description

Qty. Req.

LOUVER . . . . . . . . . . . . . . . . . . . . . 1 DECAL, A/C HEATER CONTROL. . 1 SWITCH, VARIABLE SPEED . . . . . 1 PANEL MOUNT NUT (included) . . . 2 KNOB. . . . . . . . . . . . . . . . . . . . . . . . 2 MODULE, A/C CONTROL. . . . . . . . 1 GRILL, VENT. . . . . . . . . . . . . . . . . . 2 1/4”-20X5/8” BUTTN HD BOLT . . . 10 PANEL, HVAC CONTROL. . . . . . . . 1 HOSE, OVERFLOW . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

A/C Circuit (Option) 1

2

Condenser assembly is on page 42

4 5

Condenser

3

(located inside the housing on the top-rear of the cab)

A/C compressor mounting is on page 64.

6

3 5 A/C Dryer

10

(located under the cab)

2

7 2 8

4

9 11

17 16

12 13

7 8 14

15 2 9 Evaporator / Heater Coil (located inside the cab)

50960084/AP0914

38

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab A/C Circuit (Option)

Ref. No. 01 02 03 04 05 06 07 08 09 10

Part No. L500595 138777 138778 211010 50305209 50352428 138779 50305208 50305598 138714

PRINTED IN U.S.A.

Description

Qty. Req.

Ref. No.

CONDENSER . . . . . . . . . . . . . . . . . 1 O-RING . . . . . . . . . . . . . . . . . . . . . . 4 O-RING . . . . . . . . . . . . . . . . . . . . . . 2 HOSE, #6 COND./DRYER . . . . . . . 1 HOSE, #8 COND./COMP. . . . . . . . . 1 COMPRESSOR, A/C. . . . . . . . . . . . 1 O-RING . . . . . . . . . . . . . . . . . . . . . . 2 HOSE, #10 w/SERVICE PORT . . . . 1 HOSE, #6 DRYER/EVAPORATOR . 1 SWITCH, BINARY . . . . . . . . . . . . . . 1

11 12 13 14 15 16 17 --

39

Part No. 138649 650450 650491 138651 090666 50305578 210796

Description

Qty. Req.

A/C DRYER . . . . . . . . . . . . . . . . . . . 1 CS 3/8 x 5/8 C5ZY . . . . . . . . . . . . . 1 CS 3/8 x 1-1/4 C5ZY . . . . . . . . . . . . 1 CLAMP, DRYER . . . . . . . . . . . . . . . 1 HN FL SLOC 3/8 CZY . . . . . . . . . . . 2 MOUNT, DRYER . . . . . . . . . . . . . . . 1 HVAC UNIT (Evaporator/Heater). . . 1

-- ITEMS NOT SHOWN -50305621 WIRE HARNESS, A/C . . . . . . . . . . . 1 (Attaches to starter, A/C compressor, A/C condenser, and HVAC unit in the cab.)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

Heater Circuit (Option) ENGINE

4

A/C and Heater Equipped 6 5 2

3

7

1

2

6

1

8 23

24

22

21 11

10

20

Bracket fastens to engine near heater hose ports

12

3

13

2 HVAC (located inside the cab)

9

14

12

2

ENGINE

Heater Only Equipped

15

6

16 2

7

2

2 Heater Unit

6

17

8

(located inside the cab)

23 22

21

24

20

Bracket fastens to engine near heater hose ports

50960084/AP0914

40

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab Heater Circuit (Option)

Ref. No. 01 02 03 04 05 06 07 08 09 10 11

Part No. 210796 095955 138459 272546 50305830 50303155 50302496 065415 138459 L50051 650512

PRINTED IN U.S.A.

Description

Qty. Req.

Ref. No.

HVAC UNIT . . . . . . . . . . . . . . . . . . . 1 CLAMP, HOSE #10 . . . . . . . . . . . AR HOSE, HEATER 5/8" x 50" . . . . . . . 1 WIRE GUARD (for heater hose) . . . 2 HOSE, HEATER 5/8" x 113" . . . . . . 1 ST MJ10-MM22 SP . . . . . . . . . . . . . 2 90 HB10-FJS10 . . . . . . . . . . . . . . . . 2 90 MJ10-FJS10 . . . . . . . . . . . . . . . . 1 HOSE, HEATER 5/8" x 50" . . . . . . . 1 HLN SERR 1/4"-20 . . . . . . . . . . . . . 2 CS 1/4" x 3/4" C5 . . . . . . . . . . . . . . 2

Part No.

Description

Qty. Req.

12 186193 ST HB10-MP08 . . . . . . . . . . . . . . . . 2 13 50305570 BRACKET, HEATER VALVE . . . . . . 1 14 186703 VALVE, HEATER-A/C SOLENOID . 1 15 102907 HEATER UNIT . . . . . . . . . . . . . . . . . 1 16 243008 HOSE, HEATER 5/8" x 71" . . . . . . . 1 17 230209 HOSE, HEATER 5/8" x 60" . . . . . . . 1 -----------------------------------------------------------------------------20 50306490 BRACKET, HEATER HOSE . . . . . . 1 21 L50206 CLAMP, HOSE 0.875" DBL . . . . . . . 1 22 651695 CS FL M8-1.25x25 8.8 . . . . . . . . . . 1 23 651706 LN INST FL M8-1.25 C8 ZY . . . . . . 1 24 651732 CS FL M10-1.5x20 8.8 ZY. . . . . . . . 2

41

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Cab

RS6-34 Telescopic Handler

A/C Condenser - (A/C Equipped - Option) 1 Condenser Assembly (located on the top-rear of the cab)

2 3

5

3

4

6

7

11 8

12

13

14

16

A/C Hose Covers (located on the right rear corner of the cab)

3

9

10 15

3

17 18

50960084/AP0914

42

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Cab

A/C Condenser - (A/C Equipped - Option) Ref. No.

Part No.

01

211052

02 03 04 05 06 07 08 09

211039 089888 L50051 L500596 211035 L500595 211045 420-35602

PRINTED IN U.S.A.

Description

Qty. Req.

Ref. No.

CONDENSER ASSEMBLY . . . . . . . 1 (includes items 1-10) COVER, CONDENSER HOUSING . 1 BHSCS 1/4” x 1/2” . . . . . . . . . . . . 17 FLANGE LN 1/4”-20 . . . . . . . . . . . . 2 SELF-TAP SCREW 3/16” x 5/8” . . . 6 MOUNT, CONDENSER COIL . . . . . 1 CONDENSER COIL . . . . . . . . . . . . 1 CONDENSER HOUSING . . . . . . . . 1 RELAY . . . . . . . . . . . . . . . . . . . . . . . 1

10 11 12 13 14 15 16 17 18

43

Part No. L500594 651640 210765 070648 210833 50305607 650315 L50051 650512

Description

Qty. Req.

CONDENSER FAN ASSEMBLY . . . 2 BHSCS 5/16” x 3/4” . . . . . . . . . . . . 4 FW 5/16” ZY SEALING . . . . . . . . . . 4 LN LG FL SERR 5/16 CZ . . . . . . . . 4 COVER, A/C HOSES (upper) . . . . . 1 COVER, A/C HOSES (lower) . . . . . 1 SELF-TAP SCREW 1/4” x 1/2” . . . . 3 FLANGE LN 1/4”-20 . . . . . . . . . . . . 3 CS 1/4" x 3/4" C5ZY . . . . . . . . . . . . 3

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Chassis

RS6-34 Telescopic Handler

Hoods - Front

11 1

14 13

13 12

9

8

11

10

2

9 8 4

3

9 8

5

4

4 9

4

8

6

4 5

7

4

50960084/AP0914

44

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Chassis Hoods - Front

Item No. 01 02 03 04 05 06 07

Part No. 50381236 50381229 L68866 L530004 651640 650484 L70045

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

COVER, ACCESS . . . . . . . . . . . . . . 1 HOOD, FRONT . . . . . . . . . . . . . . . . 1 COVER, FRAME FRONT . . . . . . . . 1 FASTENER RETAINED NUT . . . . . 9 BHSCS 5/16”-18X3/4” C8 OCG . . . 4 CS 5/16”-18X1/2”. . . . . . . . . . . . . . . 1 HORN W/GROUND (12V). . . . . . . . 1

08 09 10 11 12 13 14

45

Part No. 654004 650486 210-19470 104222 650648 650387 L64673

Description

Qty. Req.

FW 5/16” AWZY. . . . . . . . . . . . . . . . 6 CS 5/16”-18X3/4” C5ZY . . . . . . . . . 6 LN FL SERR 5/16 CZY . . . . . . . . . . 1 LATCH, COMPRESSION . . . . . . . . 2 HN MS #10-32 FZY. . . . . . . . . . . . . 2 RHMS SLT #10-32 x 1/2" FZY . . . . 2 HANDLE, HOOD . . . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Chassis

RS6-34 Telescopic Handler

Hoods - Center

4

5

7

2

6

2

1

2 3 3

2

3

3 4

4 4 2 3

2 3 2

3

2

4

3

4

4 15 2

8

3 4

2 2

3

3

2

3 9

11 14

2

2

13

3 10

12

4

2 3 4

11

50960084/AP0914

3

46

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Chassis Hoods - Center

Item No. 01 02 03 04 05 06 07 08

Part No. 50304907 650486 654004 L530004 50304791 50304788 50304759 50304821

Description

Qty. Req.

Item No.

COVER, ENGINE . . . . . . . . . . . . . . 1 CS 5/16”-18X3/4” C5ZY . . . . . . . . AR FW 5/16” AWZY . . . . . . . . . . . . . . AR FASTENER RETAINED NUT . . . . AR COVER, REAR . . . . . . . . . . . . . . . . 1 MOUNT, HOOD (LH) . . . . . . . . . . . . 1 PANEL, REAR LEFT SIDE . . . . . . . 1 HOOD, MAIN (CENTER). . . . . . . . . 1

09 10 11 12 13 14 15

Part No. 210-19470 651457 103873 50381241 104222 50304797 50304798

Description

Qty. Req.

LN FL SERR 5/16" CZY . . . . . . . . . 3 LN INST M6-1 C8 ZY . . . . . . . . . . . 8 HINGE, ACCESS COVER. . . . . . . . 2 DOOR, ENGINE ACCESS . . . . . . . 1 LATCH, COMPRESSION . . . . . . . . 1 PANEL, REAR RIGHT SIDE . . . . . . 1 MOUNT, HOOD (RH) . . . . . . . . . . . 1

CENTER HOOD ASSEMBLED

PRINTED IN U.S.A.

47

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Chassis

RS6-34 Telescopic Handler

Hoods and Covers - Rear

1 2 15

3 3

1

14

2

1 2 3

2

DOC Guard (Under the Frame Right Side)

1 1

3

12

3

2

13

3 4

2

12

5

2

1

9

4 2

11

6 7

11 Hose Guard (Under/Inside the Frame -Left Side)

1

2 1

8

2

9 10

8 16

17

Counterweight

NOTE: The counterweight is a non-serviceable item.

50960084/AP0914

48

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Chassis Hoods and Covers - Rear

Item No. 01 02 03 04

Part No.

Description

08 09 10 11 12 13 14 15 16 17 18a

650486 654004 L530004 L70701 L500339 L71595 L500606 100102 210-19470 L70200 L47847 L60956 650489 654049 50304736 090666 L50442 50381217 50304812 50304811 L50333 079209 L60587

19a 20a 21a

103101 L500748 L500747

05 06 07

Qty. Req.

Item No.

CS 5/16”-18X3/4” C5ZY . . . . . . . . AR FW 5/16” AWZY . . . . . . . . . . . . . . AR FASTENER RETAINED NUT . . . . AR LIGHT, TAIL (includes bezel) . . . . . . 2 RUBBER BEZEL . . . . . . . . . . . . . . . 2 LIGHT, BACKUP (includes bezel) . . 1 RUBBER BEZEL . . . . . . . . . . . . . . . 1 JUMPER WIRE (not included) . . . . 1 LN FL SERR 5/16 CZY . . . . . . . . . . 2 BACKUP ALARM. . . . . . . . . . . . . . . 1 ELEC. TERM. FEMALE (not incl.). . 1 ELEC. TERM. MALE (not included) 1 CS 3/8" X 7/8" C5Z . . . . . . . . . . . . . 4 FW 3/8" ANZY . . . . . . . . . . . . . . . . . 4 GUARD, HOSE . . . . . . . . . . . . . . . . 1 LN FL SERR 3/8" CZY . . . . . . . . . . 4 CS 3/8"-16 x 1-1/4" SELF-TAP . . . . 4 GUARD, DOC . . . . . . . . . . . . . . . . . 1 HOOD, REAR . . . . . . . . . . . . . . . . . 1 COVER, REAR . . . . . . . . . . . . . . . . 1 CS 3/4"-10X3" GR5HX . . . . . . . . . . 4 HLN INST 3/4" CZY. . . . . . . . . . . . . 4 3 AMP/800PIV (in-line diode) . . . . . 2 (rear of machine inside the wire loom between diode pack (103101) and back-up alarm wires) DIODE PACK . . . . . . . . . . . . . . . . . 1 DIODE PACK . . . . . . . . . . . . . . . . . 1 CLEAR COVER, DIODE PACK . . . 2

Part No.

--

102647

--

102572

Description

Qty. Req.

-- ITEMS NOT SHOWN -WIRE HARNESS, REAR HOOD. . . 1 (Standard) Connects to chassis wire harness and to the backup alarm, rear backup light, and the right and left stop lights—not used when equipped with the optional light package; the rear section of the optional light package wire harness PN 102572 replaces this standard wire harness.

WIRE HARNESS, LIGHT PACKAGE 1 (Option) Connects to canopy wire harness for the light switch, hazard switch, and turn signal switch. Also connects to the boom light wire harness and the frame harness at the rear of the machine. The rear section of this wire harness replaces the standard rear hood wire harness (PN 102647) and connects to the backup alarm, rear backup light, and the right and left stop lights.

The rear section of this harness replaces the standard rear hood wire harness (102647).

This harness also includes items 18-21. a

Included with light package wire harness 102572.

18

L60587 IN-LINE DIODE

PRINTED IN U.S.A.

21

20

19

103101

L500748

DIODE PACK

DIODE PACK

LOCATED NEAR

LOCATED UNDER DASH

REAR LIGHTS

NEAR SWITCHES

49

L500747 DIODE PACK CLEAR COVER

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Chassis

RS6-34 Telescopic Handler

Hydraulic Tank Group

1 2 10 11 3 8 12

4 5 6

9

7

13

14 15

32

2

16 17

Hydraulic Oil Tank Heater (Option)

18

20 19

31 30

Hydraulic Pump and circuit is on page 134.

29 28

21 26

24

27

25 22

50960084/AP0914

50

23

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Chassis Hydraulic Tank Group

Item No.

Part No.

01

101879

02 03 04 05 06 07 08

50380450 L97489 650489 654006 L277944 L63406 50306017

09 10 11 12 13 14 15 16 17

L99163 L63756 103991 L520003 081379 650488 654004 L65142 L65144

Description

Qty. Req.

Item No.

ASSEMBLY, IN-TANK FILTER. . . . . 1 (includes items 1-3) SEAL KIT (three o-rings) . . . . . . . . . 1 HYDRAULIC FILTER ELEMENT. . . 1 CS 3/8”-16X 7/8” C5Z . . . . . . . . . . . 4 3/8” FLAT WASHER . . . . . . . . . . . . 4 ADAP., -20ORM -12JICM . . . . . . . . 1 HOSE, -12 A12/DS12 114” . . . . . . . 1 CAP ASSEMBLY, HYDRAULIC . . . . 1 (includes item 9) GASKET, FILLER NECK . . . . . . . . . 2 MIRROR, CONVEX 6-1/2”X10”. . . . 1 BRACKET, MIRROR . . . . . . . . . . . . 1 1/4”-20 NYLON INSERT NUT . . . . . 1 5/16”x1/2” LOCK BOLT . . . . . . . . . . 4 5/16”-18x3/4” BOLT . . . . . . . . . . . . 10 5/16” FLAT WASHER . . . . . . . . . . 10 PLATE, HYDRAULIC TANK COVR. 1 GASKET, RUBBER . . . . . . . . . . . . . 1

Part No.

Description

Qty. Req.

18

50380516

HYDRAULIC TANK WELDMENT . . 1 (includes items 22 and 23) 1/2”-13X1-3/4” BOLT . . . . . . . . . . . . 4 HLN INST 1/2 CZY . . . . . . . . . . . . . 4 PLUG, -8ORM SAE . . . . . . . . . . . . . 1 STRAINER, HYD. OIL . . . . . . . . . . . 1 1-1/2” THREADED PIPE . . . . . . . . . 1 ADAP., -24NPTM -24JICM . . . . . . . 1 HOSE, -24 A24/A24 35” . . . . . . . . . 1 HOSE, -4 A6/DS6 60” . . . . . . . . . . . 1 HOSE, -6 A6/DS6 52” . . . . . . . . . . . 1 HOSE, -6 A6/DS8 70” . . . . . . . . . . . 1 HOSE, -6 A6/DS6 52” . . . . . . . . . . . 1 ADAP., -6ORM -6JICM . . . . . . . . . AR PLUG, -6ORM SAE . . . . . . . . . . . . . 1 HEATER/500W (option). . . . . . . . . . 1

19 20 21 22 23 24 25 26 27a 28 29 30 31b 32c

650569 068034 131529 L49327 L61620 L441010 L63309 103315 103318 L68805 103368 054994 122778 50381156

a

Used on units equipped with PWP.

b

Used on units not equipped with PWP.

c

Optional tank heater attaches to the bottom of the hydraulic tank. Used for operating in cold climates.

HOSE LOCATOR 07 25 26 27a 28 29

HYDRAULIC FILTER HYDRAULIC TANK HYDRAULIC TANK RETURN HYDRAULIC TANK RETURN HYDRAULIC TANK RETURN HYDRAULIC TANK RETURN

PRINTED IN U.S.A.

HYDRAULIC CONTROL VALVE “OUT” HYDRAULIC PUMP “IN” JOYSTICK PWP VALVE “T” STEER MOTOR “T” FLOW DIVIDER “T”

51

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Chassis

RS6-34 Telescopic Handler

Fuel Tank Group 5

3

2

4

1

6

7

15

13

10

12

14

8

FUEL SUPPLY

9 11

10

FUEL RETURN

Fuel circuit is shown on page 66.

50960084/AP0914

52

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Chassis Fuel Tank Group

Item No.

Part No.

01 02 03

50381061 210722 L61867

04 05 06 07 08

L41854 650387 068034 650569 110227

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

FUEL TANK WELDMENT . . . . . . . . 1 CAP, FUEL (vented) . . . . . . . . . . . . 1 SENDER, FUEL LEVEL . . . . . . . . . 1 (includes gasket; item #4) GASKET, FUEL SENDER . . . . . . . . 1 #10-32X1/2” RD MACH SCREW . . 5 HLN INST 1/2 CZY . . . . . . . . . . . . . 4 1/2”-13X1-3/4” BOLT . . . . . . . . . . . . 4 ADAP., -8ORM -6JICM 90º . . . . . . . 1

09 10 11 12 13 14 15

53

Part No. 50300449 087852 50304972 054816 50300462 50304958 131529

Description

Qty. Req.

ST HB06-FJS06 BRASS . . . . . . . . . 1 CLAMP, HOSE #06 . . . . . . . . . . . . . 2 HOSE, FUEL -6 x 120" . . . . . . . . . . 1 90 MJ08-MAORB08 . . . . . . . . . . . . 1 ST HB08-FJS08 BRASS . . . . . . . . . 1 HOSE, FUEL -8 x 25" . . . . . . . . . . . 1 PLUG, -8ORM SAE . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Chassis

RS6-34 Telescopic Handler

Battery Group and ECU Secures chassis wire harness to the top left-side of the engine flywheel housing.

1

2

Connects to alternator and starter

3 4

Engine is shown on page 62.

5 6 28

7

7

2

Located under center hood

8

3 10

9

15 11 24

27

16

12 25

23

14 24

13 14

22

17 26

15

16

21 29 17 20 19 18 18

Battery Thermal Wrap (Option)

50960084/AP0914

19 19 18

Located at the front of the machine under the front panel

54

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Chassis Battery Group and ECU

Item No. 01 02 03 04 05a 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20b 21c 22

Part No. 50301134 651668 191352 055648 L500225 210-19469 650863 650347 191192 50301357 650542 193856 195740 651269 653098 L70146 090666 651759 651705 NA NSS L63334

PRINTED IN U.S.A.

Description

Qty. Req.

ALTERNATOR CABLE . . . . . . . . . . 1 CS M12-1.75x16 C8.8 . . . . . . . . . . . 2 CLAMP 0.88" X 0.53" . . . . . . . . . . . 2 TIE, CABLE 0.19x7.50 IN. . . . . . . AR FUSE, MAXI 60 AMP (not shown) . 1 LN FL SERR 1/4" CZY . . . . . . . . . . 1 FW 1/4" ANZY . . . . . . . . . . . . . . . . . 4 CS 1/4x1-3/4 C2 . . . . . . . . . . . . . . . 1 FUSE HOLDER . . . . . . . . . . . . . . . . 1 FUSE, 100A AMG . . . . . . . . . . . . . . 1 CS 1/4" x 1/2" C5ZY . . . . . . . . . . . . 2 SOLENOID (does not include #13) . 1 COVER (not included with #12) . . . 1 SHCS HS 1/4"x7/8" C5 OCG . . . . . 2 WING NUT 3/8" . . . . . . . . . . . . . . . . 2 ROD, BATTERY HOLD DOWN. . . . 2 3/8”-16 FLANGE NUT . . . . . . . . . . . 4 CS FL M6-1.0x30 8.8 ZY. . . . . . . . . 4 LN INST FL M6-1.00 C8 ZY . . . . . . 4 ECU (Engine Control Unit) . . . . . . . 1 BATTERY, 12V 4DLT TYPE . . . . . . 1 BAR, BATTERY HOLD-DOWN . . . . 1

55

Item No.

Part No.

Description

Qty. Req.

23

243319

24 25 26 27 28 29d

071244 071245 101954 L630004 50304354 50381167

a

The fuse holder (shown as item #5) is part of the canopy wire harness and is not sold separately.

b

The ECU is a special order item that requires factory programming. Please provide the engine model and serial number (located on a plate on top of the valve cover) when ordering this part. Be aware that due to the programming requirements there may be a delay in obtaining this part.

c

The battery is not sold separately or is it available from the parts department; please obtain locally.

d

Thermal battery wrap is an option; is included with the Arctic Weather Kit option (PN 50860109).

CABLE END (includes item 24-25) . 1 (cover is not sold separately) LN INST M6-1.0 C9 . . . . . . . . . . . . . 2 LN INST M8-1.25 C9 . . . . . . . . . . . . 1 CABLE, BATTERY NEG. . . . . . . . . . 1 GROUND STRAP, 14GA.X14” . . . . 1 CABLE, BATTERY POS. . . . . . . . . . 1 WRAP, BATTERY THERMAL 56" . . 1 (Option)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Chassis

RS6-34 Telescopic Handler

Frame Level Circuit 3 2

1

4 5 6 6 7

7 Frame Level Cylinder parts are on page 184.

8

9 11

16

12

15 Hydraulic Control Valve parts are on page 168.

10

14

FR

ON

17 13

TA

XL

E

Hydraulic Control Valve

50960084/AP0914

56

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Chassis Frame Level Circuit

Item No. 01 02 03 04 05 06 07 08 09 10

Part No. L63015 L64367 650731 L63276 067847 L68794 L68809 650487 L63715 210447

PRINTED IN U.S.A.

Description

Qty. Req.

LEVEL CYLINDER . . . . . . . . . . . . . 1 BRONZE BEARING . . . . . . . . . . . . 1 3/8”-16X3-1/2” BOLT . . . . . . . . . . . . 1 PIN, CYLINDER (BASE END). . . . . 1 HLN INST 3/8 CZY . . . . . . . . . . . . . 1 ADAP., W/ORIFICE -8ORM -6JICM 2 HOSE, -4 A6/DS6 136” . . . . . . . . . . 2 5/16”X1” BOLT. . . . . . . . . . . . . . . . . 2 PLATE . . . . . . . . . . . . . . . . . . . . . . . 1 PIVOT PIN (ROD END). . . . . . . . . . 1

Item No.

Part No.

11 12 13 14 15 16 17

L63016 210569 210572 L50712 654014 L50084 L60253

Description

Qty. Req.

BRONZE BEARING . . . . . . . . . . . . 1 FRAME LEVEL MOUNT . . . . . . . . . 1 PLATE, FRAME LEVEL. . . . . . . . . . 1 3/4”-10X9” GR8 BOLT . . . . . . . . . . . 4 3/4” FLAT WASHER . . . . . . . . . . . . 4 3/4”-10 STOVER NUT . . . . . . . . . . . 4 ADAP., -10ORM -6JICM . . . . . . . . . 2

.

57

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Personnel Work Platform

RS6-34 Telescopic Handler

Boom Components - (Standard PWP)

1 2 3

4

(Attached to Personnel Work Platform)

5

9'-2“

6

Item No.

Part No.

01

L71729

02 03 04

102408 L71726 L71725

50960084/AP0914

Description

51'-0"

Qty. Req.

REMOTE SWITCH W/CABLE. . . . . 1 (Includes item 2-4) CABLE ASSEMBLY . . . . . . . . . . . . . 1 REMOTE STOP SWITCH . . . . . . . . 1 REMOTE SWITCH ENCLOSURE. . 1

Item No.

Part No.

05 06

L71750 L71732 420-19671 650484 L51143

58

Description

Qty. Req.

REMOTE SWITCH POUCH . . . . . . 1 REMOTE SWITCH HARNESS . . . . 1 (consists of two cables) CLAMP, 3/8" (not shown) . . . . . . . . 1 CS 5/16x1/2 C5ZY (not shown). . . . 1 ZIP TIE 0.171 x 11" (not shown) . . 15

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Personnel Work Platform

Level Sensor, Module, Chains, and Manifold

Located under transmission hood—attached to inner frame PWP circuit is shown on page 154 and 158.

1 2

4 Located under the joysticks—behind access cover.

5

3

Chain and Shackle (Used to secure personnel work platform)

Item No. 01 02

03

Part No. 50380789 650835 L50051 102321 650706 654002 L50139 104078 L50655 650550

PRINTED IN U.S.A.

Description

Qty. Req.

LEVEL SENSOR/PWP 1-AXIS . . . . 1 CS 1/4" x 1" C5ZY (not shown). . . . 2 HLN SERR 1/4" (not shown) . . . . . . 2 MANIFOLD, PWP JOYSTICK . . . . . 1 CS 1/4" x 2" C5ZY (not shown). . . . 2 FW 1/4" AWZY (not shown). . . . . . . 2 LW 1/4" (not shown) . . . . . . . . . . . . 2 MODULE, PWP CONTROL . . . . . . 1 MS #10-24x1/2" RND (not shown) . 2 HN MS #10-24 CZY (not shown) . . 2

59

Item No.

Part No.

Description

Qty. Req.

04a 05a

L71752 L71751

5/16” CHAIN SHACKLE . . . . . . . . . 1 5/16” CHAIN GR40 16 LINKS . . . . 1

---

L71691 104064

-- ITEMS NOT SHOWN -SWITCH, PWP (located on dash) . . 1 WIRE HARNESS, PWP. . . . . . . . . . 1 (under dash)

a

Chain shackle and chain are used to secure the personnel work platform.

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Personnel Work Platform

RS6-34 Telescopic Handler

PWP Radio Remote (Option) - Transmitter and Receiver 14

4

6

7 5

1

2

3 8

12

13

9

10

Bracket (#10) bolts to the bracket that is welded to the frame under the transmission access hood.

11 16 15

Not shown to scale.

Not shown to scale.

50960084/AP0914

60

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Personnel Work Platform

PWP Radio Remote (Option) - Transmitter and Receiver Item No.

Part No.

01

50380274

02a 03 04 05 06 07 08 09 10 11 12

50220629 50220630 NSS 50220628 50220627 50220626 103475 103476 50380826 L50051 650426

PRINTED IN U.S.A.

Description

Qty. Req.

Item No. 13

RADIO REMOTE, SYSTEM . . . . . . 1 (Includes items 2 and 3) REMOTE TRANSMITTER. . . . . . . . 1 RECEIVER, RADIO REMOTE . . . . 1 HOUSING . . . . . . . . . . . . . . . . . . . . 1 SWITCH, TOGGLE 2-POS.. . . . . . . 1 SWITCH, TOGGLE 3-POS.. . . . . . . 4 BUTTON, RADIO E-STOP . . . . . . . 1 LANYARD (wire cable) . . . . . . . . . . 1 SNAP RING, LANYARD . . . . . . . . . 1 BRACKET, RECEIVER MOUNT . . . 1 HLN SERR 1/4" . . . . . . . . . . . . . . . . 2 CS 1/4”X1-1/4” C5ZY . . . . . . . . . . . 2

61

Part No.

Description

Qty. Req.

14

50380789 650835 L50051 50380825

LEVEL SENSOR/PWP 1-AXIS . . . . 1 CS 1/4" x 1" C5ZY (not shown). . . . 2 HLN SERR 1/4" (not shown) . . . . . . 2 DECAL, REMOTE TRANSMITTER. 1 (not included with item 1) HARNESS, CERVIS RADIO . . . . . . 1 HARNESS, RADIO REMOTE . . . . . 1

15 16

50380836 50305606

a

Requires programming—refer to Radio Remote Operator’s Manual / Parts Manual (50960060), included with the Radio Remote Control at the time of purchase.

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Engine

RS6-34 Telescopic Handler

External Components

1 18 19

21

LEFT 18 2

3 17

16

15

4

5 14 13

7 6 7

8 12 9 12

10

8 9

11

10 11

RIGHT 20 Oil Pan Heater (Option)

50960084/AP0914

62

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Engine External Components

Item No. 01 02 03 04 05 06 07 08 09 10 11

Part No. 50380587 TBD 132023 133444 50220553 50220515 50301039 271601 135425 L64197 067826

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

ENGINE, DEUTZ TD 3.6 L4 . . . . . . 1 DIPSTICK, ENGINE OIL LEVEL . . . 1 FILTER, ENGINE OIL . . . . . . . . . . . 1 CAP, ENGINE OIL FILL. . . . . . . . . . 1 SENSOR, PRESSURE . . . . . . . . . . 1 ALTERNATOR . . . . . . . . . . . . . . . . . 1 CS FLH M12-1.75x25 10.9ZY . . . . . 8 CS 5/8" x 4" C8OCG SP . . . . . . . . . 2 MOUNT, ENGINE CUSHION . . . . . 2 WASHER . . . . . . . . . . . . . . . . . . . . . 2 HLN INST 5/8" CZY. . . . . . . . . . . . . 2

12 13 14 15 16 17 18 19 20 21

63

Part No. 50380592 50220511 L69264 651695 50300466 50381171 105910 TBD 50302785 50304956

Description

Qty. Req.

MOUNT, ENGINE . . . . . . . . . . . . . . 2 BELT, FAN/ALTERNATOR. . . . . . . . 1 FAN, ENGINE 20" . . . . . . . . . . . . . . 1 CS FL M8-1.25x25 8.8 ZY. . . . . . . . 4 CS M8-1.25x65 c8.8 ZY SP . . . . . . 4 SPACER, FAN . . . . . . . . . . . . . . . . . 1 CS FL M10 x 30m . . . . . . . . . . . . . . 3 STARTER . . . . . . . . . . . . . . . . . . . . 1 HEATER, OIL PAN 250W (option). . 1 WRAP, REFLECTIVE HEAT . . . . . . 1 (wraps around EGR coolant hose)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Engine

RS6-34 Telescopic Handler

A/C Compressor Group - (Option)

2

2

3

2

4 9

6

8

7

12

6

11

5

10 A/C hoses are shown on page 38.

13

14 15

16 17

18

19

50960084/AP0914

64

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS-634 Telescopic Handler

Engine A/C Compressor Group - (Option)

Ref. No.

Part No.

01 02 03 04 05 06 07 08 09 10a

50305581 651702 50302216 50301159 650579 654049 139952 241385 071703 241010

PRINTED IN U.S.A.

Description

Qty. Req.

Ref. No.

MOUNT, A/C COMPRESSOR . . . . . 1 CS FLH M16-2.00x50 8.8 ZY . . . . . 4 PULLEY, A/C (crankshaft) . . . . . . . . 1 CS M10-1.5x45 C8.8 ZY . . . . . . . . . 6 CS 3.8"x1-3.4" C5ZY. . . . . . . . . . . . 1 FW 3/8 ANZY. . . . . . . . . . . . . . . . . . 2 PULLEY W/BEARING . . . . . . . . . . . 1 SPACER, PULLEY . . . . . . . . . . . . . 1 LN 3/8" CBZY . . . . . . . . . . . . . . . . . 1 BELT TENSIONER . . . . . . . . . . . . . 1

11a 12a 13 14 15 16 17 18 19

656103 651395 071043 651706 651517 271491 50352428 656133 651796

a

Belt tensioner includes items #11 and 12

65

Part No.

Description

Qty. Req.

LW M10 ZY . . . . . . . . . . . . . . . . . . . 1 CS M10-1.5x30 C10.9 ZY . . . . . . . . 1 LN SER FL M10-1.50 C10 ZY. . . . . 4 LN INST FL M8-1.25 C8 ZY . . . . . . 1 SHCS M8-1.25x30 C8.8 OCG. . . . . 1 V-BELT /Ax43 . . . . . . . . . . . . . . . . . 1 COMPRESSOR, A/C. . . . . . . . . . . . 1 FW M10 ZY . . . . . . . . . . . . . . . . . . . 4 CS M10-1.50x110 C10.9 ZY . . . . . . 4

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Engine

RS6-34 Telescopic Handler

Fuel Circuit 2

3

RADIATOR

1 4

Radiator show on next page

5 15

6 7

15 SUPPLY

RETURN

ENGINE

15

32 31

26

27

28

25 30

14

26 15 25

RETURN

15 24 29

FUEL TANK

7

8

6

9 5

23

25

22

15 SUPPLY

13 15 16 21

Fuel tank is on shown on page 52.

14

10 11

12

15

15

17 20 18

19

50960084/AP0914

15

66

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Engine Fuel Circuit

Item No.

Part No.

01 02 03 04 05

650542 50351523 50304911 071401 50303802

06 07 08 09 10 11 12 13 14 15 16 17

50303801 50303794 50303791 50303793 651698 50302437 50302441 50302203 50300449 087852 50304962 50288223

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

CS 1/4"x1/2" C5ZY . . . . . . . . . . . . . 2 COOLER, FUEL . . . . . . . . . . . . . . . 1 MOUNT, FUEL COOLER . . . . . . . . 1 HLN INST 1/4" C5ZY. . . . . . . . . . . . 2 HOSE ASSEMBLY, FUEL . . . . . . . . 1 (includes items 6 and 7) CLAMP, COMPRESSION . . . . . . . . 2 FITTING, ST 1/2" QD FEMALE . . . . 2 FITTING, ST QD FUEL . . . . . . . . . . 1 WASHER, SEALING . . . . . . . . . . . . 1 CS FL M10-1.50x35 8.8 ZY. . . . . . . 2 FUEL FILTER ASY. (secondary) . . . 1 FUEL FILTER (only - incld. w/#11) . 1 ST MJ06-MM16 . . . . . . . . . . . . . . . . 1 ST HB06-FJS06 BRASS . . . . . . . . . 2 CLAMP, HOSE #06 . . . . . . . . . . . AR HOSE, FUEL -6 x 10" . . . . . . . . . . . 1 FUEL PUMP (w/fitting). . . . . . . . . . . 1

67

Part No.

18 19 20 21 22 23 24 25 26 27 28

NSS 50381223 650584 651195 50304958 50302438 651707 50300462 50300327 650489 50303845

29 30 31 32

054816 110227 50304972 50304965

Description

Qty. Req.

FITTING (included with #17) . . . . . . 1 HOSE, FUEL -8 x 18" . . . . . . . . . . . 1 FW #10 AZY . . . . . . . . . . . . . . . . . . 4 SHCS HS #10-24x1/2 C . . . . . . . . . 4 HOSE, FUEL -8 x 25" . . . . . . . . . . . 1 SENSOR, PRESSURE . . . . . . . . . . 1 LN INST FL M10-1.50 C8 . . . . . . . . 2 ST HB08-FJS08 BRASS . . . . . . . . . 3 90 MJ08-MMA16 . . . . . . . . . . . . . . . 2 CS 3/8"x7/8" C5Z . . . . . . . . . . . . . . 2 WATER SEPARATOR ASSEMBLY . 1 (Refer to filter section at beginning of this manual for more information.)

90 MJ08-MAORB08 . . . . . . . . . . . . 1 90 MJ06-MAORB08 . . . . . . . . . . . . 1 HOSE, FUEL -6 x 120" . . . . . . . . . . 1 HOSE, FUEL -6 x 58" . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Engine

RS6-34 Telescopic Handler

Radiator and Cooler Group

2

Radiator and cooler parts shown on the next page.

21 24 22

1

23

21 3

10 20

19 18

17 14

12

4

16

10 14 12

16

5 19

25 12

6

10 7

12

10

13

6

11 9 14

15 8

12 14

25

7

12 Transmission (Left Side)

Transmission (Top-Right Side)

Transmission is shown on page 76.

50960084/AP0914

68

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Engine Radiator and Cooler Group

Item No.

Part No.

01

50380595

02 03 04 05 06 07 08 09 10 11 12

50302457 055005 L67455 210-19470 210148 090666 50301444 055064 055030 50381160 654004

PRINTED IN U.S.A.

Description

Qty. Req.

COOLER ASSEMBLY . . . . . . . . . . . 1 (refer to next page for components) SENSOR, COOLANT LEVEL . . . . . 1 90 MJ12-MAORB12 . . . . . . . . . . . . 1 HOSE, -12 A12/DS12 105" . . . . . . . 1 LN FL SERR 5/16" CZY . . . . . . . . . 6 STUD 3/8"-16 x 2" . . . . . . . . . . . . . . 6 LN FL SERR 3/8" CZY . . . . . . . . . . 6 HOSE, MP -12 x 68" . . . . . . . . . . . . 1 45 MJ12-MAORB12 . . . . . . . . . . . . 1 CLAMP, HOSE #28 . . . . . . . . . . . . . 4 HOSE, RADIATOR BOTTOM . . . . . 1 FW 5/16 AWZY . . . . . . . . . . . . . . . 12

69

Item No.

Part No.

13

650486

14 15 16 17 18 19 20 21 22 23 24 25

650484 420-19671 210329 50381224 50381161 L75990 50380594 062023 50381259 133074 102262 650487

Description

Qty. Req.

CS 5/16" x 3/4" C5ZY . . . . . . . . . . . 2 (used on in the center hole on both sides of shroud) CS 5/16" x 1/2" C5ZY . . . . . . . . . . . 6 CLAMP, HOSE 3/8" . . . . . . . . . . . . . 1 FAN GUARD . . . . . . . . . . . . . . . . . . 2 FAN SHROUD . . . . . . . . . . . . . . . . . 1 HOSE, COOLANT . . . . . . . . . . . . . . 1 CLAMP, HOSE #16 . . . . . . . . . . . . . 2 HOSE, RADIATOR TOP . . . . . . . . . 1 CLAMP, HOSE #05 M . . . . . . . . . . . 2 HOSE, HEATER -5 x 16". . . . . . . . . 1 ST HB05-MP04 . . . . . . . . . . . . . . . . 1 HOSE, OVERFLOW 42" . . . . . . . . . 1 CS 5/16" x 1" C5ZY. . . . . . . . . . . . . 4 (used on the yop and bottom on both sides of shroud)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Engine

RS6-34 Telescopic Handler

Radiator and Cooler Components

Cooler Group shown on previous page.

3

1

2 4

7

5 6

6 8

9

50960084/AP0914

70

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Engine Radiator and Cooler Components

Item No.

Part No.

01

50380595

02 03 04 05

50220759 104932 50220227 081377

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

COOLER/RAD/TOC/SURGE ASY. . 1 (includes all items shown) RADIATOR SECTION . . . . . . . . . . . 1 CAP, RADIATOR 16PSI. . . . . . . . . . 1 SIGHT GLASS. . . . . . . . . . . . . . . . . 1 CS FL LOCK 3/8 x 1-1/4" C5ZY . . . 6

06 07 08 09

71

Part No. 654006 50220761 067847 L40805

Description

Qty. Req.

FW 3/8" AWZY. . . . . . . . . . . . . . . . 12 COOLER SECTION, TRANS. . . . . . 1 HLN INST 3/8 CZY . . . . . . . . . . . . . 6 VALVE, COOLANT DRAIN . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Engine

RS6-34 Telescopic Handler

Air Intake Group

2 1

1

1 3

4 7

6

8

6

5 7

6

9

14 13 12 11

10

50960084/AP0914

72

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Engine Air Intake Group

Item No. 01 02 03 04 05 06 07 08

Part No. 190091 50304225 50381224 50304231 272299 651720 651706 50302313

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

CLAMP, T-BOLT 3-3/4" . . . . . . . . . . 3 HOSE, AIR INTAKE. . . . . . . . . . . . . 1 FAN SHROUD . . . . . . . . . . . . . . . . . 1 HOSE, AIR INTAKE. . . . . . . . . . . . . 1 INDICATOR, SERVICE . . . . . . . . . . 1 CS FL M8-1.25x35 8.8 ZY. . . . . . . . 3 LN INST FL M8-1.25 C8 ZY . . . . . . 3 CLAMP, T-BOLT 4-1/4" . . . . . . . . . . 1

73

Part No.

09

50351477

10 11 12 13 14

50220719 NSS 50352454 50352455 NSS

Description

Qty. Req.

AIR CLEANER ASSEMBLY. . . . . . . 1 (includes items 10-14) DUST EVACUATOR . . . . . . . . . . . . 1 END CAP (not sold separately). . . . 1 FILTER, AIR (PRIMARY) . . . . . . . . . 1 FILTER, AIR (SECONDARY) . . . . . 1 HOUSING (not sold separately) . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Engine

RS6-34 Telescopic Handler

Exhaust Group

1 5

2

6 4

3

16 Attaches to turbocharger

15

14

13 12 Attaches to engine

7 8 7 8

9 11 9

10

50960084/AP0914

74

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Engine Exhaust Group

Item No.

Part No.

01 02 03 04 05 06 07 08 09 10 11a

131951 L64764 067847 654006 650490 50381174 50220574 50220575 651706 50302200 NSS

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

CLAMP, MUFFLER 3" . . . . . . . . . . . 1 HANGER, TAILPIPE . . . . . . . . . . . . 1 HLN INST 3/8" CZY. . . . . . . . . . . . . 1 FW 3/8" AWZY. . . . . . . . . . . . . . . . . 2 CS 3/8" x 1" C5ZY. . . . . . . . . . . . . . 1 TAILPIPE . . . . . . . . . . . . . . . . . . . . . 1 CLAMP, EXHAUST . . . . . . . . . . . . . 2 GASKET, EXHAUST . . . . . . . . . . . . 2 LN INST FL M8-1.25 C8 ZY . . . . . . 8 CLAMP, DOC MOUNT . . . . . . . . . . 2 DOC . . . . . . . . . . . . . . . . . . . . . . . . 1

75

Part No.

Description

Qty. Req.

12 13 14 15 16

651695 50381198 651699 50381150 50220500 50220501

CS FL M8-1.25x25 8.8 ZY. . . . . . . . 8 MOUNT, DOC . . . . . . . . . . . . . . . . . 1 CS FLH M12-1.75x25 8.8ZY . . . . . . 4 COUPLER, EXHAUST PIPE . . . . . . 1 CLAMP, EXHAUST (3-1/2"). . . . . . . 1 NUT (not included with clamp) . . . . 1

a

The DOC is not sold separately; please consult the engine parts manual PN 50960088, or contact the factory parts department for assistance.

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Transmission

RS6-34 Telescopic Handler

External Components Transmission Cooler Top Port

RIGHT 16

2 15

Transmission cooler shown on page 70.

1

14 6

8

3

Drive/Flex plate shown on next page.

4

13

5

9 6 10

12

7

11

8 Transmission Cooler Bottom Port

9 10

18

11

17

19

20 23

20

24

20

17

18

LEFT

21

21

50960084/AP0914

76

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Transmission External Components Group

Item No.

Part No.

01 02a 03b 04 05 06 07 08 09 10 11 12 13 14 15

50305017 656007 50302228 188973 50301444 271601 50380901 L50704 135425 L64197 067823 L66965 50304852 054819 L99184

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

TRANSMISSION/1102 T12000 . . . . 1 CS M10-1.5X25 C8.8. . . . . . . . . . . 11 CS FLH M10-1.5x40 10.90 CGSP . 8 ST-L MJ12-MORB12 . . . . . . . . . . . . 1 HOSE, MP -12 x 68" . . . . . . . . . . . . 1 CS 5/8x4 C8OCG SP . . . . . . . . . . . 2 MOUNT, TRANSMISSION (LH) . . . 1 CS M12-1.75x40 GR8 . . . . . . . . . . . 5 MOUNT CUSHION . . . . . . . . . . . . . 2 WASHER . . . . . . . . . . . . . . . . . . . . . 2 HLN INST 5.8 CZY . . . . . . . . . . . . . 2 SENDER, TEMPERATURE. . . . . . . 1 MOUNT, TRANSMISSION (RH) . . . 1 ST MJ12-MORB10 . . . . . . . . . . . . . 1 TRANSMISSION FILTER . . . . . . . . 1

16 17 18c 19 23d

77

Part No.

Description

24

L67455 L99182 L50468 50381202 650965 654026 50381201

a b c d

Fastens Fastens Fastens Fastens

Qty. Req.

HOSE, -12 A12/DS12 105" . . . . . . . 1 UNIVERSAL JOINT (includes bolts) 4 3/8”-24X1-3/4” GR8 BOLT. . . . . . . 16 DRIVESHAFT, REAR . . . . . . . . . . . 1 3/8”-24X1-1/4” GR 8 BOLT . . . . . . . 8 3/8” LOCK WASHER . . . . . . . . . . . . 8 DRIVESHAFT, FRONT . . . . . . . . . . 1

flex plate to flywheel. transmission to engine. u-joint to transmission and axle yokes. u-joint to driveshaft.

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Transmission

RS6-34 Telescopic Handler

Drive (Flex) Plate Group

2 2 1

2

3 5 4

Item No.

Part No.

01

50220762

02

NSS

03

L98316

50960084/AP0914

Description

Qty. Req.

Item No. 04 05 06

KIT, DRIVE PLATE . . . . . . . . . . . . . 1 (includes all items shown above) DRIVE PLATE . . . . . . . . . . . . . . . . . 3 (included with item 1) RING/DRIVE PLATE BACKING . . . 1

78

Part No. L99785 L99030 L98317

Description

Qty. Req.

BOLT . . . . . . . . . . . . . . . . . . . . . . . . 6 LOCKWASHER . . . . . . . . . . . . . . . . 6 KIT/DRIVE PLATE ASSY . . . . . . . . 1 (includes items 1 thru 5)

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Transmission Converter Housing Group

5

6

1

14 7 4

2 3

11 9 13

11

12 13

15

8

11

10

3 12

Item No. 01 02 03 04 05 06 07 08

Part No. L99286 NSS L99284 L99246 NSS L99284 L99262 L99285

PRINTED IN U.S.A.

2

Description

Qty. Req.

Item No.

HOUSING/CONVERTER . . . . . . . . 1 PLUG (includes item 3) . . . . . . . . . . 4 O-RING/PLUG (part of item 2) . . . . 4 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 1 PLUG (includes item 6) . . . . . . . . . . 1 O-RING/PLUG (part of item 5) . . . . 1 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 1 SCREW . . . . . . . . . . . . . . . . . . . . . . 6

09 10 11 12 13 14 15

79

Part No. L99260 L99261 L99029 L99260 L99029 L98938 L99249

Description

Qty. Req.

SCREW . . . . . . . . . . . . . . . . . . . . . . 3 SCREW . . . . . . . . . . . . . . . . . . . . . . 1 WASHER/LOCK . . . . . . . . . . . . . . 10 SCREW . . . . . . . . . . . . . . . . . . . . . 13 WASHER/LOCK . . . . . . . . . . . . . . 13 GASKET/HSG. TO PLATE. . . . . . . . 1 PLUG/TEMP PICKUP . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Transmission

RS6-34 Telescopic Handler

Case and Plate Group

7

31 29

28

24 10

30

25

27 13 36

12 31

21 19

17 29

18

30 11

15

2

16

23 14 21

18

20 19

17 6

33

3 4 26

32

22

35 34

1

8

9

50960084/AP0914

5

80

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Transmission Case and Plate Group

Item No.

Part No.

01 02 03

NSS L94824 L99251

04

L99013

05 06 07 08 09 10 11 12 13 14 15 16 17

L99253 L98927 L98926 L98185 L98176 102949 L98935 L98932 L98226 L98218 L98217 L99246 NSS

PRINTED IN U.S.A.

Description

Qty. Req.

Item No. 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35

CASE, TRANSMISSION . . . . . . . . . 1 BREATHER/AIR . . . . . . . . . . . . . . . 1 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 2 (includes item 4) O-RING/PLUG . . . . . . . . . . . . . . . . . 2 (part of item item 3) PLUG/MAGNETIC DRAIN. . . . . . . . 1 PIN/DOWEL PLATE TO CASE . . . . 2 GASKET/PLATE TO CASE . . . . . . . 1 RING/TUBE SEAL. . . . . . . . . . . . . . 1 CLIP/OIL TUBE RETAINER . . . . . . 1 PLATE, SPACER . . . . . . . . . . . . . . . 1 SEAT/SAFETY VALVE . . . . . . . . . . 1 SNAP RING . . . . . . . . . . . . . . . . . . . 1 POPPET/SAFETY VALVE . . . . . . . . 1 SPRING . . . . . . . . . . . . . . . . . . . . . . 1 WASHER/POPPET . . . . . . . . . . . . . 1 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 1 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 3

81

Part No. L99284 L99018 L99045 L99029 L98184 L99274 L99246 L99262 106175 L98734 L98735 L99287 L99312 L99288 L99285 L99294 L99295 L99296

Description

Qty. Req.

O-RING/PLUG . . . . . . . . . . . . . . . . . 3 SCREW . . . . . . . . . . . . . . . . . . . . . . 7 SCREW . . . . . . . . . . . . . . . . . . . . . . 2 WASHER/LOCK . . . . . . . . . . . . . . . 9 ASSY/TUBE & SCREEN . . . . . . . . . 1 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 1 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 1 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 1 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 1 TUBE/TRANS DIPSTICK . . . . . . . . 1 TRANS DIPSTICK TUBE . . . . . . . . 1 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 2 O-RING . . . . . . . . . . . . . . . . . . . . . . 2 SCREW . . . . . . . . . . . . . . . . . . . . . . 2 SCREW . . . . . . . . . . . . . . . . . . . . . . 1 WASHER/SEAL . . . . . . . . . . . . . . . . 1 WASHER/SCREW. . . . . . . . . . . . . . 1 NUT . . . . . . . . . . . . . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Transmission

RS6-34 Telescopic Handler

Torque Converter Group

7

8

13

10

11 13 6 9

3 1 4

14

12

2

16

5 6

15

50960084/AP0914

82

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Transmission Torque Converter Group

Item No. 01 02 03 04 05 06 07 08

Part No. L98203 L98204 L98197 L98201 L98202 L98200 L98194 L500294

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

ASSY/STATOR SUPPORT . . . . . . . 1 BUSHING . . . . . . . . . . . . . . . . . . . . 1 BEARING/FRONT . . . . . . . . . . . . . . 1 RING/PISTON . . . . . . . . . . . . . . . . . 1 EXPANDER/RING . . . . . . . . . . . . . . 1 RING/SNAP . . . . . . . . . . . . . . . . . . . 2 SEAL/OIL CONV. HSG. . . . . . . . . . . 1 ASSY/TORQUE CONVERTER . . . . 1

09 10 11 12 13 14 15 16

83

Part No. L98189 L97525 L97526 L98199 L98191 L98205 L98198 L98196

Description

Qty. Req.

PLUG/BORE . . . . . . . . . . . . . . . . . . 1 O-RING/BORE PLUG . . . . . . . . . . . 1 RING/RET. BORE PLUG. . . . . . . . . 1 IMPELLER/HUB GEAR . . . . . . . . . . 1 SNAP RING/IMPELLER HUB . . . . . 2 WASHER/HUB GEAR . . . . . . . . . . . 1 BEARING/TORQUE CONVERTER. 1 RING/OIL DISTRIBUTOR . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Transmission

RS6-34 Telescopic Handler

Gear Group

13 12 11

9

5

10 6

4

1 3

2

15

7 14 8

16

50960084/AP0914

84

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Transmission Gear Group

Item No.

Part No.

01

NSS

02

L98253

03

L98254

04

NSS

05

L98253

06

L98254

07

L500407

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

ASSY/REV. GEAR & BEARING . . . 1 (includes items 2 and 3) BEARING/NEEDLE . . . . . . . . . . . . . 2 (part of item 1) SPACER/CLUTCH GEAR . . . . . . . . 1 (part of item 1) ASSY/FOR. GEAR & BEARING . . . 1 (includes items 5 and 6) BEARING/NEEDLE . . . . . . . . . . . . . 2 (part of item 4) SPACER/CLUTCH GEAR . . . . . . . . 1 (part of item 4) ASY. 3RD CLUTCH GEAR . . . . . . . 1 (includes item 8)

85

Part No.

08

L500408

09

L98968

10

L98253

11

L98276

12

L98253

13 14 15 16

L98277 L98284 L98955 L500409

Description

Qty. Req.

BEARING-3RD CLUTCH GEAR . . . 2 (part of item 7) 1st CLUTCH GEAR/BRG. ASSY . . . 1 (includes item 9) BEARING/NEEDLE . . . . . . . . . . . . . 2 (part of item 9) 2nd CLUTCH GEAR/BRG. ASSY . . 1 (includes item 12) BEARING/NEEDLE . . . . . . . . . . . . . 2 (part of item 11) GEAR/THIRD DRIVEN - 18T . . . . . 1 GEAR/OUTPUT SHAFT - 40T . . . . 1 GEAR/REVERSE IDLER - 28T . . . . 1 GEAR/FIRST DRIVEN - 27T . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Transmission

RS6-34 Telescopic Handler

Drive Pump Group

7

5

6 1 3 4 6

Item No.

2

Part No.

01

L98945

02

L98947

03

L98944

50960084/AP0914

Description

Qty. Req.

Item No.

IDLER/SHAFT & PIN. . . . . . . . . . . . 1 (includes item 2) ROLL PIN . . . . . . . . . . . . . . . . . . . . 1 (part of item1) GEAR/IDLER,PUMP DRIVE . . . . . . 1

04 05 06 07

86

Part No. L98943 L98211 L98942 L98212

Description

Qty. Req.

BEARING/IDLER GEAR . . . . . . . . . 1 GEAR/DRIVE. . . . . . . . . . . . . . . . . . 1 WASHER/THRUST . . . . . . . . . . . . . 2 RING/SNAP . . . . . . . . . . . . . . . . . . . 1

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Transmission Charge Pump Group

Transmission Charge Pump; not to be confused with the hydraulic system pump 14

15

1

13 16

12 17 11 7

6 10

8 5

9

2

4

3

Item No.

Part No.

01 02 03 04 05 06 07

L98220 L99184 L98953 L98950 L98951 L98224 L98949

08 09 10

L98215 L98216 L98214

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

PUMP/T12000 CHARGE. . . . . . . . . 1 ASSY/ HYDRAULIC SPIN FILTER . 1 SLEEVE. . . . . . . . . . . . . . . . . . . . . . 1 PISTON . . . . . . . . . . . . . . . . . . . . . . 1 SPRING . . . . . . . . . . . . . . . . . . . . . . 1 PIN/CLARK TRANS. . . . . . . . . . . . . 1 ASSY/BALL CHECK VALVE . . . . . . 1 (includes items 8 thru 11) BALL . . . . . . . . . . . . . . . . . . . . . . . . 1 SPRING . . . . . . . . . . . . . . . . . . . . . . 1 PIN. . . . . . . . . . . . . . . . . . . . . . . . . . 1

87

Part No.

Description

Qty. Req.

11 12 13 14 15 16 17

L98948 L98219 L99025 L99023 L99020 L99027 L99029

O-RING . . . . . . . . . . . . . . . . . . . . . . 1 GASKET/CHARGE PUMP . . . . . . . 1 SCREW . . . . . . . . . . . . . . . . . . . . . . 4 SCREW . . . . . . . . . . . . . . . . . . . . . . 1 WASHER/LOCK . . . . . . . . . . . . . . . 5 SCREW . . . . . . . . . . . . . . . . . . . . . . 1 WASHER/LOCK . . . . . . . . . . . . . . . 1

--

L98954

--ITEMS NOT SHOWN-ASSY/FILTER MOUNT . . . . . . . . . . 1 (includes items 3-6)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Transmission

RS6-34 Telescopic Handler

Output Shaft Group

7 6 2 5 6

3

4 1

8 9

6 4 3

2

5

6

Item No. 01 02 03 04 05

Part No. L500274 L98282 L98281 L98268 L96053

50960084/AP0914

Description

Qty. Req.

Item No.

SHAFT/OUTPUT . . . . . . . . . . . . . . . 1 BEARING/SHAFT . . . . . . . . . . . . . . 2 SLEEVE/OIL SEAL . . . . . . . . . . . . . 2 O-RING/SLEEVE. . . . . . . . . . . . . . . 2 SEAL/OUTPUT SHAFT OIL . . . . . . 2

06 07 08 09

88

Part No. L98264 L98266 L98279 L98278

Description

Qty. Req.

RING/SNAP . . . . . . . . . . . . . . . . . . . 4 RING/SNAP . . . . . . . . . . . . . . . . . . . 2 FLANGE/OUTPUT & PLUG ASSY . 1 PLUG/FLANGE . . . . . . . . . . . . . . . . 1

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Transmission Reverse Idler Group

6 7 5 9

8

3 4

1 2

Item No. 01 02 03 04

Part No. L98229 L98228 L98231 L98230

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

SHAFT IDLER & PILOT . . . . . . . . . 1 RING/SNAP . . . . . . . . . . . . . . . . . . . 1 BEARING/REV IDLR GEAR . . . . . . 1 WASHER/THRUST . . . . . . . . . . . . . 1

05 06 07 08

89

Part No. L98232 L99031 L99032 L98233

Description

Qty. Req.

END PLATE . . . . . . . . . . . . . . . . . . . 1 CAPSCREW . . . . . . . . . . . . . . . . . . 1 WASHER . . . . . . . . . . . . . . . . . . . . . 1 END PLATE . . . . . . . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Transmission

RS6-34 Telescopic Handler

Forward and Reverse Group

21

11

19 19

17

16

20 14

12

11

13

15

17

10 5 8 9

18

7

17

16

16 19 1

6

22

19 17

7

17 6

17

5

17 20

17 9

3

8 16 10

15 12

13

14

2 4

50960084/AP0914

90

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Transmission Forward and Reverse Group

Item No.

Part No.

01 02 03 04 05

L98248 L98251 L98252 L98250 L99278

06

L98246

07

L98247

08 09 10 11

L98238 L98237 L98244 L98961

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

ASY/TURB SHFT DRUM & PLUG . 1 SLEEVE/OIL DISTRIBUTOR. . . . . . 1 SCREW . . . . . . . . . . . . . . . . . . . . . . 1 RING/PISTON . . . . . . . . . . . . . . . . . 3 ASY/PISTON . . . . . . . . . . . . . . . . . . 2 (includes items 6 and 7) SEAL/OUTER PISTON . . . . . . . . . . 2 (part of item 5) SEAL/INNER PISTON . . . . . . . . . . . 2 (part of item 5) PLATE/END . . . . . . . . . . . . . . . . . . . 2 RING/SNAP . . . . . . . . . . . . . . . . . . . 2 PLATE/WEAR . . . . . . . . . . . . . . . . . 2 ASY/DISC SPRING Pkg 5. . . . . . . . 2

91

Part No.

12 13 14 15 16 17 18 19 20 21

L98242 L98241 L98240 L98239 L98236 L98235 L98249 L98253 L98254 L98962

22

L98255

Description

Qty. Req.

RETAINER. . . . . . . . . . . . . . . . . . . . 2 RETAINER/SNAP RING . . . . . . . . . 2 CLUTCH/OUTER FWD . . . . . . . . . 12 CLUTCH/INNER FWD. . . . . . . . . . 12 BEARING. . . . . . . . . . . . . . . . . . . . . 4 WASHER/THRUST . . . . . . . . . . . . . 8 BEARING/REAR . . . . . . . . . . . . . . . 1 BEARING/CLUTCH GEAR . . . . . . . 4 SPACER/CLUTCH GEAR . . . . . . . . 2 ASSY/REV. AND BRG. . . . . . . . . . . 1 (includes items 19 and 20) ASSY/FOR. GEAR AND BRG. . . . . 1 (includes items 19 and 20)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Transmission

RS6-34 Telescopic Handler

Third Shaft Group

10

1

21

24 4 3

12

7

5

11

6

17

18

16 2 21 15

20 19

8 20

9 22

22

23 19

20

20 21 14 13

50960084/AP0914

92

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Transmission Third Shaft Group

Item No. 01 02 03 04 05 06 07 08 09 10 11 12

Part No. L500410 L500411 L500273 L500412 L98258 L98257 L98250 L99279 L98246 L98247 L98240 L98239

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

ASY-3RD SHAFT, DRUM & PLUG . 1 BEARING-ROLLER . . . . . . . . . . . . . 1 ASSY/BEARING & SEAL . . . . . . . . 1 WASHER-BEARING SUPPORT . . . 1 SLEEVE/OIL DISTRIBUTOR. . . . . . 1 SCREW/SLEEVE LOCK . . . . . . . . . 1 RING/PISTON . . . . . . . . . . . . . . . . . 2 ASSY/CLTCH PISTON & BALL. . . . 1 SEAL/OUTER PISTON . . . . . . . . . . 1 SEAL/INNER PISTON . . . . . . . . . . . 1 CLUTCH/OUTER FWD . . . . . . . . . . 5 CLUTCH/INNER FWD. . . . . . . . . . . 5

13 14 15 16 17 18 19 20 21 22 23 24

93

Part No. L98238 L98237 L98244 L98961 L98242 L98241 L500413 L500414 L99696 L500408 L500407 L500408

Description

Qty. Req.

PLATE/END . . . . . . . . . . . . . . . . . . . 1 RING/SNAP . . . . . . . . . . . . . . . . . . . 1 RING/SNAP . . . . . . . . . . . . . . . . . . . 1 ASY/DISC SPRG PKG 5. . . . . . . . . 1 RETAINER. . . . . . . . . . . . . . . . . . . . 1 RETAINER/SNAP RING . . . . . . . . . 1 BEARING-THRUST NEEDLE . . . . . 2 WASHER/CLTCH GEAR THRUST . 4 RING/SNAP . . . . . . . . . . . . . . . . . . . 3 BEARING-3RD CLUTCH GEAR . . . 2 ASY. 3RD CLUTCH GEAR . . . . . . . 1 GEAR-FIRST DRIVEN . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Transmission

RS6-34 Telescopic Handler

First and Second Shaft Group

25 12 24 13

15 3

20

14 13

4

18

16 11 19 10

21 8

5

27

9 15 1

7

17 16

16

6

7

24

26

6

15

16

5 10 9 8

15 23 22 14

2

50960084/AP0914

94

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Transmission First and Second Shaft Group

Item No. 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15

Part No. L98274 L98275 L500273 L98250 L99038 L98246 L98247 L98238 L98237 L98244 L98961 L98967 L98242 L98241 L98236

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

ASY-1ST 2ND SHAFT . . . . . . . . . . . 1 BEARING/REAR . . . . . . . . . . . . . . . 1 ASSY/BEARING & SEAL . . . . . . . . 1 RING/PISTON . . . . . . . . . . . . . . . . . 2 PISTON/CLUTCH & SEALS . . . . . . 2 SEAL/OUTER PISTON . . . . . . . . . . 2 SEAL/INNER PISTON . . . . . . . . . . . 2 PLATE/END . . . . . . . . . . . . . . . . . . . 2 RING/SNAP . . . . . . . . . . . . . . . . . . . 2 PLATE/WEAR . . . . . . . . . . . . . . . . . 2 ASSY/DISC SPRG PKG 5 . . . . . . . 1 SPRING/DISC ASSY PKG (7). . . . . 1 RETAINER. . . . . . . . . . . . . . . . . . . . 2 RETAINER/SNAP RING . . . . . . . . . 2 BEARING. . . . . . . . . . . . . . . . . . . . . 4

95

Part No.

16 17 18 19 20 21 22 23 24 25

L98235 L98260 L98272 L98257 L98240 L98239 L98240 L98239 L98253 L98968

26

L98276

27

L98277

Description

Qty. Req.

WASHER/THRUST . . . . . . . . . . . . . 8 RING/SNAP . . . . . . . . . . . . . . . . . . . 2 SLEEVE/OIL DISTRIBUTOR. . . . . . 1 SCREW/SLEEVE LOCK . . . . . . . . . 1 CLUTCH/OUTER FWD . . . . . . . . . 10 CLUTCH/INNER FWD. . . . . . . . . . 10 CLUTCH/OUTER FWD . . . . . . . . . . 5 CLUTCH/INNER FWD. . . . . . . . . . . 5 BEARING/CLUTCH GEAR . . . . . . . 4 1ST CLUTCH GEAR/BRG ASSY . . 1 (includes item 24) 2ND CLUTCH GEAR/BRG ASSY . . 1 (includes item 24) GEAR/3RD DRIVEN . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Transmission

RS6-34 Telescopic Handler

Modulation Valve Group

1 9 2

12

8

13 11

3

10 4 14

6

5

7 15

Item No. 01 02 03 04 05 06 07 08

Part No. L98291 L98292 L98294 L98295 L98304 L98298 L98307 L98293

50960084/AP0914

Description

Qty. Req.

Item No. 09 10 11 12 13 14 15

HOUSING MODULATOR VALVE . . 1 O-RING . . . . . . . . . . . . . . . . . . . . . . 1 SPRING INNER. . . . . . . . . . . . . . . . 1 SPRING MIDDLE . . . . . . . . . . . . . . 1 SPRING OUTER . . . . . . . . . . . . . . . 1 SLEEVE-MODULATION VALVE . . . 1 O-RING . . . . . . . . . . . . . . . . . . . . . . 1 PIN STOP . . . . . . . . . . . . . . . . . . . . 1

96

Part No. L98303 L98958 L98300 L98302 L98301 L98956 L98957

Description

Qty. Req.

SPOOL ACCUMULATOR . . . . . . . . 1 SPOOL . . . . . . . . . . . . . . . . . . . . . . 1 SPRING . . . . . . . . . . . . . . . . . . . . . . 1 RETAINER. . . . . . . . . . . . . . . . . . . . 1 SPACER . . . . . . . . . . . . . . . . . . . . . 1 PIN-UPPER . . . . . . . . . . . . . . . . . . . 1 PIN-LOWER . . . . . . . . . . . . . . . . . . 1

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Transmission Control Group

5

4

3

2 1 10 12 11

9

Item No.

Part No.

01

102950

02

102951

03

102952

04

102953

05

102954

06

102955

PRINTED IN U.S.A.

Description

Qty. Req.

Item No.

SOLENOID, W / DEUTSCH CON. . 4 (includes items 2 thru 5) O-RING, 21.5 X 1.5MM . . . . . . . . . . 4 (included with item 1) O-RING, 15.1 X 1.60MM . . . . . . . . . 4 (included with item 1) O-RING, 14.1 X 1.60MM . . . . . . . . . 4 (included with item 1) O-RING, 12.1 X 1.60MM . . . . . . . . . 4 (included with item 1) PLUG, SOLENOID BORE . . . . . . . . 1 (includes items 7, 8 and 9)

97

8

7

6

Part No.

07

102956

08

102952

09

102954

10 11 12

102957 106259 102959

Description

Qty. Req.

O-RING, 18.0 X 2.20MM . . . . . . . . . 1 (included with item 6) O-RING, 15.1 X 1.60MM . . . . . . . . . 1 (included with item 6) O-RING, 12.1 X 1.60MM . . . . . . . . . 1 (included with item 6) CLAMP, SOLENOID . . . . . . . . . . . . 6 CAPSCREW . . . . . . . . . . . . . . . . . 12 WASHER, PLAIN. . . . . . . . . . . . . . 12

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Axle

RS6-34 Telescopic Handler

External Components

2

3

4

LEFT 1 7

AXLE MODEL AND SERIAL NUMBER PLATE

10 9

11

RIGHT

22

14 15 20 13

12 Front axle (shown)

Driveshafts are on page 76.

16 19 18 17

50960084/AP0914

98

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Axle External Components

Item No. 01

Part No.

02a 03a 04a 07a 09

NSS L63222 NSS L68875 NSS L67504 L50253 L99951 105857 102587 L50201

10 11 12

L50712 210569 L69734

13

L50084

14 15

210572 651543

PRINTED IN U.S.A.

Description

Qty. Req.

TIRE AND WHEEL ASY . . . . . . . . AR VALVE STEM . . . . . . . . . . . . . . . . AR TIRE, 15.00X19.5 12 PLY WHEEL ONLY (for above tire) . . . AR TIRE, 9.00R 20XMINE D2 WHEEL ONLY (for above tire) . . . AR 3/8”-16 BUTTON HD BOLT . . . . . . . 6 FENDER . . . . . . . . . . . . . . . . . . . . . 1 FENDER MOUNT . . . . . . . . . . . . . . 1 M12-1.5 NUT . . . . . . . . . . . . . . . . . . 4 M20-2.5 CLASS 10 LOCK NUT . . . 8 (four per axle) 3/4”-10X9” GR8 BOLT . . . . . . . . . . . 4 FRAME LEVEL MNT (front axle). . . 1 M22-1.5 WHEEL NUT . . . . . . . . . . 32 (eight per wheel) 3/4”-10 GR8 LOCK NUT . . . . . . . . . 8 (four per axle) PLATE, FRAME LEVEL. . . . . . . . . . 1 M20-2.50X130 C10.9 BOLT . . . . . . 8 (four per axle)

Item No.

Part No.

16 17 18 19 20 21 22b

L500543 L500544 L98355 L500496 L500542 NA 102668 50380746 L68849 50380745

99

Description

Qty. Req.

THRUST BUSHING. . . . . . . . . . . . . 2 SUPPORT . . . . . . . . . . . . . . . . . . . . 2 GREASE FITTING. . . . . . . . . . . . . . 2 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 2 REDUCTION BUSING . . . . . . . . . . 4 .............................0 AXLE ASSEMBLY, 212 FRONT (with internal park brake) . . 1 FRONT (remanufactured) (note c) REAR. . . . . . . . . . . . . . . . . . . . . . . . 1 REAR (remanufactured) (note c)

a

Available only on the front axle left side.

b

Axle assembly only, does not include any other items shown in the illustration.

c

Call the factory parts department for more information regarding remanufactured axles.

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Axle

RS6-34 Telescopic Handler

Brake and Steering Circuit - Front Axle

Flow Divider parts are on page 167.

5

6

1 PARK BRAKE

PB

4

3

22

7

L

7

2

4 8

4 9

21

5

20 4

SERVICE BRAKE

Steer motor also shown on page 172

10

11

Brake valve circuit shown on page 30

19 18

9 14

2 13

T

12 17

16 15

10

11

Steer select also shown on page 26.

50960084/AP0914

100

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Axle Brake and Steering Circuit - Front Axle

Item No. 01 02 03 04 05 06 07 08 09 10 11

Part No. 102313 079026 103317 L66139 095457 L69928 091039 L69928 102842 100011 088442

PRINTED IN U.S.A.

Description

Qty. Req.

MANIFOLD, FLOW DIVIDER . . . . . 1 45 MJ06-MAORB06 . . . . . . . . . . . . 2 HOSE, -6 A6/A6 28" . . . . . . . . . . . . 1 ST MJ06-MM14 . . . . . . . . . . . . . . . . 4 TE MJ06 MJ06 FJS06. . . . . . . . . . . 2 HOSE, -4 A6/A6 25" . . . . . . . . . . . . 1 90 MJ06 FJS06 . . . . . . . . . . . . . . . . 2 HOSE, -4 A6/A6 25" . . . . . . . . . . . . 1 HOSE, -4 A4/A4 66" . . . . . . . . . . . . 1 ST MJ08-MM18 . . . . . . . . . . . . . . . . 2 90 MJ08-FJS08 . . . . . . . . . . . . . . . . 2

Item No. 12 13 14 15 16 17 18 19 20 21 22

101

Part No. 103319 L69747 230-32195 104111 50381095 50380743 L70428 210828 L63387 054626 101882

Description

Qty. Req.

HOSE, -6 A6/A8 22" . . . . . . . . . . . . 1 VALVE, STEER SELECT . . . . . . . . 1 ST MJ04-MORB04 . . . . . . . . . . . . . 2 HOSE, -4 A4/A4 18" . . . . . . . . . . . . 1 ST MJ04-M12x1 DIN FL 74235. . . . 1 BRAKE CYL. SINGLE TANDEM . . . 1 MANIFOLD, BRAKE LINE. . . . . . . . 1 SWITCH, PRESSURE 150 PSI. . . . 1 HOSE, -6 A8/DS8 67" . . . . . . . . . . . 1 ST MJ08-MORB08 . . . . . . . . . . . . . 1 STEER MOTOR/17.9 DYNAMIC. . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Axle

RS6-34 Telescopic Handler

Brake and Steering Circuit - Rear Axle

R

1

2

3

Steer motor also shown on page 26.

Steer select also shown on page 26.

19

P

21

4

3

18 20

Brake valve circuit shown on page 30.

5 A

6 B

17

16

6 7

SERVICE BRAKE

8

15

14 11

12

13

11 10 7 10

9

8

9

50960084/AP0914

102

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Axle Brake and Steering Circuit - Rear Axle

Item No. 01 02 03 04 05 06 07 08 09 10 11

Part No. 101882 054626 L63387 079026 L69747 054994 50304898 50304898 088442 100011 L66139

PRINTED IN U.S.A.

Description

Qty. Req.

STEER MOTOR/17.9 DYNAMIC. . . 1 ST MJ08-MORB08 . . . . . . . . . . . . . 1 HOSE, -6 A8/DS8 67" . . . . . . . . . . . 1 45 MJ06-MAORB06 . . . . . . . . . . . . 1 VALVE, STEER SELECT . . . . . . . . 1 ST MJ06-MORBO6 . . . . . . . . . . . . . 2 HOSE, -6 x 115" . . . . . . . . . . . . . . . 1 HOSE, -6 x 115" . . . . . . . . . . . . . . . 1 90 MJ08-FJS08 . . . . . . . . . . . . . . . . 2 ST MJ08-MM18 . . . . . . . . . . . . . . . . 2 ST MJ06-MM14 . . . . . . . . . . . . . . . . 2

Item No. 12 13 14 15 16 17 18 19 20 21

103

Part No. 091039 L69928 095457 102840 50381095 104111 L70428 210828 230-32195 50380743

Description

Qty. Req.

90 MJ06 FJS06 . . . . . . . . . . . . . . . . 1 HOSE, -4 A6/A6 25" . . . . . . . . . . . . 1 TE MJ06 MJ06 FJS06. . . . . . . . . . . 1 HOSE, -4 A4/A6 90" . . . . . . . . . . . . 1 ST MJ04-M12x1 DIN FL 74235. . . . 1 HOSE, -4 A4/A4 18" . . . . . . . . . . . . 1 MANIFOLD, BRAKE LINE. . . . . . . . 1 SWITCH, PRESSURE 150 PSI. . . . 1 ST MJ04-MORB04 . . . . . . . . . . . . . 2 BRAKE CYL. SINGLE TANDEM . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Axle

RS6-34 Telescopic Handler

Front Axle - Steer Cylinder and Tie Rods Group

RIGHT 1

2

3

LEFT

50220268 TIE ROD NUT

Item No.

Part No.

01

50220265

02

50220264 50220267 L500539

03

50220266

50960084/AP0914

Description

Qty. Req.

ARTICULATED TIE ROD . . . . . . . . 1 (includes tie rod nut) (Right [Front Axle], Left [Rear Axle]) STEER CYLINDER . . . . . . . . . . . . . 1 SEAL KIT (not shown) . . . . . . . . . . . 1 STEER CYLINDER BOLT . . . . . . . 4 (not shown) ARTICULATED TIE ROD . . . . . . . . 1 (includes tie rod nut) (Left [Front Axle], Right [Rear Axle])

104

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Axle

Rear Axle - Steer Cylinder and Tie Rods Group

LEFT

1

2

3

RIGHT

50220268 TIE ROD NUT

Item No.

Part No.

01

50220265

02

50220264 50220267 L500539

03

50220266

PRINTED IN U.S.A.

Description

Qty. Req.

ARTICULATED TIE ROD . . . . . . . . 1 (includes tie rod nut) (Right [Front Axle], Left [Rear Axle]) STEER CYLINDER . . . . . . . . . . . . . 1 SEAL KIT (not shown) . . . . . . . . . . . 1 STEER CYLINDER BOLT . . . . . . . 4 (not shown) ARTICULATED TIE ROD . . . . . . . . 1 (includes tie rod nut) (Left [Front Axle], Right [Rear Axle])

105

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Axle

RS6-34 Telescopic Handler

Front Axle - Differential Housing Group

Item No. 01 02 03 04 05

Part No. L98417 L500451 102573 104518 L500454

50960084/AP0914

Description

Qty. Req.

O-RING . . . . . . . . . . . . . . . . . . . . . . 3 INTERMEDIATE COVER . . . . . . . . 1 HOUSING . . . . . . . . . . . . . . . . . . . . 1 COVER . . . . . . . . . . . . . . . . . . . . . . 1 VENT . . . . . . . . . . . . . . . . . . . . . . . . 1

Item No.

Part No.

06 07 08 09

NA 102575 102576 L98373

106

Description

Qty. Req.

.............................0 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 1 MAGNETIC PLUG. . . . . . . . . . . . . . 1 SNAP RING . . . . . . . . . . . . . . . . . . . 1

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Axle Rear Axle - Differential Housing Group

2 4

3

5

6

7 1 8

6

1

1

Item No. 01 02 03 04

Part No. L98417 L500451 L500452 L500453

PRINTED IN U.S.A.

Description

Qty. Req.

O-RING . . . . . . . . . . . . . . . . . . . . . . 3 INTERMEDIATE COVER . . . . . . . . 1 HOUSING . . . . . . . . . . . . . . . . . . . . 1 COVER . . . . . . . . . . . . . . . . . . . . . . 1

Item No.

Part No.

05 06 07 08

L500454 L500455 L98318 102576

107

Description

Qty. Req.

VENT . . . . . . . . . . . . . . . . . . . . . . . . 1 SEAL WASHER . . . . . . . . . . . . . . . . 2 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 1 MAGNETIC PLUG. . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Axle

RS6-34 Telescopic Handler

Front Axle - Brake Group

1 23

2

22

4

25 26

5

19

10 3

18 6

14

7

8

9 11 21

20 17

12 13 15

16 24

Item No. 01 02 03 04 05 06 07 08 09 10 11 12 13 14

Part No. 102617 102618 102619 102620 102621 102622 102623 L98368 102624 102625 102626 102627 102628 L500527

50960084/AP0914

Description

Qty. Req.

SPACER . . . . . . . . . . . . . . . . . . . . . 2 SPRING . . . . . . . . . . . . . . . . . . . . . . 4 PISTON . . . . . . . . . . . . . . . . . . . . . . 2 O-RING . . . . . . . . . . . . . . . . . . . . . . 2 O-RING . . . . . . . . . . . . . . . . . . . . . . 4 BACKUP RING . . . . . . . . . . . . . . . . 4 COVER . . . . . . . . . . . . . . . . . . . . . . 2 O-RING . . . . . . . . . . . . . . . . . . . . . . 2 BACKUP RING . . . . . . . . . . . . . . . . 2 PISTON . . . . . . . . . . . . . . . . . . . . . . 2 INTERMEDIATE BRAKE DISC . . . . 2 SPRING . . . . . . . . . . . . . . . . . . . . . . 6 ADJUSTING BOLT . . . . . . . . . . . . . 6 BRAKE DISC. . . . . . . . . . . . . . . . . . 6

Item No. 15 16 17 18 19 20 21 22 23 24 25 26

108

Part No. L500536 103390 103391 103392 102632 102633 102634 104655 L500496 102635 102636 102637 104621 104607

Description

Qty. Req.

INTERMEDIATE BRAKE DISC . . . . 6 SPACER . . . . . . . . . . . . . . . . . . . . . 2 BOLT . . . . . . . . . . . . . . . . . . . . . . . . 4 ADJUSTING BOLT . . . . . . . . . . . . . 6 SPRING . . . . . . . . . . . . . . . . . . . . . . 6 NUT . . . . . . . . . . . . . . . . . . . . . . . . . 4 LOCK WASHER . . . . . . . . . . . . . . . 4 BLEEDING BOLT . . . . . . . . . . . . . . 4 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 4 SHIM (2mm) . . . . . . . . . . . . . . . . . . 2 SHIM (3mm) . . . . . . . . . . . . . . . . . . 2 SHIM (5mm) . . . . . . . . . . . . . . . . . . 2 BOLT . . . . . . . . . . . . . . . . . . . . . . . . 4 SEAL WASHER . . . . . . . . . . . . . . . . 4

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Axle Rear Axle - Brake Group

10

2 3 1

4 5

12 14 11 6 7 9 8 13

Item No. 01 02 03 04 05 06 07 08

Part No. L500527 L500528 L500529 NSS L500531 L500532 L500533 L500534

PRINTED IN U.S.A.

Description

Qty. Req.

BRAKE DISC. . . . . . . . . . . . . . . . . . 6 ADJUSTING BOLT . . . . . . . . . . . . . 6 SPRING . . . . . . . . . . . . . . . . . . . . . . 6 PISTON . . . . . . . . . . . . . . . . . . . . . . 2 SPRING . . . . . . . . . . . . . . . . . . . . . . 6 BACK-UP RING. . . . . . . . . . . . . . . . 2 O-RING . . . . . . . . . . . . . . . . . . . . . . 2 BACK-UP RING. . . . . . . . . . . . . . . . 2

Item No.

Part No.

09 10 11 12 13 14

L500535 L500536 104655 L500496 L500537 L500538

109

Description

Qty. Req.

O-RING . . . . . . . . . . . . . . . . . . . . . . 2 INTERMEDIATE BRAKE DISC . . . . 8 BLEEDING BOLT . . . . . . . . . . . . . . 2 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 2 DOWEL . . . . . . . . . . . . . . . . . . . . . . 2 PISTON . . . . . . . . . . . . . . . . . . . . . . 2 (includes items 3,4, 6-9)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Axle

RS6-34 Telescopic Handler

Front Axle - Outer End Group

4

5

5 6

FRONT

3 1 2

8

31 9

7 10

30 FRONT AXLE

20

11

21

23

12 13

22

16

14

24

15

25 27 28

26 29 30, 31 35

37 17

36 38

18 39

33

19

36

27

41

29

42

32

34

44 43

24

45 46

23 40

47

51 50 49

50960084/AP0914

110

48

8

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Axle Front Axle - Outer End Group

Item No. 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26

Part No. L500483 L500484 103394 102614 L500487 102615 103393 102575 102576 L500488 L98372 L98373 L98371 L500489 L500490 103395 NSS 105958 L500492 102587 102583 102893 L500496 L98355 103398 L500523 L500524 L500525

PRINTED IN U.S.A.

Description

Qty. Req.

NUT . . . . . . . . . . . . . . . . . . . . . . . . . 2 BOLT . . . . . . . . . . . . . . . . . . . . . . . . 2 BOLT . . . . . . . . . . . . . . . . . . . . . . . 24 STUD . . . . . . . . . . . . . . . . . . . . . . . . 8 WASHER . . . . . . . . . . . . . . . . . . . . 32 NUT . . . . . . . . . . . . . . . . . . . . . . . . . 8 AXLE CASE. . . . . . . . . . . . . . . . . . . 2 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 4 MAGNET PLUG. . . . . . . . . . . . . . . . 2 REDUCTION BUSHING (set) . . . . . 2 SNAP RING . . . . . . . . . . . . . . . . . . . 2 SNAP RING . . . . . . . . . . . . . . . . . . . 2 BALL BEARING. . . . . . . . . . . . . . . . 2 SEAL . . . . . . . . . . . . . . . . . . . . . . . . 2 O-RING . . . . . . . . . . . . . . . . . . . . . . 2 JOINT . . . . . . . . . . . . . . . . . . . . . . . 2 (included as part of item 18) . . . . . . 0 SEAL/DUST EXCLUDER . . . . . . . . 2 THRUST BUSHING. . . . . . . . . . . . . 2 NUT . . . . . . . . . . . . . . . . . . . . . . . . . 5 WASHER . . . . . . . . . . . . . . . . . . . . . 8 STUD . . . . . . . . . . . . . . . . . . . . . . . . 8 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 4 GREASE FITTING. . . . . . . . . . . . . . 4 PIVOT PIN . . . . . . . . . . . . . . . . . . . . 2 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 2 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 2 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 2

Item No.

Part No.

27 28 29 30

NSS 103396 L500499 L500501

31

L500504

32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49

L500498 L500500 L500494 L500505 104604 102601 L500508 L98417 L500519 L500509 L500510 L500522 104600 104641 104642 103399 104504 103401

50 51

L500518 L500517

111

Description

Qty. Req.

(not used on this axle) . . . . . . . . . . . 0 BUSHING . . . . . . . . . . . . . . . . . . . . 2 SEAL . . . . . . . . . . . . . . . . . . . . . . . . 4 STEERING CASE . . . . . . . . . . . . . . 1 (includes item 19) STEERING CASE . . . . . . . . . . . . . . 1 (includes item 19) PIVOT PIN (set). . . . . . . . . . . . . . . . 2 BEARING. . . . . . . . . . . . . . . . . . . . . 2 BOLT . . . . . . . . . . . . . . . . . . . . . . . 12 SEAL . . . . . . . . . . . . . . . . . . . . . . . . 2 BEARING. . . . . . . . . . . . . . . . . . . . . 4 WHEEL STUD . . . . . . . . . . . . . . . . 16 WHEEL HUB . . . . . . . . . . . . . . . . . . 2 O-RING . . . . . . . . . . . . . . . . . . . . . . 2 SNAP RING . . . . . . . . . . . . . . . . . . . 2 RING GEAR . . . . . . . . . . . . . . . . . . 2 RING GEAR SUPPORT . . . . . . . . . 2 LOCKING PLATE . . . . . . . . . . . . . . 2 SNAP RING . . . . . . . . . . . . . . . . . . . 8 PLANET GEAR . . . . . . . . . . . . . . . . 8 BEARING. . . . . . . . . . . . . . . . . . . . . 8 PLANET GEAR CARRIER . . . . . . . 2 COUNTERSUNK BOLT. . . . . . . . . . 4 PLANET GEAR CARRIER . . . . . . . 2 (includes items 41-48) NUT . . . . . . . . . . . . . . . . . . . . . . . . 16 STUD . . . . . . . . . . . . . . . . . . . . . . . 16

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Axle

RS6-34 Telescopic Handler

Front Axle - Differential Group

50960084/AP0914

112

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Axle Front Axle - Differential Group

Item No. 01 02

Part No.

03 04 05 06 07 08 09 10a

L500457 L500459 L500460 L500461 L98414 L500463 L98380 L500464 L500465 L500466 L500467 L500468 105266

11 12

103402 L500471

Description

Qty. Req.

O-RING . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 BEVEL GEAR SET . . . . . . . . . . . . . 1 TAPER ROLLER BEARING . . . . . . 2 RING NUT . . . . . . . . . . . . . . . . . . . . 2 CYLINDER BOLT . . . . . . . . . . . . . . 4 CYLINDER BOLT . . . . . . . . . . . . . . 2 BOLT . . . . . . . . . . . . . . . . . . . . . . . 12 FRICTION WASHER . . . . . . . . . . . . 2 DIFFERENTIAL PINION GEAR . . . 1 (DIFFERENTIAL SIDE GEAR KIT) PIN. . . . . . . . . . . . . . . . . . . . . . . . . . 4 SNAP RING . . . . . . . . . . . . . . . . . . . 4

Item No.

Part No.

13 14b

L500472 105266

15 16 17

L500474 L500475 L98404 L98406 L500476 L500477 L500478 L98396 L98395 102863 L500480 L500481

18 19 20 22 23 24 a

PRINTED IN U.S.A.

113

Description

Qty. Req.

FRICTION WASHER . . . . . . . . . . . . 4 DIFFERENTIAL PINION GEAR . . . 1 (DIFFERENTIAL SIDE GEAR KIT) DIFFERENTIAL CARRIER . . . . . . . 1 TAPER ROLLER BEARING . . . . . . 2 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SPACER . . . . . . . . . . . . . . . . . . . . . 1 RING NUT . . . . . . . . . . . . . . . . . . . . 1 SEAL . . . . . . . . . . . . . . . . . . . . . . . . 1 FLANGE . . . . . . . . . . . . . . . . . . . . . 1 NUT . . . . . . . . . . . . . . . . . . . . . . . . . 1 SNAP RING . . . . . . . . . . . . . . . . . . . 4

Differential gear kit #105266 includes 2 of item #10 (L500469) and 4 of item #14 (L500473).

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Axle

RS6-34 Telescopic Handler

Rear Axle - Outer End Group

FRONT

5 3

4 1 2

25

14 8 15 47 7 16 6 17

13

10

49

12

24

9

19 21,26 27 28

29 30 31

2 20 1

45 48

11

28

19 44

22 32

18

13

33

16

46

15

34

35 36 50

43

37

38 41 42

FRONT

40

39

25

21

26 REAR AXLE

50960084/AP0914

114

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Axle Rear Axle - Outer End Group

Item No.

Part No.

01 02 03 04 05

L500483 L500484 L500485 L500486 L500488

06 07 07 09 10 11

L500489 L98371 L98372 L500490 L500491 L500492

12 13 14 15 16 17

L500493 L500494 L500495 L500496 L98355 L500497

18

L500498

19 20 21

L500499 L500500 L500501

22 24 25

105958 102576 L98318

PRINTED IN U.S.A.

Description

Qty. Req.

NUT . . . . . . . . . . . . . . . . . . . . . . . . . 2 STEERING ADJUST BOLT . . . . . . . 2 AXLE CASE. . . . . . . . . . . . . . . . . . . 2 BOLT . . . . . . . . . . . . . . . . . . . . . . . 32 REDUCTION BUSHING . . . . . . . . . 2 (includes items 6-9, and 47) SEAL . . . . . . . . . . . . . . . . . . . . . . . . 2 BALL BEARING. . . . . . . . . . . . . . . . 2 SNAP RING . . . . . . . . . . . . . . . . . . . 2 O-RING . . . . . . . . . . . . . . . . . . . . . . 2 JOINT . . . . . . . . . . . . . . . . . . . . . . . 2 THRUST BUSHING. . . . . . . . . . . . . 2 (included with items 21 and 26) OUTER RACE . . . . . . . . . . . . . . . . . 2 BOLT . . . . . . . . . . . . . . . . . . . . . . . 20 COVER . . . . . . . . . . . . . . . . . . . . . . 2 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 4 GREASE FITTING. . . . . . . . . . . . . . 2 PIVOT PIN . . . . . . . . . . . . . . . . . . . . 2 (includes item 16) PIVOT PIN . . . . . . . . . . . . . . . . . . . . 2 (includes items 16, 19 and 20) SEAL . . . . . . . . . . . . . . . . . . . . . . . . 2 ARTICULATION. . . . . . . . . . . . . . . . 2 STEERING CASE . . . . . . . . . . . . . . 1 (includes item 11) SEAL . . . . . . . . . . . . . . . . . . . . . . . . 2 MAGNETIC PLUG. . . . . . . . . . . . . . 2 PLUG . . . . . . . . . . . . . . . . . . . . . . . . 4

Item No.

Part No.

26

L500504

27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49

L500505 104604 L500507 L500508 L98417 L500509 L500510 104600 104641 104642 L69734 L500455 104504 L500516 L500517 L500518 L500519 104546 NSS L500522 L98373 L500555 L500523 L500524 L500525 103401

50

115

Description

Qty. Req.

STEERING CASE . . . . . . . . . . . . . . 1 (includes item 11) SEAL . . . . . . . . . . . . . . . . . . . . . . . . 2 BEARING. . . . . . . . . . . . . . . . . . . . . 4 WHEEL STUD . . . . . . . . . . . . . . . . 16 WHEEL HUB . . . . . . . . . . . . . . . . . . 2 O-RING . . . . . . . . . . . . . . . . . . . . . . 2 RING GEAR . . . . . . . . . . . . . . . . . . 2 RING GEAR SUPPORT . . . . . . . . . 2 SNAP RING . . . . . . . . . . . . . . . . . . . 8 PLANET GEAR . . . . . . . . . . . . . . . . 8 BEARING. . . . . . . . . . . . . . . . . . . . . 8 WHEEL NUT . . . . . . . . . . . . . . . . . 16 SEAL WASHER . . . . . . . . . . . . . . . . 6 COUNTERSUNK BOLT. . . . . . . . . . 4 PLANET GEAR CARRIER . . . . . . . 2 STUD . . . . . . . . . . . . . . . . . . . . . . . 16 NUT . . . . . . . . . . . . . . . . . . . . . . . . 16 SNAP RING . . . . . . . . . . . . . . . . . . . 2 ADJUSTING BOLT (includes #45) . 4 NUT (included with item #44) . . . . . 4 LOCKING PLATE . . . . . . . . . . . . . . 2 SNAP RING . . . . . . . . . . . . . . . . . . . 2 SPACER . . . . . . . . . . . . . . . . . . . . . 2 SHIM - .15mm . . . . . . . . . . . . . . . . . 2 SHIM - .20mm . . . . . . . . . . . . . . . . . 2 SHIM - .50mm . . . . . . . . . . . . . . . . . 2 PLANET GEAR CARRIER . . . . . . . 2 (includes items 32-36, 40-41)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Axle

RS6-34 Telescopic Handler

Rear Axle - Differential Group

7

8

6

24

12

13

11

10

14

12 24

5 4 16

24

3

18

9 11 12

13

12 24

22

21

7

13

14 11

20

15 4

13

16

11

9 5

1

17 2

23

50960084/AP0914

19

116

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Axle Rear Axle - Differential Group

Item No. 01 02

Part No.

03 04 05 06 07 08 09 10a

L500457 L98415 L500459 L500460 L500461 L98414 L500463 L98380 L500464 L500465 L500466 L500467 L500468 105266

11 12

L500470 L500471

Description

Qty. Req.

O-RING . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 BEVEL GEAR SET . . . . . . . . . . . . . 1 TAPER ROLLER BEARING . . . . . . 2 RING NUT . . . . . . . . . . . . . . . . . . . . 2 CYLINDER BOLT . . . . . . . . . . . . . . 4 CYLINDER BOLT . . . . . . . . . . . . . . 2 BOLT . . . . . . . . . . . . . . . . . . . . . . . 12 FRICTION WASHER . . . . . . . . . . . . 2 DIFFERENTIAL PINION GEAR . . . 1 (DIFFERENTIAL SIDE GEAR KIT) PIN W/CLIP (includes item 12) . . . . 4 SNAP RING . . . . . . . . . . . . . . . . . . . 4

Item No.

Part No.

13 14a

L500472 105266

15 16 17

L500474 L500771 L98404 L98406 L500476 L500477 L500478 L98396 L98395 L98394 102863 L500480 L500481

18 19 20 21 22 23 24 a

PRINTED IN U.S.A.

117

Description

Qty. Req.

FRICTION WASHER . . . . . . . . . . . . 4 DIFFERENTIAL PINION GEAR . . . 1 (DIFFERENTIAL SIDE GEAR KIT) DIFFERENTIAL CARRIER . . . . . . . 1 TAPER ROLLER BEARING . . . . . . 2 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SHIM . . . . . . . . . . . . . . . . . . . . . . . . 1 SPACER . . . . . . . . . . . . . . . . . . . . . 1 RING NUT . . . . . . . . . . . . . . . . . . . . 1 SEAL . . . . . . . . . . . . . . . . . . . . . . . . 1 COVERPLATE. . . . . . . . . . . . . . . . . 1 FLANGE . . . . . . . . . . . . . . . . . . . . . 1 NUT . . . . . . . . . . . . . . . . . . . . . . . . . 1 SNAP RING . . . . . . . . . . . . . . . . . . . 4

Differential Gear Kit #105266 includes 2 of item #10 (L500469) and 4 of item #14 (L500473).

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Boom

RS6-34 Telescopic Handler

Outer Boom Section

Boom chains are on page 122.

32

Boom hoses begin on page 128.

1

FRONT 33

27 30

35

34

10

2

31

3

36 45

4

5 6

27 29

28

44

7

42 43

B

B 23

8

24

9

27 25

26

22

25

10

12 11

21

13

14

15

15

REAR

16

50960084/AP0914

118

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Boom Outer Boom Section

Item No. 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 21 22 23 24

Part No.

Description

L68350 L70242 L65640 654004 L52048 L65638 651271 650549 L50380 654030 655001 L63169 L63173 L63131 L50226 L68006 L68003 L63099 L50462 068034 L63694 650490 654026 L61708 L62715

Qty. Req.

BOOM, OUTER . . . . . . . . . . . . . . . . 1 5/16”-18 NUTSERT . . . . . . . . . . . . . 2 PLATE, BOOM ANGLE IND.. . . . . . 1 5/16” FLAT WASHER . . . . . . . . . . . 2 BUTTON HD 5/16”-18X1” SS . . . . . 2 INCLINOMETER-ANGLE IND. . . . . 1 #8-32X3/8” HHM USL CZY . . . . . . . 2 #10 FW (not shown) . . . . . . . . . . . . 2 1/2”-20X1-1/4” BOLT . . . . . . . . . . . . 2 1/2” LOCK WASHER . . . . . . . . . . . . 2 PIN, COTTER 1/16”X3/4” . . . . . . . . 6 PIN, OUTER BOOM CLEVIS . . . . . 1 CLEVIS, OUTER BOOM . . . . . . . . . 1 REAR OUTER COVER . . . . . . . . . . 1 5/16”-18X1” SELF TAP SCREW . . . 4 BUSHING 2.5IDX2.75ODX4” . . . . . 2 LIFT CYLINDER PIVOT BUSHING. 2 PIN, PIVOT PIN. . . . . . . . . . . . . . . . 1 1/2”-13X5 BOLT (not shown) . . . . . 1 HLN INST 1/2 CZY (not shown) . . . 1 EXTEND CYLINDER BRACKET. . . 1 3/8”-16X1” BOLT (not shown) . . . . 2 3/8” LOCK WASHER (not shown) . 2 SLIDE PAD 5/8”X4”X6” . . . . . . . . . . 2 FLAT-BOLT LOCK . . . . . . . . . . . . . . 2

Item No.

Part No.

Description

Qty. Req.

25 26 27 28 29 30 31 32 33 34a 35 36 37b 38b 39b 40b 41b 42 43 44 45

650488 650490 654026 L61709 L62733 650491 L64143 650533 L63167 L63166 L50086 L71748 103333 L70040 654006 090666 650491 103330 103331 L50056 L51035

3/8”-16X3/4” BOLT . . . . . . . . . . . . . 6 3/8”-16X1” BOLT . . . . . . . . . . . . . . . 2 3/8” LOCK WASHER . . . . . . . . . . . 12 SLIDE PAD 5/8”X3”X4” . . . . . . . . . . 4 SHIM .06”X3”X4” . . . . . . . . . . . . . . . 2 3/8”-16X1-1/4” BOLT . . . . . . . . . . . . 4 SHIM 1/2”X3”X4” . . . . . . . . . . . . . . . 2 3/8”-16X1-1/2” BOLT . . . . . . . . . . . . 4 PIN, CLEVIS ADJUSTMENT. . . . . . 2 CLEVIS, CHAIN ADJUSTMENT . . . 2 3/4”-10 NUT. . . . . . . . . . . . . . . . . . . 4 TOP CLAMP PLATE . . . . . . . . . . . . 1 BRACKET, LIGHT MOUNT . . . . . . . 1 WORK LIGHT . . . . . . . . . . . . . . . . . 2 3/8” FLAT WASHER . . . . . . . . . . . . 4 3/8”-16 WHIZ LOCK NUT . . . . . . . . 4 3/8”-16X1-1/4” BOLT . . . . . . . . . . . . 2 CLAMP, BOOM HOSES . . . . . . . . AR CLAMP, BOOM W/INSERT . . . . . AR 5/16” FLANGE LOCK NUT. . . . . . AR 5/16”X2” BOLT . . . . . . . . . . . . . . . AR

00b

L70462

--- ITEMS NOT SHOWN --WIRE HARNESS, WORK LIGHT . . 1

a b

Refer to page 122 for boom chains.

When equipped with Optional Boom Work Lights.

(Refer to illustration below.)

38

B 39

40

40 41

Boom Work Lights (Option)

39

37

(mounts to front of boom; reference B on facing page)

PRINTED IN U.S.A.

119

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Boom

RS6-34 Telescopic Handler

Intermediate Boom Section 12 8 13

11

10

14

9

1

8 2 3 7

FRONT

4 5

6

15 16 17 18

19 21

20 17 16 19

Boom chains are on page 122.

12 8

11 10

22

9 8 27

13

23 2

24 28

25

29

26

16 21

19 17 19 17

21

16 19 16 1

50960084/AP0914

120

21

REAR

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Boom Intermediate Boom Section

Item No. 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15

Part No. L68744 L63006 650484 L50207 L520004 067847 651625 L68697 L63158 L63157 L63153 650493 067847 L68695 650490

Description

Qty. Req.

INTERMEDIATE SECT WLDMNT. . 1 TRAY, INTERMEDIATE . . . . . . . . . . 1 5/16”-18X1/2” BOLT . . . . . . . . . . . . 1 CLAMP, VINYL .69 DBL . . . . . . . . . 1 5/16”X18 NYLON INSERT NUT . . . 1 HLN INST 3/8 CZY . . . . . . . . . . . . . 2 3/8”-16X1-1/4” BOLT . . . . . . . . . . . . 2 WASHER, CHAIN SHEAVE . . . . . . 6 RING, BEARING-INNER . . . . . . . . . 3 BEARING, BOOM SHEAVE . . . . . . 3 SHEAVE, CHAIN . . . . . . . . . . . . . . . 3 3/8”-16X2-3/4” BOLT . . . . . . . . . . . . 2 HLN INST 3/8 CZY . . . . . . . . . . . . . 2 PIN, FRONT SHEAVE . . . . . . . . . . . 1 3/8”-16X1” BOLT . . . . . . . . . . . . . . . 4

Item No.

Part No.

16 17 18 19 20 21 22 23 24 25 26 27 28 29

L62715 L62734 L62733 650488 654026 L61709 650533 654026 L68696 L63239 L61699 L61708 L62731 L62732

Description

Qty. Req.

FLAT-BOLT LOCK . . . . . . . . . . . . . 12 SHIM, .105”X3”X4” . . . . . . . . . . . . . 8 SHIM, .06”X3”X4” . . . . . . . . . . . . . . 2 3/8”-16X3/4” BOLT . . . . . . . . . . . . 28 3/8” LOCK WASHER . . . . . . . . . . . . 8 SLIDE PAD, 5/8”X3”X4”. . . . . . . . . 12 3/8”-16X1-1/2” BOLT . . . . . . . . . . . . 1 3/8” LOCK WASHER . . . . . . . . . . . . 1 PIN, REAR SHEAVE . . . . . . . . . . . . 1 SPACER, TRAY BRACKET. . . . . . . 1 SLIDE PAD, 2”X3” . . . . . . . . . . . . . . 1 SLIDE PAD, 5/8”X4”X6”. . . . . . . . . . 2 SHIM, .06”X4”X6” . . . . . . . . . . . . . . 2 SHIM, .105”X4”X6” . . . . . . . . . . . . . 2

NOTE: Refer to page 122 for boom chains.

PRINTED IN U.S.A.

121

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Boom

RS6-34 Telescopic Handler

Inner Boom Section

30

3 5

REAR

Boom hoses begin on page 128.

14

6

8

17

15

12

7 29 1

16

13 9 10 11

18

2 19

7 4

21

28 27

20

10 7

26

9

11 25

9

24 23

Refer to note c on facing page.

22

22

FRONT

50960084/AP0914

122

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Boom Inner Boom Section

Item No. 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15a 16 17 18b 19 20 21 22

Part No. L68762 L63005 L71748 L61699 103330 103331 650488 654026 L61709 L62734 L62715 L66783 L66782 L66780 L63156 655001 L63168 L63156 L63166 L63167 L50086 L68003

PRINTED IN U.S.A.

Description

Qty. Req.

INNER BOOM WELDMENT . . . . . . 1 HOSE TRAY, INNER BOOM . . . . . . 1 TOP PLATE, HOSE CLAMP . . . . . . 1 SLIDE PAD 2”X3” . . . . . . . . . . . . . . 1 CLAMP, BOOM HOSES . . . . . . . . . 1 CLAMP, BOOM W/INSERT . . . . . . 1 3/8”-16X3/4” BOLT . . . . . . . . . . . . 17 3/8” LOCK WASHER . . . . . . . . . . . . 1 SLIDE PAD 5/8”X3”X4” . . . . . . . . . . 4 SHIM .105”X3”X4” . . . . . . . . . . . . . . 2 FLAT-BOLT LOCK . . . . . . . . . . . . . . 8 SHIM .105”X3”X8” . . . . . . . . . . . . . . 2 SHIM .06”X3”X8” . . . . . . . . . . . . . . . 2 SLIDE PAD 3”x8”. . . . . . . . . . . . . . . 2 CHAIN, BOOM LEAF . . . . . . . . . . . 2 PIN, COTTER 1/16”X3/4” . . . . . . . . 4 PIN, INNER BOOM CLEVIS . . . . . . 1 CHAIN, BOOM LEAF . . . . . . . . . . . 1 CLEVIS, CHAIN ADJUSTMENT . . . 1 PIN, CLEVIS ADJUSTMENT. . . . . . 1 3/4”-10 NUT. . . . . . . . . . . . . . . . . . . 2 BUSHING . . . . . . . . . . . . . . . . . . . . 2

Item No.

Part No.

23c 24c 25 26c 27 28 29 30

L50877 L63716 L63715 L520004 067847 651625 L50056 L51035

a

Attaches from the rear of the inner boom to the chain adjustment clevis’ located on the front of the outer boom section. (Refer to Outer Boom Section, item #34, chain adjustment clevis.)

b

Attaches from item #19 (chain adjustment clevis) to outer boom clevis. (Refer to Outer Boom Section, item #12, outer boom clevis.)

c

If the machine is equipped with optional auxiliary hydraulics, items #23 and #26 are not used; instead there will be (2) 650784 5/16" x 2-3/4" bolts, (2) 654024 5/16" lock washers, and two additional hose cushions (#24).

123

Description

Qty. Req.

5/16”-18X2-1/4” STUD. . . . . . . . . . . 2 CUSHION, HOSE-TWIN .68 . . . . . . 2 PLATE, TWIN CUSHION TOP . . . . 1 HLN INST 5/16" . . . . . . . . . . . . . . . . 2 HLN INST 3/8 CZY . . . . . . . . . . . . . 2 BH CS 3/8”-1-1/4” . . . . . . . . . . . . . . 2 5/16” FLANGE LOCK NUT. . . . . . AR 5/16”X2” BOLT . . . . . . . . . . . . . . . AR

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Boom

RS6-34 Telescopic Handler

Dynattach® Bracket Assembly

3 1 14

2

4

5

13

Tilt Cylinder

3 6 7

9 12

2 11 10

Tilt Cylinder parts are on page 190.

9

15

50960084/AP0914

124

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Boom Dynattach® Bracket Assembly

Item No.

Part No.

01

L98700

02 03 04 05 06 07 09 10a

067847 650493 L63274 L68003 L63272 L63018 L66456 NSS

PRINTED IN U.S.A.

Description

Qty. Req.

DYNATTACH WELDMENT . . . . . . . 1 (includes items 9, and 12-15) HLN INST 3/8 CZY . . . . . . . . . . . . . 3 3/8”-16X2-3/4” BOLT . . . . . . . . . . . . 3 PIN, TAPPED 1-1/2” DIA . . . . . . . . . 2 BUSHING . . . . . . . . . . . . . . . . . . . . 2 PIN, TILT CYL.(ROD END) . . . . . . . 1 BUSHING, TILT CYL (ROD END) . . 1 BUSHING, LOCK PIN . . . . . . . . . . . 2 PIN, DYNATTACH LOCK . . . . . . . . 1

Item No.

Part No.

11a 12 13 14 15

NSS L50646 L65097 L65098 L63957

--

L66613

a

Not sold separately; order item #15.

125

Description

Qty. Req.

DYNATTACH LOCK WLDMNT . . . . 1 3/16”X1-3/4” ROLL PIN . . . . . . . . . . 1 LOCK SPRING . . . . . . . . . . . . . . . . 1 SPRING MOUNT. . . . . . . . . . . . . . . 1 LOCK AND PIN ASSEMBLY . . . . . . 1 (includes items 10-11) -- ITEMS NOT SHOWN -DECAL, DYNATTACH UNLOCKED 1 (adheres to item #11)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Boom Hydraulics

RS6-34 Telescopic Handler

Lift Circuit 4 3 2 1 2

4

1

5

3 6 5

Lift cylinder parts are on page 186.

6 4

7

7

4 7 7

3

1

3

5 EXTEND

8

RETRACT

2

9

EXTEND

5

1

12

RETRACT

13 8 13 9

12

10

11

11

Hydraulic valve parts are on page 168.

FT

126

CT

50960084/AP0914

A TR

ND

TE

EX

Valve circuit is on page 136.

RE

M LI

BOO

10

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Boom Hydraulics Lift Circuit

Item No. 01 02 03 04 05 06 07

Part No. L10057 L68003 L63274 650493 067847 L63199 054816

PRINTED IN U.S.A.

Description

Qty. Req.

ZERK, GREASE . . . . . . . . . . . . . . . 4 BRONZE BUSHING . . . . . . . . . . . . 4 PIN, LIFT CYLINDER . . . . . . . . . . . 4 3/8”-16X2-3/4” BOLT . . . . . . . . . . . . 4 HLN INST 3/8 CZY . . . . . . . . . . . . . 4 CYLINDER, LIFT . . . . . . . . . . . . . . . 2 90 MJ08-MAORB08 . . . . . . . . . . . . 4

Item No.

Part No.

08 09 10 11 12 13

L63407 L63407 076143 076031 L63407 L63407

127

Description

Qty. Req.

HOSE, -6 A8/A8 48” . . . . . . . . . . . . 1 HOSE, -6 A8/A8 48” . . . . . . . . . . . . 1 ADAP -8JICFS -8JICM RUN TEE . . 2 90 MJ08-MAORB10 . . . . . . . . . . . . 2 HOSE, -6 A8/A8 48” . . . . . . . . . . . . 1 HOSE, -6 A8/A8 48” . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Boom Hydraulics

RS6-34 Telescopic Handler

Tilt / Slave Circuit

2 1

16 15 14 13 12

26

25

28 17 7

16

18 5

6

18

3

13

19

27

8

20

8

21

7

22

24

9

10

3 23

5

3

Extend

Retract

23

Extend

7

5

4

FORK TILT

Hydraulic valve parts are on page 168.

2 1

25

Retract

12

11

26

24

15

14

Tilt cylinder parts are on page 190.

Slave cylinder parts are on page 188.

5

7

50960084/AP0914

128

6

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Boom Hydraulics Tilt / Slave Circuit

Item No.

Part No.

01a 02a 03 04 05 06 07 08 09 10 11b 12 13 14 15 16 17 18 19

L68374 L68374 054816 L63013 650493 L63272 067847 L520004 L63715 L63716 L50877 L50056 103331 103330 L71748 L51035 L50877 L68039 L63715

PRINTED IN U.S.A.

Description

Qty. Req.

HOSE, -6 A8/H10 322” . . . . . . . . . . 1 HOSE, -6 A8/H10 322” . . . . . . . . . . 1 ADAP., -8ORM -8JICM 90º . . . . . . . 3 CYLINDER, TILT . . . . . . . . . . . . . . . 1 3/8”-16X2-3/4” BOLT . . . . . . . . . . . . 4 PIN, CYLINDER (rod end). . . . . . . . 2 HLN INST 3/8 CZY . . . . . . . . . . . . . 4 5/16”-18 NYLON INSERT NUT . . . 10 PLATE, TWIN CUSHION. . . . . . . . . 1 CUSHION, HOSE 0.6875 TWIN . . . 2 5/16”-18X2-1/4” STUD. . . . . . . . . . . 2 FLN SERR 5/16" . . . . . . . . . . . . . . . 2 CLAMP, HOSE 0.625 W/INSRT . . . 2 CLAMP, BOOM HOSE 0.625 . . . . . 2 PLATE, CLAMP TOP. . . . . . . . . . . . 2 CS 5/16" x 2" . . . . . . . . . . . . . . . . . . 2 5/16”-18X2-1/4” STUD. . . . . . . . . . . 8 CUSHION, TUBE 0.625 TWIN . . . . 8 PLATE, TWIN CUSHION. . . . . . . . . 4

Item No.

Part No.

Description

Qty. Req.

20 21 22 23 24 25 26 27 28

L63407 L68817 076880 L63273 121387 50380757 50380757 L63014 L68351

a

Both hoses fit inside the protective hose sleeve PN L500784.

b

If the machine is equipped with optional auxiliary hydraulics, items #11 and two of the item #8 are not used; instead there will be (2) 650784 5/16" x 2-3/4" bolts, (2) 654024 5/16" lock washers, and two additional hose cushions (#10). Refer to the auxiliary hydraulics circuit pages for more information.

129

HOSE, -6 A8/A8 48" . . . . . . . . . . . . 1 HOSE, -6 A8/A8 28” . . . . . . . . . . . . 1 45 MJ08 MAORB08. . . . . . . . . . . . . 1 PIN, CYLINDER (base end) . . . . . . 2 TEE MJ08-MAORB10-MJ08 . . . . . . 2 HOSE, -8 x 52" . . . . . . . . . . . . . . . . 1 HOSE, -8 x 52" . . . . . . . . . . . . . . . . 1 CYLINDER, SLAVE . . . . . . . . . . . . . 1 TUBE, TILT/AUX . . . . . . . . . . . . . . . 2

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Boom Hydraulics

RS6-34 Telescopic Handler

Boom Extend Circuit

7

8

4 6

3

7

9

2

8

6 5

9

10

5 Boom Extend cylinder parts are on page 192.

10

1 Hose cushion mounts are welded to the underside of the outer boom and are not a service part.

4 16 2

11

12

13 15

14

Hydraulic valve parts are on page 168.

50960084/AP0914

130

BOOM EXTEND

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Boom Hydraulics Boom Extend Circuit

Item No. 01 02 03 04 05 06 07 08

Part No. L63012 067847 L63273 650493 126862 50380756 650784 L68358

PRINTED IN U.S.A.

Description

Qty. Req.

CYLINDER, BOOM EXTEND . . . . . 1 HLN INST 3/8 CZY . . . . . . . . . . . . . 2 PIN, CYLINDER (base end) . . . . . . 1 CS 3/8”-16x2-3/4” C5ZY . . . . . . . . . 2 90-LL MJ08-MAORB08 . . . . . . . . . . 2 HOSE, -8 x 70" . . . . . . . . . . . . . . . . 2 CS 5/16" x 2-3/4" C5ZY. . . . . . . . . . 4 CUSHION, TOP PLATE. . . . . . . . . . 2

Item No. 09 10 11 12 13 14 15 16

131

Part No. L68348 L520004 50302155 L63272 654026 650490 L63694 570019

Description

Qty. Req.

CUSHION, HOSE 0.875" . . . . . . . . 4 HLN INST 5/16"-18 . . . . . . . . . . . . . 4 ST-L MJ08-MORB10 . . . . . . . . . . . . 2 PIN, CYLINDER (rod end). . . . . . . . 1 LW 3/8" RZY . . . . . . . . . . . . . . . . . . 2 CS 3/8" x 1" C5ZY. . . . . . . . . . . . . . 2 BRACKET, CYLINDER STOP . . . . . 1 FITTING, GREASE 1/4". . . . . . . . . . 2

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Boom Hydraulics

RS6-34 Telescopic Handler

Auxiliary Hydraulics Circuit

1 2 6 16

3 16

15

4

14

14 1

13

15

13

6

Hose cushions and clamps fasten to the front-right side of inner boom.

12 12

2 21

17 18

5

7 7 11 8

10 8

24

19 20

9

23 Inner boom is on page 122.

22 Hydraulic valve parts (including auxiliary section) are on page 168.

Hydraulic valve is shown with the optional auxiliary hydraulics work section.

50960084/AP0914

AUXILIARY HYDRAULIC (Option)

132

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Boom Hydraulics Auxiliary Hydraulics Circuit

Item No.

Part No.

01a 02a 03 04 05 06

L68376 L68376 654024 650784 L63715 L63716

07 08 09 10 11 12

076147 054626 L65273 650448 654002 L50056

PRINTED IN U.S.A.

Description

Qty. Req.

HOSE, -6 A8/H10 352” . . . . . . . . . . 1 HOSE, -6 A8/H10 352” . . . . . . . . . . 1 LW 5/16 RZY . . . . . . . . . . . . . . . . . . 2 CS 5/16”-18X2-3/4” C5ZY . . . . . . . . 2 PLATE, TOP 2.50" . . . . . . . . . . . . . . 1 CUSHION, HOSE 0.69" TWIN . . . . 4 (two for the tilt hoses and two for the auxiliary hydraulics hoses) CLAMP, HOSE 0.50 x 0.41 . . . . . . . 4 ST MJ08-MORB08 . . . . . . . . . . . . . 2 QUICK COUPLER SET. . . . . . . . . . 1 CS 1/4 x 3/4 C5ZY . . . . . . . . . . . . . 2 FW 1/4 AWZY . . . . . . . . . . . . . . . . . 2 FLN SERR 5/16" . . . . . . . . . . . . . . . 2

Item No.

Part No.

Description

Qty. Req.

13 14 15 16 17 18 19 20 21 22 23 24

103331 103330 L71748 L51035 L50877 L68039 L63715 L520004 L68351 50302155 50380757 50380757

a

Used with protective fabric sleeve PN L500784.

133

CLAMP, HOSE 0.625 W/INSRT . . . 2 CLAMP, BOOM HOSE 0.625 . . . . . 2 PLATE, CLAMP TOP. . . . . . . . . . . . 2 CS 5/16" x 2" . . . . . . . . . . . . . . . . . . 2 5/16”-18X2-1/4” STUD. . . . . . . . . . . 8 CUSHION, TUBE 0.625 TWIN . . . . 8 PLATE, TWIN CUSHION. . . . . . . . . 4 5/16”-18 NYLON INSERT NUT . . . . 8 TUBE, BOOM TILT/AUX . . . . . . . . . 2 ST-L MJ08-MORB10 . . . . . . . . . . . . 2 HOSE, -8 X 52" . . . . . . . . . . . . . . . . 1 HOSE, -8 X 52" . . . . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Hydraulic Pump Group 2 1

LS

13 3 12 32 33 28

Hydraulic Pump parts are on page 166.

4

P

31

29

30

5

6

5

27

Flow Divider parts are on page 167.

6

26

12 11

Hydraulic Control Valve

1

25

(right-front port)

13

22

S

IN

7

8

9

10

14 EP

21 23

20

T

11

24

18

Hydraulic Tank

11 16

(return)

19

17

15

PWP Manifold "P" Port (Note b)

Front Axle Park Brake (left side)

Hydraulic Tank

J

PB

Joysticks (Note a)

Hydraulic Tank is on page 50.

(supply)

50960084/AP0914

134

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics Hydraulic Pump Group

Item No.

Part No.

01 02 03 04 05 06 07 08 09 10 11 12 13 14 15a 16b 17 18

L63402 137784 101882 L64524 L68808 50381079 654002 L50139 L50217 102313 054994 L66563 055005 055064 103318 L63381 103317 079026

PRINTED IN U.S.A.

Description

Qty. Req.

HOSE, -4 A4/A6 48" . . . . . . . . . . . . 1 90 MJ06-MAORB04 . . . . . . . . . . . . 1 STEER MOTOR 17.9 DYNAMIC. . . 1 CHECK VALVE FITTING . . . . . . . . . 1 HOSE, -6 A8/DS8 48" . . . . . . . . . . . 1 HOSE, -6 X 23" . . . . . . . . . . . . . . . . 1 FW 1/4" AWZY . . . . . . . . . . . . . . . . 2 LW 1/4" . . . . . . . . . . . . . . . . . . . . . . 2 CS 1/4"x3-1/2" (one not shown) . . . 2 FLOW DIVIDER. . . . . . . . . . . . . . . . 1 ADAP., -6ORM -6JICM STR . . . . . . 3 HOSE, -12 A12/A12 26" . . . . . . . . . 1 90 MJ12-MAORB12 . . . . . . . . . . . . 2 45 MJ12-MAORB12 . . . . . . . . . . . . 1 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 1 HOSE, -4 A6/A6 15” . . . . . . . . . . . . 1 HOSE, -6 A6/A6 28” . . . . . . . . . . . . 1 45 JM06-MAORB06 . . . . . . . . . . . . 1

Item No.

Part No.

Description

19 20 21 22 23 24 25 26 27 28 29 30 31 32 33

103368 L67455 650488 090666 L570017 L63309 100012 L445014 L46865 651148 650495 50380843 054626 088442 076143

a b

Standard (units not equipped with PWP).

Option (units equipped with PWP).

135

Qty. Req.

HOSE, -6 A6/DS6 52” . . . . . . . . . . . 1 HOSE, -12 A12/DS12 105" . . . . . . . 1 CS 3/8" x 3/4" C5ZY . . . . . . . . . . . . 1 LN FL SERR 3/8" CZY . . . . . . . . . . 1 CLAMP, HOSE 1.19 x 0.41 . . . . . . . 1 HOSE, -24 A24/A24 35” . . . . . . . . . 1 90 MJ04-FJS04 . . . . . . . . . . . . . . . . 1 90 MJ24-MAORB20 . . . . . . . . . . . . 1 GASKET, HYD PUMP . . . . . . . . . . . 1 FW 1/2” . . . . . . . . . . . . . . . . . . . . . . 2 CS 1/2”-13 x 1-1/4” . . . . . . . . . . . . . 2 HYDRAULIC PUMP, 47cc . . . . . . . 1 ST MJ08-MORB08 . . . . . . . . . . . . . 1 90 MJ08-FJS08 . . . . . . . . . . . . . . . . 1 TEE MJ08-FJS08-MJ08 . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Hydraulic Control Valve and Hoses

1 2 3 17

16

4

5

20

17 18

18

6

19 21

15 20

19

7

22

13

14

8

B 21 24

A

23

9

11 12

22 10 23 25 26 Hydraulic valve parts are on page 168.

50960084/AP0914

136

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics Hydraulic Control Valve and Hoses

Item No. 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18

Part No. L68809 L67455 L68809 L63407 L63407 50380756 50380757 L68817 50380757 50380757 50380757 L63407 50380756 L63407 L63407 L63406 L60253 072587

Description

Qty. Req.

Item No.

HOSE, -4 A6/DS6 136” . . . . . . . . . . 1 HOSE, -12 A12/DS12 105" . . . . . . . 1 HOSE, -4 A6/DS6 136” . . . . . . . . . . 1 HOSE, -6 A8/A8 48” . . . . . . . . . . . . 1 HOSE, -6 A8/A8 48” . . . . . . . . . . . . 1 HOSE, -8 X 70" . . . . . . . . . . . . . . . . 1 HOSE, -8 X 52" . . . . . . . . . . . . . . . . 1 HOSE, -6 A8/A8 26” . . . . . . . . . . . . 1 HOSE, -8 X 52" (hydraulic option) . 1 HOSE, -8 X 52" (hydraulic option). . 1 HOSE, -8 X 52" . . . . . . . . . . . . . . . . 1 HOSE, -6 A8/A8 48” . . . . . . . . . . . . 1 HOSE, -8 X 70" . . . . . . . . . . . . . . . . 1 HOSE, -6 A8/A8 48” . . . . . . . . . . . . 1 HOSE, -6 A8/A8 48” . . . . . . . . . . . . 1 HOSE, -12 A12/DS12 114” . . . . . . . 1 ST MJ06-MORB10 . . . . . . . . . . . . . 2 ST MJ12-MORB12 . . . . . . . . . . . . . 2

Part No.

Description

Qty. Req.

19 20 21 22 23 24a

076031 076143 50302155 121387 50302155 L68694

90 MJ08-MAORB10 . . . . . . . . . . . . 2 TEE MJ08-FJS08-MJ08 . . . . . . . . . 2 ST-L MJ08-MORB10 . . . . . . . . . . . . 2 TEE MJ08-MAORB10-MJ08 . . . . . . 2 ST-L MJ08-MORB10 (hyd. option) . 2 VALVE, HYDRAULIC CONTROL . . 1 (refer to note a) CS 5/16" X 3" C5ZY . . . . . . . . . . . . 3 LN INST 5/16" . . . . . . . . . . . . . . . . 3

25 26

650833 L520004

a

The illustration on the facing page shows the hydraulic valve with the optional auxiliary hydraulics work section. Be aware that the standard four-section valve, PN L68694, does not include the auxiliary hydraulics work section. The kit for the optional auxiliary hydraulics work section is PN L68778.

Valve Functions Hose Layout

L

VE

E EL

M

T

TE

(

A

T

H

.

YD

N)

IO

T OP

ND

X.

AU

FO

TE

BO

T TIL

RK

AC

EX

EX

OM

ND

TR

BO

B

LIF

OM

RE

A FR

HOSE LOCATOR 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16

HYDRAULIC CONTROL VALVE SECTION HYDRAULIC CONTROL VALVE “IN” HYDRAULIC CONTROL VALVE SECTION HYDRAULIC CONTROL VALVE SECTION HYDRAULIC CONTROL VALVE SECTION HYDRAULIC CONTROL VALVE SECTION HYDRAULIC CONTROL VALVE SECTION HYDRAULIC CONTROL VALVE SECTION OPTIONAL HYD. SECTION PORT “B” OPTIONAL HYD. SECTION PORT “A” HYDRAULIC CONTROL VALVE SECTION HYDRAULIC CONTROL VALVE SECTION HYDRAULIC CONTROL VALVE SECTION HYDRAULIC CONTROL VALVE SECTION HYDRAULIC CONTROL VALVE SECTION HYDRAULIC CONTROL VALVE “OUT”

PRINTED IN U.S.A.

1 PORT “A” 1 2 2 3 4 4

PORT “B” PORT “B” PORT “B” PORT “B” PORT “B” PORT “B”

4 4 3 2 2

PORT “A” PORT “A” PORT “A” PORT “A” PORT “A”

137

LEVEL CYLINDER (INSIDE-EXTEND) FLOW DIVIDER PORT “EF” LEVEL CYLINDER (OUTSIDE-RETRACT) LIFT CYLINDER (LEFT) (OUTSIDE-RETRACT) LIFT CYLINDER (RIGHT) (INSIDE-RETRACT) BOOM EXTEND CYLINDER (BOOM RETRACT) TILT CYLINDER (RETRACT) SLAVE CYLINDER (BOTTOM-RETRACT) HYDRAULIC OPTION (RETRACT) HYDRAULIC OPTION ( EXTEND) TILT CYLINDER (EXTEND) SLAVE CYLINDER (TOP-EXTEND) BOOM EXTEND CYLINDER (BOOM EXTEND) LIFT CYLINDER (LEFT) (INSIDE-EXTEND) LIFT CYLINDER (RIGHT) (OUTSIDE-EXTEND) HYDRAULIC TANK (FILTER COVER FITTING)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Dual Controls (Standard) Circuit

TILT LEVEL

3

Controllers are on pages 176-182.

LIFT

2

EXTEND

TILT “FORWARD” (R)

LEVEL “LEFT” (E) HYDRAULIC

TILT “BACK”(E)

OPTION

1

LEVEL “RIGHT” (R)

BOOM “DOWN”(R)

BOOM “IN” (R)

4

BOOM “OUT” (E)

BOOM “UP”(E)

9 4

EXTEND

6

9

6

5

RETRACT

BACK

6

4

FORWARD

5

6 UP

DOWN

7

7

IN OUT

RIGHT

LEFT

LEVE

TILT HYDR

FT)

M (U

BOO

FRONT

L (LE

BOO

P)

M (IN

)

(FOR WAR D)

AULIC

OPTIO

N

(R) = retract (E) = extend

HYDR

Hydraulic Control Valve shown with Auxiliary Hydraulics Option

50960084/AP0914

8

138

LEVE L (RIG HT) BOO M (D OWN BOO ) M (O UT) TILT (BAC K)

AULIC

8

OPTIO

N

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics Dual Controls (Standard) Circuit

Item No. 01 02 03 04 05 06 07

Part No. 103264 103263 103262 054994 L68811 L68810 L68810

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, AUX. HYD . . . . . . . 1 CONTROLLER, LIFT/EXTEND . . . . 1 CONTROLLER, TILT/LEVEL. . . . . . 1 ADAP., -6ORM -6JICM STR. . . . . AR HOSE, -4 A6/A6 108” . . . . . . . . . . . 2 HOSE, -4 A6/A6 96” . . . . . . . . . . . . 4 HOSE, -4 A6/A6 96” . . . . . . . . . . . . 2

Item No.

Part No.

08a 09

L68694 L64275

a

The illustration on the facing page shows the (optional) auxiliary hydraulic work section with the hydraulic control valve. Be aware the auxiliary hydraulic work section is not included with the hydraulic control valve (PN L68694), but must be ordered separately as a kit (PN L68778). Refer to page 168 for more information

139

Description

Qty. Req.

HYDRAULIC CONTROL VALVE . . . 1 HOSE, -4 A6/A6 102” . . . . . . . . . . . 2

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Tri-Function Control (Option) - Standard Hydraulics Circuit

LEGEND BOOM IN/OUT BOOM UP/DOWN FRAME LEVEL

1

Controllers are on pages 176-182.

2

4 3

7

2

T

11

3

3

P

10

8

T

4

5

3

1

6

P

8 3

7

12

7 7

9

7

7 FLOW DIVIDER PORT “J” HYDRAULIC TANK MANIFOLD

4 17 P

16

13 14 B

3

6 3

T

A

15

4

4 10

14 3

50960084/AP0914

140

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics

Tri-Function Control (Option) - Standard Hydraulics Circuit Item No. 01 02 03 04 05 06 07 08 09 10

Part No. L71346 103264 054994 068938 054820 091039 L68810 L69903 103315 102831

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, TRI-FUNCTION. . . 1 CONTROLLER, FRAME LEVEL . . . 1 ADAP., -6ORM -6JICM STR . . . . . 14 ADAP., -6ORM -6JICM 90º . . . . . . . 9 ADAP., -6ORM -6JICM RUN TEE . . 1 ADAP., -6JICM -6JICFS 90º . . . . . . 2 HOSE, -6 A6/A6 96” . . . . . . . . . . . . 6 HOSE, -4 A6/DS6 17” . . . . . . . . . . . 2 HOSE, -4 A6/A6 60” . . . . . . . . . . . . 1 HOSE, -4 A6/DS6 102” . . . . . . . . . . 2

Item No.

Part No.

11 12 13 14 15 16 17

072806 103318 L69904 102843 106898 L50741 L50051

ADAP., -6JICM -6JICFS RUN TEE . 1 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 1 HOSE, -4 A6/DS6 20” . . . . . . . . . . . 1 HOSE, -4 A6/DS6 35” . . . . . . . . . . . 1 PILOT APPLY MANIFOLD. . . . . . . . 1 STUD, 1/4”X3-1/4”. . . . . . . . . . . . . . 2 NUT, 1/4”-20 WHIZ NUT . . . . . . . . . 2

---

105580 L62761

-- ITEMS NOT SHOWN -TRI-FUNCTION WIRE HARNESS . 1 1/4” MALE ELEC. CONNECTOR . . 8

141

Description

Qty. Req.

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Tri-Function Control (Option) with Auxiliary Hydraulics Circuit

LEGEND BOOM IN/OUT BOOM UP/DOWN FRAME LEVEL

1

Controllers are on pages 176-182.

2

4

7

3

3

2 T

11

3

P

10

8

4

T

5

3

1

6

P

8 3

7

12

7 7

9

7

7 FLOW DIVIDER PORT “J”

HYDRAULIC TANK MANIFOLD

17 19

16

18 P

15

B

13 3

T

A

14 3

P

18

4 4

B

13

T

A

15 11

3

4 14 3

10

50960084/AP0914

142

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics

Tri-Function Control (Option) with Auxiliary Hydraulics Circuit Item No. 01 02 03 04 05 06 07 08 09 10 11 12

Part No. L71346 103264 054994 068938 054820 091039 L68810 L69903 103315 102831 072806 103318

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, TRI-FUNCTION. . . 1 CONTROLLER, FRAME LEVEL . . . 1 ADAP., -6ORM -6JICM STR . . . . . 19 ADAP., -6ORM -6JICM 90º . . . . . . 10 ADAP., -6ORM -6JICM RUN TEE . . 1 ADAP., -6JICM -6JICFS 90º . . . . . . 1 HOSE, -6 A6/A6 96” . . . . . . . . . . . . 6 HOSE, -4 A6/DS6 17” . . . . . . . . . . . 2 HOSE, -4 A6/A6 60” . . . . . . . . . . . . 1 HOSE, -4 A6/DS6 102” . . . . . . . . . . 2 ADAP., -6JICM -6JICFS RUN TEE . 2 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 1

Item No.

Part No.

13 14 15 16 17 18 19

L69904 102843 106898 L50745 L50051 105593 L51762

HOSE, -4 A6/DS6 20” . . . . . . . . . . . 2 HOSE, -4 A6/DS6 35” . . . . . . . . . . . 2 PILOT APPLY MANIFOLD. . . . . . . . 2 STUD, 1/4”X5-3/4”. . . . . . . . . . . . . . 2 NUT, 1/4”-20 WHIZ NUT . . . . . . . . . 2 HOSE, -4 A6/DS6 12” . . . . . . . . . . . 2 ADAP., -6ORM -6JICM B TEE . . . . 1

--

105580

-- ITEMS NOT SHOWN -TRI-FUNCTION WIRE HARNESS . 1

143

Description

Qty. Req.

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Radio Remote (Option) Circuit

NOTE: Hose reference AA, BB, and CC attach to joysticks and manifolds.

Refer to “Hydraulic Controls - Radio Remote” section for more information.

JS

AA CC

2

Radio Remote Manifold parts are on page 175.

E1 E2

5

3

5

BB

4

E3 E4

P

1

INL

T

DN EXT RET

J1

UP J2 J4 Boom Out J3

6 7

Boom Down

Boom In

1 8 TILT BOO

Boom Up

(FOR WAR D)

M (IN

BOO

)

LEVE

M (U

P)

L (LE

9

9

FT)

8

Boom Down Boom In

Boom Out

50960084/AP0914

Boom Up

144

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics Radio Remote (Option) Circuit

Item No. 01 02 03 04 05

Part No. L68804 L69905 103505 137784 129124

PRINTED IN U.S.A.

Description

Qty. Req.

HOSE, -4 A6/DS6 26” . . . . . . . . . . . 4 HOSE, -4 A6/A6 130” . . . . . . . . . . . 2 HOSE, -4 H6/DS6 109” . . . . . . . . . . 1 ADAP., -4ORM -6JICM 90º . . . . . . . 6 ADAP., -4ORM -6JICM STR . . . . . . 5

Item No. 06 07 08 09

145

Part No. 50380273 103425 L69902 L68810

Description

Qty. Req.

MANIFOLD, RADIO REMOTE . . . . 1 MOUNT, RADIO REMOTE . . . . . . . 1 HOSE, -4 A6/H6 20” . . . . . . . . . . . . 4 HOSE, -4 A6/A6 96” . . . . . . . . . . . . 4

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Dual Controls - Standard

TILT LEVEL

1 LIFT EXTEND

Controllers are on pages 176-182.

2 P

3

T P T

5

3

5 5

Flow Divider parts are on page 167.

4 5

FRONT

6 FLOW DIVIDER

7 J

HYDRAULIC TANK

8

50960084/AP0914

146

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics Dual Controls - Standard

Item No. 01 02 03 04

Part No. 103262 103263 054994 072806

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, TILT/LEVEL. . . . . . 1 CONTROLLER, LIFT/EXTEND . . . . 1 ADAP., -6ORM -6JICM STR . . . . . . 4 ADAP., -6 SWVL RUN TEE . . . . . AR

Item No.

Part No.

05 06 07 08

L69903 103315 102313 103318

147

Description

Qty. Req.

HOSE, -4 A6/DS6 17”. . . . . . . . . . AR HOSE, -4 A6/A6 60” . . . . . . . . . . . . 1 MANIFOLD, JOYSTICK RELIEF. . . 1 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Dual Controls with only Auxiliary Hydraulics (Option)

TILT LEVEL

1

LIFT EXTEND

Controllers are on pages 176-182.

2 P

3 T

4

P HYDRAULIC OPTION

T

8

12

3 3

10 7

4 5

8

T

12

9

P

10

6 9 7

FLOW DIVIDER

13 J

HYDRAULIC TANK

11

Flow Divider parts are on page 167.

50960084/AP0914

148

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics

Dual Controls with only Auxiliary Hydraulics (Option) Item No. 01 02 03 04 05 06 07

Part No. 103262 103263 054994 072806 091039 068938 L69904

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, TILT/LEVEL. . . . . . 1 CONTROLLER, LIFT/EXTEND . . . . 1 ADAP., -6ORM -6JICM STR. . . . . AR ADAP., -6 SWIVEL RUN TEE. . . . AR ADAP., -6JICM -6JICFS 90º . . . . . AR ADAP., -6ORM -6JICM 90º. . . . . . AR HOSE, -4 A6/DS6 20” . . . . . . . . . . . 1

Item No.

Part No.

08 09 10 11 12 13

L69903 L69904 L69903 103318 103264 102313

149

Description

Qty. Req.

HOSE, -4 A6/DS6 17” . . . . . . . . . . . 1 HOSE, -4 A6/DS6 20” . . . . . . . . . . . 1 HOSE, -4 A6/DS6 17” . . . . . . . . . . . 1 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 1 CONTROLLER, AUX. HYD . . . . . . . 1 MANIFOLD, JOYSTICK RELIEF. . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Dual Controls with only PWP (Option)

TILT LEVEL

1 LIFT

Controllers are on pages 176-182.

EXTEND

2

P

3 T P T

5

8

3 7 4 7 Flow Divider parts are on page 167.

6

PWP valve parts are on page 170.

FLOW DIVIDER

HYDRAULIC TANK

PWP VALVE

10 9 p

11 J

12

J2 J1

5

8

50960084/AP0914

150

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics Dual Controls with only PWP (Option)

Item No. 01 02 03 04 05 06 07

Part No. 103262 103263 054994 072806 103318 103315 L69903

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, TILT/LEVEL. . . . . . 1 CONTROLLER, LIFT/EXTEND . . . . 1 ADAP., -6ORM -6JICM STR. . . . . AR ADAP., -6 SWIVEL RUN TEE. . . . AR HOSE, -4 A6/DS6 52” . . . . . . . . . . . 1 HOSE, -4 A6/A6 60” . . . . . . . . . . . . 1 HOSE, -4 A6/DS6 17” . . . . . . . . . . . 1

Item No.

Part No.

08 09 10 11

103318 102313 102321 103318

12

L63381

151

Description

Qty. Req.

HOSE, -4 A6/DS6 52” . . . . . . . . . . . 1 MANIFOLD, JOYSTICK RELIEF. . . 1 MANIFOLD, PWP JOYSTICK . . . . . 1 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 1 (to hydraulic tank) HOSE, -4 A6/DS6 15” . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Dual Controls with PWP and Auxiliary Hydraulics (Option)

TILT LEVEL

Controllers are on pages 176-182.

1 LIFT EXTEND

2 P

3

T

4

P

HYDRAULIC OPTION

T

16

11

3 4

3 5

T

7

8

10 9

P

12 6 9 7

PWP VALVE HYDRAULIC TANK

14 17

13

p

15 J1

Flow Divider parts are on page 167.

50960084/AP0914

PWP valve parts are on page 170.

J2

11 FLOW DIVIDER

152

8

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics

Dual Controls with PWP and Auxiliary Hydraulics (Option) Item No. 01 02 03 04 05 06 07 08 09

Part No. 103262 103263 054994 072806 091039 068938 L69904 103318 L69904

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, TILT/LEVEL. . . . . . 1 CONTROLLER, LIFT/EXTEND . . . . 1 ADAP., -6ORM -6JICM STR. . . . . AR ADAP., -6 SWIVEL RUN TEE. . . . AR ADAP., -6JICM -6JICFS 90º . . . . . AR ADAP., -6ORM -6JICM 90º. . . . . . AR HOSE, -4 A6/DS6 20” . . . . . . . . . . . 1 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 1 HOSE, -4 A6/DS6 20” . . . . . . . . . . . 1

Item No.

Part No.

10 11 12 13 14 15 16 17

L69903 103318 103315 102313 102321 L63381 103264 103318

153

Description

Qty. Req.

HOSE, -4 A6/DS6 17” . . . . . . . . . . . 1 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 1 HOSE, -4 A6/A6 60” . . . . . . . . . . . . 1 MANIFOLD, JOYSTICK RELIEF. . . 1 MANIFOLD, PWP JOYSTICK . . . . . 1 HOSE, -4 A6/A6 15” . . . . . . . . . . . . 1 CONTROLLER, AUX. HYD . . . . . . . 1 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 1 (to hydraulic tank)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Dual Controls with Radio Remote (Option)

TILT LEVEL

1 Controllers are on pages 176-182.

LIFT EXTEND

P

2

3 T P T

3

8

8

Flow Divider parts are on page 167.

7 4

PWP valve parts are on page 170.

5

9 10

T

P

11

3 J

J1

12 T

13

8

6

AA

8

6

HYDRAULIC TANK MANIFOLD

JS NOTE: Hose reference AA, BB, and CC attach to radio remote manifold.

Refer to the “Hydraulic Control Valve - Radio Remote” section for more information.

50960084/AP0914

10

3 4

14

J2

154

BB

CC

T

P

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics

Dual Controls with Radio Remote (Option) Item No. 01 02 03 04 05 06 07

Part No. 103262 103263 054994 072806 103315 L69905 L69904

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, TILT/LEVEL. . . . . . 1 CONTROLLER, LIFT/EXTEND . . . . 1 ADAP., -6ORM -6JICM STR . . . . . . 8 ADAP., -6 SWIVEL RUN TEE . . . . . 2 HOSE, -4 A6/A6 60” . . . . . . . . . . . . 1 HOSE, -4 A6/DS6 130” . . . . . . . . . . 2 HOSE, -4 A6/DS6 20” . . . . . . . . . . . 1

Item No.

Part No.

08 09 10 11 12 13 14

103318 102321 068938 L63381 103368 102313 103505

155

Description

Qty. Req.

HOSE, -4 A6/DS6 52” . . . . . . . . . . . 3 MANIFOLD, PWP JOYSTICK . . . . . 1 ADAP., -6ORM -6JICM 90º . . . . . . . 2 HOSE, -4 A6/A6 15” . . . . . . . . . . . . 1 HOSE, -6 A6/DS6 52” . . . . . . . . . . . 1 MANIFOLD, JOYSTICK RELIEF. . . 1 HOSE, -4 H6/DS6 109” . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Dual Controls with Radio Remote and Auxiliary Hydraulics (Option)

1

LIFT

TILT LEVEL

EXTEND

2 P

Controllers are on pages 176-182.

T P

5

8 8

T

3

11

4 3

8

7

T

9 P

6

8

8 14 3 6

3 J

T P

12

11 13

16 15

T

4

J2

J1

6

3

11

11

10

HYDRAULIC TANK MANIFOLD

10

AA JS

NOTE: Hose reference AA, BB, and CC attach to radio remote manifold. Refer to the “Radio Remote” section for more information.

BB T

50960084/AP0914

156

CC P

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics

Dual Controls with Radio Remote and Auxiliary Hydraulics (Option) Item No. 01 02 03 04 05 06 07 08 09

Part No. 103262 103263 054994 072806 103264 068938 091039 L69904 103315

Flow Divider parts are on page 167.

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, TILT/LEVEL. . . . . . 1 CONTROLLER, LIFT/EXTEND . . . . 1 ADAP., -6ORM -6JICM STR . . . . . . 9 ADAP., -6 SWIVEL RUN TEE . . . . . 2 CONTROLLER, AUX. HYD . . . . . . . 1 ADAP., -6ORM -6JICM 90º . . . . . . . 3 ADAP., -6ORM -6JICFS 90º . . . . . . 1 HOSE, -4 A6/DS6 20” . . . . . . . . . . . 3 HOSE, -4 A6/A6 60” . . . . . . . . . . . . 1

Item No.

Part No.

10 11 12 13 14 15 16

L69905 103318 L63381 103368 102321 102313 103505

Description

Qty. Req.

HOSE, -4 A6/A6 130” . . . . . . . . . . . 2 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 3 HOSE, -4 A6/A6 15” . . . . . . . . . . . . 1 HOSE, -6 A6/DS6 52” . . . . . . . . . . . 1 MANIFOLD, PWP JOYSTICK . . . . . 1 MANIFOLD, JOYSTICK RELIEF. . . 1 HOSE, H6/DS6 109” . . . . . . . . . . . . 1

PWP valve parts are on page 170.

157

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Tri-Function Control (Option) with only PWP

1

2 Controllers are on pages 176-182.

4 T T

3

10

3

8

P

10 P

3

T

9

P

5

4

6

9 7 4 PILOT APPLY VALVE (REAR OF MACHINE)

P

14

T

13

T

3

P

9

3

10 J2

J

J1

11 15 12

T

9 4

9

HYDRAULIC TANK RETURN MANIFOLD

50960084/AP0914

158

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics

Tri-Function Control (Option) with only PWP Item No. 01 02 03 04 05 06 07 08 09

Part No. L71346 103264 054994 068938 054820 091039 103315 L69903 103318

Flow Divider parts are on page 167.

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, TRI-FUNCTION. . . 1 CONTROLLER, FRAME LEVEL . . . 1 ADAP., -6ORM -6JICM STR . . . . . . 8 ADAP., -6ORM -6JICM 90º . . . . . . . 5 ADAP., -6ORM -6JICM RUN TEE . . 1 ADAP., -6JICM -6JICFS 90º . . . . . . 1 HOSE, -4 A6/A6 60” . . . . . . . . . . . . 1 HOSE, -4 A6/DS6 17” . . . . . . . . . . . 1 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 3

PWP valve parts are on page 170.

Item No.

Part No.

Description

Qty. Req.

10 11 12 13 14 15

102831 L63381 102313 106898 102321 103368

HOSE, -4 A6/DS6 102” . . . . . . . . . . 2 HOSE, -4 A6/DS6 15” . . . . . . . . . . . 1 MANIFOLD, JOYSTICK RELIEF. . . 1 PILOT APPLY MANIFOLD. . . . . . . . 1 MANIFOLD, PWP JOYSTICK . . . . . 1 HOSE, -6 A6/DS6 52”

--

105580

-- ITEMS NOT SHOWN -TRI-FUNCTION WIRE HARNESS . 1

Pilot Apply valve parts are on page 174.

159

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Tri-Function Control (Option) with PWP and Auxiliary Hydraulics

1

2 Controllers are on pages 176-182.

4 T

3 T

8

10

P

3

10

T

P P

9

5

4

6

9 15

7 13 P

16

14

16 T

10

T

P

9

PILOT APPLY VALVE (REAR OF MACHINE)

3

3

3 J2

J

J1

11 17 12

T

9 4

HYDRAULIC TANK RETURN MANIFOLD

50960084/AP0914

9

160

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics

Tri-Function Control (Option) with PWP and Auxiliary Hydraulics Item No. 01 02 03 04 05 06 07 08 09 10

Part No. L71346 103264 054994 068938 054820 091039 103315 L69903 103318 102831

Flow Divider parts are on page 167.

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, TRI-FUNCTION. . . 1 CONTROLLER, FRAME LEVEL . . . 1 ADAP., -6ORM -6JICM STR . . . . . . 8 ADAP., -6ORM -6JICM 90º . . . . . . . 5 ADAP., -6ORM -6JICM RUN TEE . . 1 ADAP., -6JICM -6JICFS 90º . . . . . . 1 HOSE, -4 A6/A6 60” . . . . . . . . . . . . 1 HOSE, -4 A6/DS6 17” . . . . . . . . . . . 1 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 3 HOSE, -4 A6/DS6 102” . . . . . . . . . . 2

PWP valve parts are on page 170.

Item No.

Part No.

Description

Qty. Req.

11 12 13 14 15 16 17

L63381 102313 106898 102321 L51762 105593 103368

HOSE, -4 A6/DS6 15” . . . . . . . . . . . 1 MANIFOLD, JOYSTICK RELIEF. . . 1 PILOT APPLY MANIFOLD. . . . . . . . 1 MANIFOLD, PWP JOYSTICK . . . . . 1 ADAP., -6ORM -6JICM B TEE . . . . 1 HOSE, -4 A6/DS6 12” . . . . . . . . . . . 2 HOSE, -6 A6/DS6 52” . . . . . . . . . . . 1

--

105580

-- ITEMS NOT SHOWN -TRI-FUNCTION WIRE HARNESS . 1

Pilot Apply valve parts are on page 174.

161

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Tri-Function Control (Option) with Radio Remote

1

2 4 T T

10

Controllers are on pages 176-182.

3 8

3

P

10 P

P

T

9

5

3 4

6

9

4

7 13

P

T

3

14

10 PILOT APPLY VALVE (REAR OF MACHINE)

4

3 J

T

P

11 J1

12

3

15

T

16

17

JS

J2

9

18

AA

3

BB T

4

3

9

9

17

CC HYDRAULIC TANK RETURN MANIFOLD

P

NOTE: Hose reference AA, BB, and CC attach to radio remote manifold.

Refer to the “Hydraulic Control Valve - Radio Remote” section for more information.

50960084/AP0914

162

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics

Tri-Function Control (Option) with Radio Remote Item No. 01 02 03 04 05 06 07 08 09 10 11

Part No. L71346 103264 054994 068938 054820 091039 103315 L69903 103318 102831 L63381

Flow Divider parts are on page 167.

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, TRI-FUNCTION. . . 1 CONTROLLER, FRAME LEVEL . . . 1 ADAP., -6ORM -6JICM STR . . . . . . 7 ADAP., -6ORM -6JICM 90º . . . . . . . 4 ADAP., -6ORM -6JICM RUN TEE . . 1 ADAP., -6JICM -6JICFS 90º . . . . . . 1 HOSE, -4 A6/A6 60” . . . . . . . . . . . . 1 HOSE, -4 A6/DS6 17” . . . . . . . . . . . 1 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 3 HOSE, -4 A6/DS6 102” . . . . . . . . . . 2 HOSE, -4 A6/DS6 15” . . . . . . . . . . . 1

PWP valve parts are on page 170.

Item No.

Part No.

Description

Qty. Req.

12 13 14 15 16 17 18

102313 106898 102321 103368 072806 L69905 103505

MANIFOLD, JOYSTICK RELIEF. . . 1 PILOT APPLY MANIFOLD. . . . . . . . 2 MANIFOLD, PWP JOYSTICK . . . . . 1 HOSE, -6 A6/DS6 52” . . . . . . . . . . . 1 ADAP., -6JICM -6JICFS R TEE. . . . 1 HOSE, -4 A6/A6 130” . . . . . . . . . . . 2 HOSE, -4 H6/DS6 109” . . . . . . . . . . 1

--

105580

-- ITEMS NOT SHOWN -TRI-FUNCTION WIRE HARNESS . 1

Pilot Apply valve parts are on page 174.

163

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulics

RS6-34 Telescopic Handler

Tri-Function Control (Option) with Radio Remote and Auxiliary Hydraulics

1

2 4 T T

10

Controllers are on pages 176-182.

3

3

8

P

10 P

P

T

9

5

3 4

6

15 9

13

7

P

16

16 14

T

10 PILOT APPLY VALVE (REAR OF MACHINE)

4

3 J

T

P

11 J1

9

20

12

3

17

T

18

19

AA JS

BB T

3

J2

4

3

9

9

19

CC HYDRAULIC TANK RETURN MANIFOLD

P

NOTE: Hose reference AA, BB, and CC attach to radio remote manifold.

Refer to the “Radio Remote” section for more information.

50960084/AP0914

164

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulics

Tri-Function Control (Option) with Radio Remote and Auxiliary Hydraulics Item No. 01 02 03 04 05 06 07 08 09 10 11 12

Part No. L71346 103264 054994 068938 054820 091039 103315 L69903 103318 102831 L63381 102313

Flow Divider parts are on page 167.

PRINTED IN U.S.A.

Description

Qty. Req.

CONTROLLER, TRI-FUNCTION. . . 1 CONTROLLER, FRAME LEVEL . . . 1 ADAP., -6ORM -6JICM STR . . . . . . 7 ADAP., -6ORM -6JICM 90º . . . . . . . 4 ADAP., -6ORM -6JICM RUN TEE . . 1 ADAP., -6JICM -6JICFS 90º . . . . . . 1 HOSE, -4 A6/A6 60” . . . . . . . . . . . . 1 HOSE, -4 A6/DS6 17” . . . . . . . . . . . 1 HOSE, -4 A6/DS6 52” . . . . . . . . . . . 3 HOSE, -4 A6/DS6 102” . . . . . . . . . . 2 HOSE, -4 A6/DS6 15” . . . . . . . . . . . 1 MANIFOLD, JOYSTICK RELIEF. . . 1

PWP valve parts are on page 170.

Item No.

Part No.

Description

Qty. Req.

13 14 15 16 17 18 19 20

106898 102321 L51762 105593 103368 072806 L69905 103505

PILOT APPLY MANIFOLD. . . . . . . . 2 MANIFOLD, PWP JOYSTICK . . . . . 1 ADAP., -6ORM -6JICM B TEE . . . . 1 HOSE, -4 A6/DS6 12” . . . . . . . . . . . 2 HOSE, -6 A6/DS6 52” . . . . . . . . . . . 1 ADAP., -6JICM -6JICFS R TEE. . . . 1 HOSE, -4 A6/A6 130” . . . . . . . . . . . 2 HOSE, -4 H6/DS6 109” . . . . . . . . . . 1

--

105580

-- ITEMS NOT SHOWN -TRI-FUNCTION WIRE HARNESS . 1

Pilot Apply valve parts are on page 174.

165

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Hydraulic Pump

2 1

Item No.

Part No.

01

50380843

02

L46865

Description

Qty. Req.

HYDRAULIC PUMP, 47CC . . . . . . . 1 (Cast Iron Body) GASKET . . . . . . . . . . . . . . . . . . . . . 1

NOTE: The pump is not a serviceable item; order complete pump.

50960084/AP0914

166

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Joystick Relief - Flow Divider

5

3 6 2

PARKING BRAKE VALVE

7

1

4

8 9

Item No. 01 02 03

Part No.

04 05

102313 103017 L99927 L99925 105087 NSS

06

L99908

07

L99910 L99911

Description

Qty. Req.

FLOW DIVIDER . . . . . . . . . . . . . . . .1 PILOTED SPOOL LOGIC ELEM.. . .1 RELIEF VALVE . . . . . . . . . . . . . . . .1 SEAL KIT . . . . . . . . . . . . . . . . . . . .1 DEBRIS SCREEN . . . . . . . . . . . . . .1 NUT, SOLENOID VALVE . . . . . . . . .1 (included with item 6) 12 VDC WEATHER PACK COIL . . .1 (includes item 5) SOLENOID VALVE . . . . . . . . . . . . .1 SEAL KIT . . . . . . . . . . . . . . . . . . . .1

Item No.

Part No.

08

P471997 L62840 NSS

09

----

L50217 L50139 654002

Description

Qty. Req.

TEST PORT . . . . . . . . . . . . . . . . . . .3 CAP, DUST COVER (not shown) . .3 MANIFOLD BLOCK . . . . . . . . . . . . .1 -- ITEMS NOT SHOWN -(Mounting Hardware) 1/4”-20X3-1/2” BOLT . . . . . . . . . . . .2 1/4” LOCK WASHER . . . . . . . . . . . .2 1/4” FLAT WASHER . . . . . . . . . . . .2

NOTE: Items included in seal kits are not shown.

PRINTED IN U.S.A.

167

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Hydraulic Control Valve

2 1 4

4 7

11

10

9

5

14

8

4

10

6

7

5 4

TILT

15

5

‘B’ PORT 3

13

12

IN

BOOM

5

OUT

2

LIFT 15 18

13

17

22

15

15

‘A’ PORT

16

LEVEL

4

5

5 19

20 Auxiliary Hydraulics Work Section (Option)

15

22

SEAL KITS

21

50960084/AP0914

168

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Hydraulic Control Valve

Item No.

Part No.

01

L68694

02 03 04 05 06

L98891 L500954 L500134 L500132 L500130 L98895

07 08

L500952 L500953

09

L500956

10 11

L98896 L98897 L98898 L98899

12 13 14

L500955 L500957 L500959

PRINTED IN U.S.A.

Description

Qty. Req.

HYDRAULIC CONTROL VALVE . . . 1 (does not include items 20 and 21) STUD KIT (3 tie bolts and 3 nuts) . . 1 INLET COVER. . . . . . . . . . . . . . . . . 1 HRO ACTUATOR “B” END . . . . . . . 4 NO RELIEF-NO ANTI-CAV.PLUG . . 4 SEAL KIT . . . . . . . . . . . . . . . . . . . . . 1 WORK SECTION 1 (Frame Level) . 1 (includes items 4, 5, 15 & 16) NO RELIEF - ANTI-CAV PLUG. . . . 1 WORK SECTION 2 (Boom Lift). . . . 1 (includes items 4, 5, 7, 15 & 16) WORK SECTION 3 (Boom Extend) 1 (includes items 4, 5, 7, 15 & 16) RELIEF CARTRIDGE . . . . . . . . . . . 2 SERVICE KIT (less seals) . . . . . . . . 2 SEAL KIT . . . . . . . . . . . . . . . . . . . . . 2 WORK SECTION 4 (Fork Tilt). . . . . 1 (includes items 4, 10, 15 & 16) OUTLET COVER. . . . . . . . . . . . . . . 1 PLUG SAE-12 . . . . . . . . . . . . . . . . . 1 PLUG SAE 12 (socket head). . . . . . 1

Item No.

Part No.

15 16

L500135 L500961 654022 L500129 L96580 L500958

17 18 19

L500127 L98887 20 21

L98895 L500960

22

L500300

--

L68778

169

Description

Qty. Req.

HRO ACTUATOR “A” END . . . . . . . 4 SCREW . . . . . . . . . . . . . . . . . . . . 32 LOCK WASHER . . . . . . . . . . . . . . 32 RELIEF CARTRIDGE (RP51-A) . . . 1 RELIEF SEAL KIT . . . . . . . . . . . . . . 1 PLUG WITH TEST PLUG . . . . . . . . 1 SEAL KITS FOR WORK SECTIONS SECTION SEAL KIT . . . . . . . . . . 1ea (used with items 6-8 & 10) SPOOL SEAL KIT . . . . . . . . . . . . 1ea (used with items 4 & 15) WORK SECTION (Aux. Hyd.) . . . . . 1 STUD ASSEMBLY KIT (Aux. Hyd.) . 1 (used with item 21) DUST BOOT. . . . . . . . . . . . . . . . . AR -- ITEMS NOT SHOWN -KIT, VALVE SECTION (AUX.) . . . . . 1 (includes all items shown on facing page in the “Auxiliary Hydraulics Work Section” window, plus item 21)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

PWP Valve

1 2

3

4 5

6

Item No.

Part No.

04

102321

02

NSS

03 04

L99908 L99909 L99911

50960084/AP0914

Description

Qty. Req.

MANIFOLD, PWP JOYSTICK . . . . . 1 (complete assembly) NUT, SOLENOID VALVE . . . . . . . . . 2 (included with item 4 and 5) 12 VDC WEATHER PACK COIL . . . 2 SOLENOID VALVE . . . . . . . . . . . . . 1 SEAL KIT . . . . . . . . . . . . . . . . . . . . 1 (Items included are not shown.)

Item No.

Part No.

05

L99910 L99911

06

NSS

170

Description

Qty. Req.

SOLENOID VALVE . . . . . . . . . . . . . 1 SEAL KIT . . . . . . . . . . . . . . . . . . . . 1 (Items included are not shown) MANIFOLD . . . . . . . . . . . . . . . . . . . 1

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Steer Select Valve

3

1

2

4

5

Item No.

Part No.

01

L69747

02 03

210018 NSS

PRINTED IN U.S.A.

Description

Qty. Req.

STEER SELECT VALVE.. . . . . . . . . 1 (Includes items 1-5) WEATHER PAK VALVE. . . . . . . . . . 1 SHCS #10-24 x 1-3/4" . . . . . . . . . . . 4 (included with item #1)

Item No.

Part No.

04

107000

05

NSS

171

Description

Qty. Req.

SEAL KIT . . . . . . . . . . . . . . . . . . . . 1 (consists of the o-rings shown) MANIFOLD . . . . . . . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Steer Motor

1

LS L T

R P

2

Item No. 01

Part No. 101882

Description

Qty. Req.

STEERING CONTROL UNIT . . . . . 1

Item No.

Part No.

02

L500968

Description

Qty. Req.

SEAL KIT . . . . . . . . . . . . . . . . . . . . . 1 (Items included are not shown.)

NOTE: Field service is limited to seals replacement.

50960084/AP0914

172

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Brake Valve

1

Item No. 01

Part No. 50380743

Description

Qty. Req.

BRAKE VALVE . . . . . . . . . . . . . . . . 1

NOTE: At the time of publication, the OEM supplier was unable to provide individual serviceable items.

Contact the factory parts department for additional information.

PRINTED IN U.S.A.

173

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Pilot Apply Manifold - Tri-Function (Option)

1 2 8

T

B

7

6

5 4 9

3

Item No.

Part No.

01a

106898

02

L500745 L99911 244655 240202 106893 NSS 106892

03 04 05 06

50960084/AP0914

Description

Qty. Req.

PILOT APPLY MANIFOLD . . . . . . . . a (includes all items except item 9) PRESSURE CONTROL . . . . . . . . . 2 SEAL KIT . . . . . . . . . . . . . . . . . . . . 2 CARTRIDGE, 3-WAY/2-POSITION . 2 SEAL KIT (for one cartridge) . . . . AR SCHS M5-.08X10MM . . . . . . . . . . . 4 COIL NUT (included with item 7). . . 1 COIL, 12VDC. . . . . . . . . . . . . . . . . . 1

Item No.

Part No.

07

L500746

08 09

L99924 L99917 211161

a

174

Description

Qty. Req.

VALVE, 2-WAY . . . . . . . . . . . . . . . . 1 (includes item 5) SEAL KIT, 2-WAY VALVE . . . . . . . . 1 PLUG -4 NWD STYLE . . . . . . . . . . 1 WIRE HARNESS, TILT CONTROL . 1

Units equipped with Auxiliary Hydraulics use (2) 106898 Pilot Apply Manifolds.

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Radio Remote Manifold — (Option)

1

3 2 4

5

Item No.

Part No.

01

50380273

02 03 04

50220634 50220635 104736 50220631 50220632 50220633

05

NSS

PRINTED IN U.S.A.

Description

Qty. Req.

MANIFOLD, RADIO REMOTE . . . . 1 (includes all items shown and listed) 2/4 WAY SOLENOID VALVE . . . . . . 1 SEAL KIT FOR VALVE . . . . . . . . . . 1 12 VDC COIL (WEATHERPAK). . . . 1 PROPORTIONAL PRESS. VALVE . 4 SEAL KIT (one per valve) . . . . . . . . 4 SCREWS, M4-0.7x12mm . . . . . . . . 8 (not shown) MANIFOLD . . . . . . . . . . . . . . . . . . . 1

175

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Controller - Tilt/Frame Level

2

3

1 4

5

6

7

8

9

10

11

50960084/AP0914

176

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Controller - Tilt/Frame Level

Item No. 01 02 03 04 05 06

Part No. 103262 103122 103112 103113 102674 103114

PRINTED IN U.S.A.

Description

Qty. Req.

HYDRAULIC CONTROLLER . . . . . 1 KNOB. . . . . . . . . . . . . . . . . . . . . . . . 1 LEVER ROD (as shown) . . . . . . . . . 1 BOOT. . . . . . . . . . . . . . . . . . . . . . . . 1 LOCK GATE . . . . . . . . . . . . . . . . . . 1 SELECTOR DISC . . . . . . . . . . . . . . 1

Item No.

Part No.

07 08 09 10 11a

103115 103116 103403 103404 103117

a

Items included in seal kit are not shown.

177

Description

Qty. Req.

PIVOT/ BALL JOINT . . . . . . . . . . . . 1 PLATE / BOOT MOUNT . . . . . . . . . 1 METERING CURVE (as shown) . . . 4 RETURN SPRING. . . . . . . . . . . . . . 4 SEAL KIT . . . . . . . . . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Controller - Lift/Extend

2

3

4

1

5

6

7

8

9

10

50960084/AP0914

178

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Controller - Lift/Extend

Item No. 01 02 03 04 05 06

Part No. 103263 103122 103112 103113 103114 103115

PRINTED IN U.S.A.

Description

Qty. Req.

HYDRAULIC CONTROLLER . . . . . 1 KNOB. . . . . . . . . . . . . . . . . . . . . . . . 1 LEVER ROD (as shown) . . . . . . . . . 1 BOOT. . . . . . . . . . . . . . . . . . . . . . . . 1 SELECTOR DISC . . . . . . . . . . . . . . 1 PIVOT/ BALL JOINT . . . . . . . . . . . . 1

Item No.

Part No.

07 08 09 10a

103116 103403 103404 103117

a

Items included in seal kit are not shown.

179

Description

Qty. Req.

PLATE /BOOT MOUNT . . . . . . . . . . 1 METERING CURVE (as shown) . . . 4 RETURN SPRING. . . . . . . . . . . . . . 4 SEAL KIT . . . . . . . . . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Controller - Tri-Function (Option)

1

13 2

8

9

3

10 4

5

11

4 6 12 7

50960084/AP0914

180

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Controller - Tri-Function (Option)

Item No. 01 02 03 04 05 06 07

Part No. L71346 L500371 L62761 L500688 L500656 L500689 L500652

PRINTED IN U.S.A.

Description

Qty. Req.

JOYSTICK 4BUTTN/TRIGGER . . . 1 HANDLE W/4 BUTTONS . . . . . . . . 1 WIRE CONNECTOR . . . . . . . . . . . . 8 NUT M10 UNI . . . . . . . . . . . . . . . . . 2 RUBBER BOOT . . . . . . . . . . . . . . . 1 SELECTOR DISC . . . . . . . . . . . . . . 1 UNIVERSAL JOINT . . . . . . . . . . . . . 1

Item No.

Part No.

08 09 10 11 12a 13

L500692 L500690 L500691 NSS L500653 104304

a

Items included in the seal kit are not shown.

181

Description

Qty. Req.

SPINDLE GUIDE ASSEMBLY. . . . . 4 HPV SPINDLE 10mm . . . . . . . . . . . 4 PILOT SPRING PACK C094 . . . . . . 4 BODY ASSEMBLY. . . . . . . . . . . . . . 1 SEAL REPAIR KIT . . . . . . . . . . . . . 1 BEZEL, JOYSTICK . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Controller - Auxiliary Hydraulics (Option)

(Tri-Function - Level Valve)

2

1

3

4

5

6

7

50960084/AP0914

182

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components

(Tri-Function - Level Valve) Item No. 01 02 03 04

Part No. 103264 103077 103084 103078

PRINTED IN U.S.A.

Description

Controller - Auxiliary Hydraulics Qty. Req.

HYDRAULIC CONTROLLER. . . . . . 1 LEVER ROD (as shown) . . . . . . . . . 1 BOOT (included with item #4) . . . . . 1 CONTROL KIT. . . . . . . . . . . . . . . . . 1 (includes item #3 Boot)

Item No.

Part No.

05 06 07a

103403 103404 103083

a

Items included in seal kit are not shown.

183

Description

Qty. Req.

METERING CURVE (as shown) . . . 2 RETURN SPRING. . . . . . . . . . . . . . 2 SEAL KIT . . . . . . . . . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Frame Level Cylinder

1

2

3

8

7

6 4

5

9

10

External Threads

Cylinder Part Number Stamped Here

12

13

11

50960084/AP0914

184

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Frame Level Cylinder

Item No. 01 02 03 04 05 06 07

Part No. L63015 L98503 L63016 L98547 L99857 L98507 L98550

PRINTED IN U.S.A.

Description

Qty. Req.

CYLINDER, FRAME LEVEL . . . . . . 1 ROD (includes #3) . . . . . . . . . . . . . . 1 BUSHING . . . . . . . . . . . . . . . . . . . . 1 HEAD GLAND CAP. . . . . . . . . . . . . 1 5/16”-18x1/4” SET SCREW. . . . . . . 1 HEAD GLAND . . . . . . . . . . . . . . . . . 1 PISTON . . . . . . . . . . . . . . . . . . . . . . 1

Item No.

Part No.

08 09 10 11 12

L99405 L64367 NSS L98509 L70495 L97889 L98506

13

185

Description

Qty. Req.

1-1/4”-12 UNF LOCKNUT . . . . . . . . 1 BUSHING 2.0X2.25X2.0” . . . . . . . . 1 TUBE WELDMENT . . . . . . . . . . . . . 1 OIL LINE TUBE ASSEMBLY . . . . . . 1 COUNTER-BALANCE VALVE. . . . . 2 SEAL KIT (CBV) . . . . . . . . . . . . . . . 1 CYLINDER SEAL KIT . . . . . . . . . . . 1 (Items included are not shown.)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Lift Cylinder 1

2

7

6

5 3 Cylinder Part Number Stamped Here

4 8

External Threads

10

11

9

50960084/AP0914

186

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Lift Cylinder

Item No.

Part No.

Description

Qty. Req.

01

L63199

Note: 02 03 04 05 06

Quantities shown are for one cylinder.

L98518 ROD WELDMENT . . . . . . . . . . . . . . 1 L98520 HEAD GLAND CAP. . . . . . . . . . . . . 1 L99857 5/16”-18X1/4” SET SCREW . . . . . . 1 L98522 HEAD GLAND . . . . . . . . . . . . . . . . . 1 L98523 PISTON . . . . . . . . . . . . . . . . . . . . . . 1

PRINTED IN U.S.A.

CYLINDER, LIFT . . . . . . . . . . . . . . 2

Item No.

Part No.

07 08 09

L99405 NSS L98519

10

L64175 L97889 L98521

11

187

Description

Qty. Req.

1-1/4”-12 UNF LOCKNUT . . . . . . . . 1 TUBE WELDMENT . . . . . . . . . . . . . 1 OIL LINE TUBE ASSEMBLY . . . . . . 1 (includes nuts and ferrules) COUNTER-BALANCE VALVE. . . . . 1 SEAL KIT (CBV) . . . . . . . . . . . . . . . 1 CYLINDER SEAL KIT . . . . . . . . . . . 1 (Items included are not shown.)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Slave Cylinder

1

2

3

8 7

6 5 4 Cylinder Part Number Stamped Here

External Threads

9 10 11

50960084/AP0914

188

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Slave Cylinder

Item No. 01 02 03 04 05 06

Part No. L63014 L98524 L63018 L99857 L98513 L98528

PRINTED IN U.S.A.

Description

Qty. Req.

CYLINDER, SLAVE . . . . . . . . . . . . 1 ROD WELDMENT (includes #3) . . . 1 BUSHING . . . . . . . . . . . . . . . . . . . . 1 5/16”-18X1/4” SET SCREW . . . . . . 1 HEAD GLAND CAP. . . . . . . . . . . . . 1 HEAD GLAND . . . . . . . . . . . . . . . . . 1

Item No.

Part No.

07 08 09 10 11

L98516 L500668 L68003 NSS L98527

189

Description

Qty. Req.

PISTON . . . . . . . . . . . . . . . . . . . . . . 1 1-1/8”-12 UN LOCKNUT . . . . . . . . . 1 BUSHING . . . . . . . . . . . . . . . . . . . . 1 TUBE WELDMENT . . . . . . . . . . . . . 1 CYLINDER SEAL KIT . . . . . . . . . . . 1 (Items included are not shown.)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Tilt Cylinder

1

2

3

8 7

6 5 4

Cylinder Part Number Stamped Here

9

External Threads

10

11

12

50960084/AP0914

13

190

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Tilt Cylinder

Item No. 01 02 03 04 05 06 07 08

Part No. L63013 L98545 L63018 L99857 L98547 L99866 L98550 L99405

PRINTED IN U.S.A.

Description

Qty. Req.

CYLINDER, TILT . . . . . . . . . . . . . . 1 ROD WELDMENT (includes #3) . . . 1 BUSHING . . . . . . . . . . . . . . . . . . . . 1 5/16”-18X1/4” SET SCREW . . . . . . 1 HEAD GLAND CAP. . . . . . . . . . . . . 1 HEAD GLAND . . . . . . . . . . . . . . . . . 1 PISTON . . . . . . . . . . . . . . . . . . . . . . 1 1-1/4”-12 UN LOCKNUT . . . . . . . . . 1

Item No.

Part No.

09 10 11 12

NSS L68003 L70495 L97889 L98548

13

L98551

191

Description

Qty. Req.

TUBE WELDMENT . . . . . . . . . . . . . 1 BUSHING . . . . . . . . . . . . . . . . . . . . 1 COUNTER-BALANCE VALVE. . . . . 1 SEAL KIT (CBV) CYLINDER SEAL KIT . . . . . . . . . . . 1 (Items included are not shown.)

HYDRAULIC LINE ASSEMBLY. . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Boom-Extend Cylinder

1

2 8

3 7

Cylinder Part Number Stamped Here

9

6 5 4

10

11

External Threads

13 12

50960084/AP0914

192

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Boom-Extend Cylinder

Item No. 01 02 03 04 05 06 07 08

Part No. L63012 L98511 L63018 L99857 L98513 L98515 L98516 L500668

PRINTED IN U.S.A.

Description

Qty. Req.

CYLINDER, BOOM EXTEND . . . . . 1 ROD WELDMENT (includes #3) . . . 1 BUSHING . . . . . . . . . . . . . . . . . . . . 1 5/16”-18X1/4” SET SCREW . . . . . . 1 HEAD GLAND CAP. . . . . . . . . . . . . 1 HEAD GLAND . . . . . . . . . . . . . . . . . 1 PISTON . . . . . . . . . . . . . . . . . . . . . . 1 1-1/8”-12 UN LOCKNUT . . . . . . . . . 1

Item No.

Part No.

09 10 11

L68003 NSS L48868A L96838 L98517 L98558

12 13

193

Description

Qty. Req.

BUSHING . . . . . . . . . . . . . . . . . . . . 1 TUBE WELDMENT . . . . . . . . . . . . . 1 COUNTER-BALANCE VALVE. . . . . 1 SEAL KIT (CBV) HYDRAULIC LINE ASSY. . . . . . . . . 1 CYLINDER SEAL KIT . . . . . . . . . . . 1 (Items included are not shown.)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Hydraulic Components

RS6-34 Telescopic Handler

Fork-Shift Cylinder

1

2 4

5

3

6 7

Item No. 01 02 03 04

Part No. L68337 L500763 L500762 L500761

50960084/AP0914

Description

Qty. Req.

CYLINDER, FORK-SHIFT . . . . . . . 1 ROD WELDMENT . . . . . . . . . . . . . . 1 HEAD GLAND . . . . . . . . . . . . . . . . . 1 PISTON . . . . . . . . . . . . . . . . . . . . . . 1

Item No.

Part No.

05 06 07

L500367 NSS L500370

194

Description

Qty. Req.

3/4”-16 UNF LOCKNUT. . . . . . . . . . 1 TUBE WELDMENT . . . . . . . . . . . . . 1 SEAL KIT . . . . . . . . . . . . . . . . . . . . . 1 (Items included are not shown.)

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Hydraulic Components Rotating-Carriage Cylinder 1

2 10 9 3

8 7

6 4

5

13 11

12

Item No. 01 02 03 04 05 06 07 08

Part No. L63594 L99168 L63593 121554 L99857 121554 L99174 L99175

PRINTED IN U.S.A.

Description

Qty. Req.

CYLINDER, ROTATING . . . . . . . . . 1 ROD WELDMENT (includes #3) . . . 1 BUSHING . . . . . . . . . . . . . . . . . . . . 1 HEAD GLAND CAP. . . . . . . . . . . . . 1 5/16”-18X1/4” SET SCREW . . . . . . 1 HEAD GLAND . . . . . . . . . . . . . . . . . 1 SPACER, ROD . . . . . . . . . . . . . . . . 1 SUPPORT WASHER. . . . . . . . . . . . 1

Item No.

Part No.

09 10 11

121552 L500367 L64175 L97889 NSS L99170

12 13

195

Description

Qty. Req.

PISTON . . . . . . . . . . . . . . . . . . . . . . 1 3/4”-16 UN LOCKNUT. . . . . . . . . . . 1 COUNTER-BALANCE VALVE. . . . . 2 SEAL KIT (CBV) TUBE WELDMENT . . . . . . . . . . . . . 1 CYLINDER SEAL KIT . . . . . . . . . . . 1 (Items included are not shown.)

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Attachments

RS6-34 Telescopic Handler

Carriage Forks

6

5

4

Forks with 2” Shaft Bore

3 2

1

48” Long

42” Long

9

8 7

72” Long 60” Long

50960084/AP0914

196

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Attachments Carriage Forks

Item No.

Part No.

01 02a 03 04 05 06

L71350 L61001 L61017 L66406 L400929 L47263

Description FORK, FORK, FORK, FORK, FORK, FORK,

Qty. Req.

42”X4”X2” (8,400 lbs.) . . . . . 2 48”X2”X2” (4,200 lbs.) . . . . . 4 48”X4”X2” (8,400 lbs.) . . . . . 2 48”X4”X2-1/4” (12,000 lbs.). 2 48”X5”X1-3/4” (8,500 lbs.). . 2 48”X5”X2” (10,500 lbs.) . . . . 2

Item No.

Part No.

Description

07 08 09

L47265 L60961 L68331

a

Requires 2 sets (4 forks).

Qty. Req.

FORK, 60”X5”X2” (10,500 lbs.) . . . . 2 FORK, 60”X6”X2-1/4” (12,500 lbs.). 2 FORK, 72”X5”X2” (10,500 lbs.) . . . . 2

NOTE: Ratings are based on two forks with the load at 24” on center, except for item 2, for which four forks are required.

WARNING When ordering forks, select forks with a rating capacity that meets or exceeds the lifting capacity of the machine; failure to use the correct forks could result in injury or death.

For more information contact dealer (or manufacturer).

PRINTED IN U.S.A.

197

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Attachments

RS6-34 Telescopic Handler

Standard Carriage

1

2

3 4

5

50960084/AP0914

198

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Attachments Standard Carriage

Item No.

Part No.

01 L99192 L99193 02 L63319 L63320

PRINTED IN U.S.A.

Description

Qty. Req.

CARRIAGE, WELDMENT . . . . . . . . 1 48” Carriage 66” Carriage FORK SHAFT BAR . . . . . . . . . . . . . 1 48” Carriage (50-1/2”) 66” Carriage (68-1/2”)

Item No.

Part No.

03 04 05

L400425 067847 650493

199

Description

Qty. Req.

WASHER, FORK SHAFT . . . . . . . . 2 HLN INST 3/8 CZY . . . . . . . . . . . . . 2 3/8”-16X2-3/4” BOLT . . . . . . . . . . . . 2

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Attachments

RS6-34 Telescopic Handler

Fork-Shift Carriage

1

19 20

18

13 15 15 17

2

11

9

12

16

10

9 8

7 6 5 2 3 4

50960084/AP0914

200

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Attachments Fork-Shift Carriage

Item No. 01 02 03 04 05 06 07 08 09

Part No. L500215 L50519 L400425 L50333 L66919 L66931 650500 L66921 L66948 L63715

PRINTED IN U.S.A.

Description

Qty. Req.

FORK SHIFT CARRIAGE FRAME . 1 3/4”-10 NYLON INSERT NUT . . . . . 3 FORK SHAFT WASHER . . . . . . . . . 1 3/4”-10X3” BOLT . . . . . . . . . . . . . . 1 FORK SHAFT, 50” . . . . . . . . . . . . . . 1 FORK SLIDE PLATE . . . . . . . . . . . . 2 3/4”-10X1-1/2” BOLT . . . . . . . . . . . . 1 FORK SLIDE COUPLER. . . . . . . . . 1 Used with 4” wide forks Used with 5” wide forks TWIN CUSHION TOP PLATE . . . . . 2

Item No.

Part No.

10 11 12 13 15 16 17 18 19 20

L50242 L63716 L520004 L65273 L66918 L68337 L50562 L63143 L66950 L66949

201

Description

Qty. Req.

5/16”-18X2-1/4” BOLT . . . . . . . . . . . 2 TWIN HOSE CUSHION. . . . . . . . . . 1 5/16”-18 NYLON INSERT NUT . . . . 2 QUICK COUPLER SET. . . . . . . . . . 1 CYLINDER MOUNT . . . . . . . . . . . . 2 FORK SHIFT CYLINDER . . . . . . . . 1 3/4”-10X4” BOLT . . . . . . . . . . . . . . . 2 ADAP -8ORM -6JICM W/.06 ORF . 2 HOSE -6 A6/A6 59” . . . . . . . . . . . . . 1 HOSE -6 A6/A6 56” . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Attachments

RS6-34 Telescopic Handler

Rotating Carriage

1

3 4 5

3

2 10 11

21 4

10 7

11

12 18

20

5

8 6

9

17 16

12

13 13 19

50960084/AP0914

15

14

202

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Attachments Rotating Carriage

Item No.

Part No.

01 L99225 L99224 02 03 04 05 06 07 08 09 10

L63319 L63320 650493 L400425 067847 L50205 L61287 651625 654026 L61709 L65273

PRINTED IN U.S.A.

Description

Qty. Req.

ROTATE CARRIAGE, FRAME . . . . 1 48” Carriage 66” Carriage FORK SHAFT BAR . . . . . . . . . . . . . 1 48” Carriage (50-1/2” long) 66” Carriage (68-1/2” long) 3/8”-16X2-3/4” BOLT . . . . . . . . . . . . 2 RETAINER. . . . . . . . . . . . . . . . . . . . 2 HLN INST 3/8 CZY . . . . . . . . . . . . . 2 2”-12 CASTELLATED NUT . . . . . . . 1 WASHER (not shown) . . . . . . . . . . 1 3/8”-16X1-1/4” BOLT” . . . . . . . . . . . 6 3/8” LOCK WASHER . . . . . . . . . . . . 6 SLIDE PAD 3”X4” . . . . . . . . . . . . . . 3 QUICK COUPLER SET. . . . . . . . . . 1 (includes both couplers)

Item No.

Part No.

11

L63143

12 13 14 15a 16 17 18a

L63344 L51968 067847 L63968 650493 L63594 L63969 650650 068034 NSS L63952 L64367

19 20 21

203

Description

Qty. Req.

ADAP., -8ORM -6JICM STR.. . . . . . 2 (with orifice) HOSE, -6 A8/A6 20” . . . . . . . . . . . . 2 ADAP., -6ORM -6JICM 90º . . . . . . . 2 HLN INST 3/8 CZY . . . . . . . . . . . . . 1 BASE END PIVOT PIN . . . . . . . . . . 1 3/8”-16X2-3/4” BOLT . . . . . . . . . . AR ROTATE CYLINDER . . . . . . . . . . . . 1 ROD END PIVOT PIN . . . . . . . . . . . 1 1/2”-13X3-1/2” BOLT . . . . . . . . . . . 1 HLN INST 1/2 CZY . . . . . . . . . . . . . 1 ROTATE PIN (welded to #20). . . . . 1 ROTATE, PLATE (includes #19). . . 1 BUSHING (not shown) . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Attachments

RS6-34 Telescopic Handler

Truss Booms and Bucket

1 8’ Truss Boom

26 25

2 5’ Truss Boom

24

7 Hydraulic Winch With Brake 27

6

23

19 18

17

15

16

14

11

4 3

13 9

22 21

20

12

5 10

50960084/AP0914

204

9

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Attachments Truss Booms and Bucket

28

Item No. 01 02 03 04 05

Part No.

06 07 09 10 11a 12 13 14 15 16 17 18 19 20b

L99237 104835 L64294 114742 650706 L520003 054626 L65273 054816 L82358 100963 650569 068034 089099 L400398 650733 100076 L520004 L65338 L66946

21

650492

PRINTED IN U.S.A.

Description

Qty. Req.

8’ TRUSS BOOM WELDMENT . . . . 1 5’ TRUSS BOOM WELDMENT . . . . 1 HOSE -8 A8/A8 53” . . . . . . . . . . . . . 2 ADAP -8ORM -8JICM RUN TEE. . . 1 1/4-20”X2” BOLT . . . . . . . . . . . . . . . 2 1/4”-20 NYLON INSERT NUT . . . . 2 ADAP -8ORM -8JICM STR . . . . . . . 2 QUICK COUPLER SET. . . . . . . . . . 1 ADAP -8ORM -8JICM 90º . . . . . . . . 2 RELIEF VALVE . . . . . . . . . . . . . . . . 1 HYDRAULIC WINCH. . . . . . . . . . . . 1 1/2”-13X1-3/4” GR 8 BOLT . . . . . . . 6 HLN INST 1/2 CZY . . . . . . . . . . . . . 6 ADAP -10ORM -8JICM . . . . . . . . . . 2 HOSE -6 A8/A8 18.5” . . . . . . . . . . . 2 5/16”X2-1/2” BOLT . . . . . . . . . . . . . 2 PIN, TRUSS WINCH . . . . . . . . . . . . 1 5/16”-18 NYLON INSERT NUT . . . . 2 WINCH SHEAVE . . . . . . . . . . . . . . . 1 3/8”X60’ WINCH CABLE . . . . . . . . . 1 (Includes hook and swivel) 3/8”X2-1/2” BOLT . . . . . . . . . . . . . . 2

Item No.

Part No.

22 23 24 25 26 27c 28

654026 L60451 L61411 L50380 654030 088442 L500373 L68831

3/8” LOCK WASHER . . . . . . . . . . . . 2 WINCH BALL. . . . . . . . . . . . . . . . . . 1 PINTLE HOOK . . . . . . . . . . . . . . . . 1 1/2”-20X1-1/4” GR 8 BOLT . . . . . . . 4 1/2” LOCK WASHER . . . . . . . . . . . . 4 ADAP -8JICFS -8JICM 90º . . . . . . . 2 1.3 CU. YD. BUCKET WELDMNT . 1 CUTTING EDGE 98” (weld on) . . . . 1

00

L500222

-- ITEMS NOT SHOWN -ADAPTER PLATE. . . . . . . . . . . . . . 1

a

Used with 5’ truss booms after attachment serial number 11182. The winch on 5’ truss booms before attachment serial number 11183 have been discontinued; you must purchase a boom and a winch.

b

Used with 5’ truss booms with winch.

c

Not used on some attachments.

205

Description

Qty. Req.

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Decals

RS6-34 Telescopic Handler

General Information and Application Instructions

GENERAL INFORMATION NEW DECAL APPLICATION

CAUTION ALWAYS follow the safety precautions on decals. Replace decals if they are damaged, or if the unit is repainted. If repainting, be sure that all applicable decals are affixed in their proper locations.

Decal location information is provided to assist in the proper selection and application of new decals, in the event original decals become damaged or the machine is repainted.

For correct replacement of decals, compare the location illustrations to your machine before starting to refinish the unit. Check off each required decal using the illustration reference number to find the part number, description and quantity in the list. Refer to the appropriate illustration for replacement locations.

If there is a decal on a part that is to be replaced, be sure that a new decal is applied to the replaced part.

Before applying the new decals, surfaces must be free from dirt, dust, grease and other foreign material. To apply a solid-formed decal, remove the smaller portion of the decal backing paper and apply this part of the exposed adhesive backing to the clean surface while maintaining proper position and alignment. Slowly peel off the other portion of the backing paper while applying hand pressure to smooth-out decal surface. To apply a die-cut decal, first remove the backing paper. Then, properly orient and position the decal onto the clean mounting surface. After the decal is firmly applied and smoothly pressed down, remove the front covering paper.

Paint Finish Use this list to order paint for refinishing: 167788 167789 167754 167755

One Gallon Yellow 6 (12 oz. Spray Cans) Yellow One Gallon Gun-Metal Gray 6 (12 oz. Spray Cans) Gun-Metal Gray

Decal Kits 104916 104917

RS6-34 Telescopic Handler w/o PWP RS6-34 Telescopic Handler w/ PWP

Boom Attachment Decals L65927 L65348 L66042

50960084/AP0914

206

WARNING - PINCH POINT WARNING - WINCH WARNING - TRUSS BOOM TILT

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Decals Frame and Boom

3 6 10 7 2 11

1 2 5

2 4

9 8

Item No. 01 02 03 04 05 06

Part No. L70305 L65927 184069 137632 L65932 102026

PRINTED IN U.S.A.

Description

Qty. Req.

DANGER - HANDS OUT . . . . . . . AR WARNING - PINCH POINT . . . . . AR GEHL, 6-3/4” . . . . . . . . . . . . . . . . AR HYDRAULIC OIL FILL . . . . . . . . . AR WARNING - NO RIDERS . . . . . . . AR GEHL, 2”. . . . . . . . . . . . . . . . . . . . AR

Item No.

Part No.

07

L65928

08 09 10 11

L66613 50301416 104872 L65942

207

Description

Qty. Req.

DANGER - PERSONAL INJURY . AR (units without PWP) DYNATTACH UNLOCKED . . . . . . AR DIESEL FUEL. . . . . . . . . . . . . . . . AR RS6-34, RIGHT HAND . . . . . . . . . AR HOT SURFACE . . . . . . . . . . . . . . AR

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Decals

RS6-34 Telescopic Handler

Frame and Boom

9

2

6

8

9

18

2 2

5

4 14 16

13

11

17 1 12 2 10 7

50960084/AP0914

208

3

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Decals Frame and Boom

Item No. 01 02 03 04 05 06 07 08 09

Part No. L70305 L65927 L65933 102027 L65937 184069 056859 L62583 L67718 L67719 L67720 L67721 L67722 L67723

PRINTED IN U.S.A.

Description

Qty. Req.

DANGER - HANDS OUT . . . . . . . AR WARNING - PINCH POINT . . . . . AR WARNING - JUMP START. . . . . . AR GEHL, 5”. . . . . . . . . . . . . . . . . . . . AR DYNATTACH DIAGRAM . . . . . . . AR GEHL, 6-3/4” . . . . . . . . . . . . . . . . AR ANTI-FREEZE . . . . . . . . . . . . . . . AR HALF ZONE MARKER . . . . . . . . . . 5 NO. “0” EXTENSION MARKER . . . 1 NO. “1” EXTENSION MARKER . . . 1 NO. “2” EXTENSION MARKER . . . 1 NO. “3” EXTENSION MARKER . . . 1 NO. “4” EXTENSION MARKER . . . 1 NO. “5” EXTENSION MARKER . . . 1

Item No.

Part No.

10 11 12 13 14

072798 L65932 L63474 100359 L65928

16 17 18

103229 104871 184043

209

Description

Qty. Req.

COOLANT UNDER PRESSURE. . . 1 WARNING - NO RIDERS . . . . . . . AR BRAKE FLUID . . . . . . . . . . . . . . . AR OPERATOR MANUAL WARNING. . 1 DANGER - PERSONAL INJURY . AR (units without PWP) LUBE CHART . . . . . . . . . . . . . . . . . 1 RS6-34 LEFT HAND . . . . . . . . . . . . 1 GEHL, 3.75". . . . . . . . . . . . . . . . . . . 1

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Decals

RS6-34 Telescopic Handler

Cab 5 7 3

4 12 11 6

1

7 7

8

9

13

10

14

Dual Hydraulic Controllers (Standard)

Tri-function Hydraulic Controllers (Option)

DECAL LOCATIONS - OPERATOR STATION Item No.

Part No.

01

L70306

02 03 04 05 06

L65930 L65926 L68295 140516 101506

07

104875 104876 104877 104878 104879 104880

50960084/AP0914

Description

Qty. Req.

WARNING - TILT HAZARD . . . . . . . 1 /GENERAL OPERATOR WARNING - MACHINE LEVEL . . . . 1 WARNING - CARRY LOAD LOW . . 1 F-N-R SHIFT . . . . . . . . . . . . . . . . . . 1 MADE IN U.S.A. . . . . . . . . . . . . . . . 1 WARNING - PARK BRAKE . . . . . . . 1 /SEAT BELT -- LOAD CHARTS-STANDARD CARRIAGE . . . . . . . . . 1 ROTATING CARRIAGE . . . . . . . . . 1 BUCKET LOAD CHART . . . . . . . . . 1 TRUSS BOOM LOAD CHART . . . . 1 WINCH LOAD CHART . . . . . . . . . . 1 PWP LOAD CHART . . . . . . . . . . . . 1

Item No.

Part No.

08 09 10 11 12

L63632 L63631 102718 102717 L70307

13 14 00

210

Description

Qty. Req.

ATTACHMENT TILT/FRAME LVL . . 1 BOOM CONTROL . . . . . . . . . . . . . . 1 AUX. HYD. CONTROL (optional) . . 1 IGNITION/START/HORN. . . . . . . . . 1 DANGER-HIGH VOLTAGE . . . . . . . 1 /MOVING PARTS

-- OPTIONAL TRI-FUNCTION CONTROLLER -104215 JOYSTICK CONTROL . . . . . . . . . . 1 L63311 SWAY CONTROL . . . . . . . . . . . . . . 1 L71378 VALVE ADJUSTMENT. . . . . . . . . . . 1 (not shown - attaches to pilot valve)

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Decals PWP Equipped Units

2 5

1

6 3

1

4

DECAL LOCATIONS - PWP EQUIPPED UNITS Item No.

Part No.

01 02

L71554 L71555

03

L71700

PRINTED IN U.S.A.

Description

Qty. Req.

WARNING - PERSONNEL LIFT. . AR WARNING - WORK PLATFORM . AR /RULES PERSONNEL LIFT SAFETY . . . . AR /RULES

Item No.

Part No.

04 05 06

104880 102969 103028

211

Description

Qty. Req.

PWP LOAD CHART . . . . . . . . . . . AR PWP SWITCH . . . . . . . . . . . . . . . AR PWP SYSTEM . . . . . . . . . . . . . . . AR

50960084/AP0914

http://www.minnpartelehandlerparts.com/

NUMERICAL INDEX

Numerical Index Part No. 054626 054626 054626 054626 054626 054626 054816 054816 054816 054816 054816 054819 054820 054820 054820 054820 054820 054820 054994 054994 054994 055005 055005 055030 055064 055064 055648 056859 062023 064260 065415 067823 067826 067847 067847 067847 067847 068034 068034 068034 068034 068034 068938 068938 070648 071043 071244 071245 071401 071703 072587 072798 072806 072806 076031 076143 076143 076143 076147 076880

Page No. 27 101 103 133 135 205 53 67 127 129 205 77 141 143 159 161 163 165 27 51 103 69 135 69 69 135 55 209 69 31 41 77 63 07 09 17 203 51 53 119 203 205 141 143 43 65 55 55 67 65 137 209 141 143 137 127 135 137 133 129

50960084/AP0914

Item No. 17 21 02 08 31 06 12 29 07 03 09 14 05 05 05 05 05 05 09 30 06 03 13 10 09 14 04 07 21 12 08 11 11 24 03 14 14 20 06 21 18 13 04 04 13 13 24 25 04 09 18 10 11 11 19 10 33 20 07 22

Part No. 079026 079026 079026 079026 079209 081377 081379 087852 087852 088442 088442 088442 088442 089099 089888 090666 090666 090666 090666 090666 090666 091039 091039 091039 091039 091039 091039 091039 091039 091039 091039 091039 095457 095457 095955 100011 100011 100012 100076 100359 10071 100963 101278 101436 101495 101506 101550 101667 101712 101719 101727 101746 101792 101877 101879 101882 101882 101882 101882 101882

RS6-34 Telescopic Handler Page No. 27 101 103 135 49 71 51 53 67 101 103 135 205 205 43 39 49 55 69 119 135 101 103 141 143 149 153 157 159 161 163 165 101 103 41 101 103 135 205 209 23 205 19 17 13 210 07 08 09 17 11 17 17 21 51 25 27 101 103 135

Item No. 06 02 04 18 17 05 13 10 15 11 09 32 27 14 03 15 11 17 07 40 22 07 12 06 06 05 05 07 06 06 06 06 05 14 02 10 10 25 17 13 12 11 05 22 24 06 30 05 04 19 13 32 20 06 01 10 01 22 01 03

Part No. 101882 101954 102026 102027 102262 102313 102313 102313 102321 102321 102408 102529 102572 102573 102575 102575 102576 102576 102576 102576 102583 102587 102587 102601 102614 102615 102617 102618 102619 102620 102621 102622 102623 102624 102625 102626 102627 102628 102632 102633 102634 102635 102636 102637 102647 102668 102674 102680 102681 102692 102705 102711 102712 102717 102718 102722 102727 102728 102741 102769

212

Page No. 172 55 207 209 69 101 147 149 59 151 58 29 49 106 106 111 106 107 111 115 111 99 111 111 111 111 108 108 108 108 108 108 108 108 108 108 108 108 108 108 108 108 108 108 49 99 177 17 17 07 17 15 15 210 210 11 07 07 08 07

Item No. 01 26 06 04 24 01 07 13 02 10 02 21 — 03 07 08 08 08 09 24 21 07 20 37 04 06 01 02 03 04 05 06 07 09 10 11 12 13 19 20 21 24 24 24 — 22 05 03 04 06 02 03 10 11 10 20 32 31 03 29

Part No.

Page No.

102778 102780 102780 102781 102831 102831 102831 102831 102831 102831 102840 102840 102842 102842 102843 102843 102863 102863 102874 102880 102881 102886 102893 102901 102907 102907 102925 102928 102944 102945 102948 102949 102950 102951 102952 102952 102953 102954 102954 102955 102956 102957 102959 102969 103013 103014 103017 103019 103021 103022 103022 103023 103023 103024 103024 103025 103026 103027 103028 103029

07 08 08 08 141 143 159 161 163 165 31 103 31 101 141 143 113 117 17 07 07 17 111 17 35 41 13 17 35 35 17 81 97 97 97 97 97 97 97 97 97 97 97 211 13 17 167 11 07 07 11 07 11 07 11 15 15 15 211 11

Item No. 28 01 07 04 10 10 10 10 10 10 06 15 01 09 14 14 22 22 01 13 23 21 22 12 01 15 — 15 03 04 20 10 01 02 03 08 04 05 09 06 07 10 12 05 — — 02 12 11 10 11 19 09 20 10 08 09 01 06 19

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

103033 103077 103078 103083 103084 103099 103099 103100 103100 103100 103100 103101 103104 103112 103112 103113 103113 103114 103114 103115 103115 103116 103116 103117 103117 103122 103122 103179 103180 103192 103221 103221 103221 103229 103262 103262 103263 103263 103263 103263 103263 103263 103263 103263 103264 103264 103264 103264 103264 103264 103264 103264 103264 103315 103315 103315 103315 103315 103315 103315

Page No. 35 183 183 183 183 21 21 21 21 21 21 49 21 177 179 177 179 177 179 177 179 177 179 177 179 177 179 13 13 09 21 21 21 209 139 147 139 147 149 151 153 155 157 179 33 139 153 157 159 161 163 165 183 51 141 143 147 151 153 155

PRINTED IN U.S.A.

Item No. 11 02 04 07 03 26 28 22 23 24 25 19 12 03 03 04 04 06 05 07 06 08 07 11 10 02 02 — — —29 30 31 16 03 01 02 02 02 02 02 02 02 01 07 01 16 05 02 02 02 02 01 26 09 09 06 06 12 05

Part No. 103315 103315 103315 103315 103315 103317 103317 103318 103318 103318 103319 103319 103330 103330 103330 103330 103331 103331 103331 103331 103333 103368 103368 103368 103368 103368 103368 103368 103368 103390 103391 103392 103393 103394 103395 103396 103398 103399 103401 103401 103402 103403 103403 103403 103404 103404 103404 103425 103475 103476 103505 103505 103505 103505 103505 103582 103675 103708 103873 103991

Page No. 157 159 161 163 165 101 135 51 135 141 27 101 119 123 129 133 119 123 129 133 119 51 135 155 157 159 161 163 165 108 108 108 111 111 111 111 111 111 111 115 113 177 179 183 177 179 183 145 61 61 145 155 157 163 165 33 07 33 47 51

Item No. 09 07 07 07 07 03 17 27 15 12 07 12 42 05 14 14 43 06 13 13 37 29 19 12 13 15 17 15 17 16 17 18 07 03 16 28 25 47 49 50 11 09 08 05 10 09 06 07 08 09 03 14 16 18 20 04 11 11 11 11

Part No. 104064 104078 104111 104111 104111 104214 104215 104219 104222 104222 104304 104304 104504 104504 104518 104546 104600 104600 104604 104604 104607 104621 104641 104641 104642 104642 104655 104655 104688 104736 104769 104835 104846 104871 104872 104875 104876 104877 104878 104879 104880 104880 104916 104917 104932 104950 104951 104952 105087 105236 105266 105266 105266 105266 105287 105580 105580 105580 105580 105580

213

Page No. 59 59 31 101 103 33 210 33 45 47 33 181 111 115 106 115 111 115 111 115 108 108 111 115 111 115 108 109 07 175 21 205 11 209 207 210 210 210 210 210 210 211 206 206 71 09 09 09 167 25 113 113 117 117 29 33 141 143 159 161

Item No. — 03 08 15 17 06 13 08 11 13 02 13 48 39 04 44 44 34 36 28 26 25 45 35 46 36 22 11 — 03 27 02 15 17 10 07 07 07 07 07 07 04 00 00 03 — — 06 04 07 10 14 10 14 05 — — — — —

Part No. 105580 105580 105593 105593 105593 105636 105857 105910 105958 105958 105960 106001 106175 106259 106892 106893 106898 106898 107000 110227 110227 114742 121387 121387 121552 121554 121554 122778 126862 129124 131529 131529 131951 132023 132023 133074 133444 135425 135425 136305 136305 136310 137503 137503 137602 137603 137632 137784 137784 137784 138459 138459 138623 138649 138651 138714 138777 138778 138779 139170

Page No. 163 165 143 161 165 07 99 63 111 115 21 21 81 97 174 174 141 143 171 53 67 205 129 137 195 195 195 51 131 145 51 53 75 05 63 69 63 63 77 35 37 35 35 37 19 19 207 27 135 145 41 41 37 39 39 39 39 39 39 13

Item No. — — 18 16 16 07 04 18 18 22 15 11 26 11 06 04 15 15 04 08 30 04 24 22 09 04 06 31 05 05 21 15 01 01 03 23 04 09 09 07 12 13 16 05 19 20 04 02 02 04 03 09 07 11 14 10 02 03 07 16

50960084/AP0914

NUMERICAL INDEX

Part No.

Numerical Index

http://www.minnpartelehandlerparts.com/

NUMERICAL INDEX

Numerical Index Part No. 139279 139952 140516 167754 167755 167788 167789 184043 184069 184069 186193 186703 187841 188973 189033 189049 190091 191192 191352 193856 195740 201179 210018 210148 210170 210-19469 210-19469 210-19470 210-19470 210328 210329 210403 210404 210405 210447 210569 210569 210572 210572 210608 210609 210614 210722 210765 210796 210796 210796 210797 210828 210828 210828 210833 211010 211023 211035 211039 211045 211052 211145 211146

Page No. 37 65 210 206 206 206 206 209 207 209 41 41 35 77 37 37 73 55 55 55 55 37 171 69 23 31 55 07 07 29 69 23 23 23 57 57 99 57 99 29 29 21 53 43 37 39 41 21 31 101 103 43 39 37 43 43 43 43 37 05

50960084/AP0914

Item No. 13 07 05 00 00 00 00 18 03 06 12 14 05 04 14 11 01 09 03 12 13 18 02 06 01 04 06 25 36 15 16 23 25 24 10 12 11 13 14 20 25 09 02 12 01 17 01 07 03 19 19 14 04 17 06 02 08 01 02 09

Part No. 211146 211147 211148 211149 211161 219274 230209 230-32195 230-32195 230-32195 230-32364 240202 241010 241385 242145 242875 243008 243063 243319 244655 271491 271491 271601 271601 271869 272299 272546 272578 272648 273968 420-19671 420-19671 420-35602 420-36290 50220227 50220264 50220264 50220265 50220265 50220266 50220266 50220267 50220267 50220500 50220501 50220511 50220511 50220515 50220553 50220574 50220575 50220612 50220613 50220626 50220627 50220628 50220629 50220630 50220631 50220632

RS6-34 Telescopic Handler Page No. 37 37 37 37 174 07 41 31 101 103 31 174 65 65 37 37 41 13 55 174 05 65 63 77 23 73 41 19 21 35 58 69 43 37 71 104 105 104 105 104 105 104 105 75 75 05 63 63 63 75 75 05 05 61 61 61 61 61 175 175

Item No. 03 01 06 04 09 34 17 02 14 20 05 03 10 08 08 09 16 25 23 03 13 16 08 06 15 05 04 15 03 06 06 15 09 10 04 02 02 01 01 03 03 02 02 16 16 12 13 06 05 07 08 03 04 07 06 05 02 03 04 04

Part No. 50220633 50220634 50220635 50220719 50220757 50220759 50220761 50220762 50280186 50280186 50280187 50288223 50300066 50300066 50300327 50300449 50300449 50300462 50300462 50300466 50301039 50301134 50301159 50301357 50301416 50301444 50301444 50302119 50302155 50302155 50302155 50302155 50302200 50302203 50302216 50302228 50302313 50302437 50302438 50302441 50302441 50302457 50302496 50302785 50303155 50303791 50303793 50303794 50303801 50303802 50303845 50303847 50304028 50304225 50304231 50304281 50304354 50304708 50304736 50304759

214

Page No. 175 175 175 73 21 71 71 78 19 23 19 67 35 37 67 53 67 53 67 63 63 55 65 55 207 69 77 07 131 133 137 137 75 67 65 77 73 67 67 05 67 69 41 63 41 67 67 67 67 67 67 05 21 73 73 21 55 19 49 47

Item No. 04 02 02 10 14 02 07 01 16 15 17 17 07 12 26 09 14 13 25 16 07 01 04 10 09 08 05 37 11 22 21 23 10 13 03 03 08 11 23 05 12 02 07 20 06 08 09 07 06 05 28 02 — 02 04 — 28 18 10 07

Part No.

Page No.

50304788 50304791 50304797 50304798 50304811 50304812 50304821 50304852 50304898 50304898 50304898 50304898 50304907 50304911 50304956 50304958 50304958 50304962 50304965 50304972 50304972 50305017 50305161 50305208 50305209 50305570 50305578 50305581 50305598 50305606 50305607 50305621 50305830 50306017 50306490 50351477 50351523 50352428 50352428 50352454 50352454 50352455 50352455 50380273 50380273 50380274 50380306 50380450 50380516 50380576 50380577 50380583 50380587 50380592 50380594 50380595 50380595 50380682 50380734 50380737

47 47 47 47 49 49 47 77 27 27 103 103 47 67 63 53 67 67 67 53 67 77 19 39 39 41 39 65 39 61 43 39 41 51 41 73 67 39 65 05 73 05 73 145 175 61 19 51 51 13 13 13 63 63 69 69 71 13 07 07

Item No. 06 05 14 15 15 14 08 13 10 11 07 08 01 03 21 14 22 16 32 11 31 01 02 08 05 13 16 01 09 16 15 — 05 08 20 09 02 06 17 06 12 07 13 06 01 01 01 02 18 02 01 04 01 12 20 01 01 02 01 27

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

50380743 50380743 50380743 50380743 50380743 50380745 50380746 50380751 50380753 50380754 50380756 50380756 50380756 50380757 50380757 50380757 50380757 50380757 50380779 50380789 50380789 50380825 50380826 50380836 50380841 50380843 50380843 50380847 50380852 50380853 50380894 50380901 50381061 50381079 50381095 50381095 50381095 50381115 50381150 50381156 50381160 50381161 50381167 50381171 50381174 50381198 50381201 50381202 50381217 50381223 50381224 50381224 50381229 50381236 50381241 50381259 570019 570019 650315 650347

Page No. 29 31 101 103 173 99 99 21 21 31 131 137 137 129 129 133 133 137 25 59 61 61 61 61 29 135 166 35 23 23 29 77 53 135 31 101 103 29 75 51 69 69 55 63 75 75 77 77 49 67 69 73 45 45 47 69 29 131 43 55

PRINTED IN U.S.A.

Item No. 06 10 17 21 01 22 22 04 02 11 06 06 13 25 26 23 24 11 08 01 13 14 10 15 13 30 01 10 13 14 10 07 01 06 09 16 16 01 15 32 11 18 29 17 06 13 24 19 13 19 17 03 02 01 12 22 23 16 16 08

Part No. 650387 650387 650426 650448 650450 650484 650484 650484 650484 650485 650486 650486 650486 650486 650486 650486 650487 650487 650488 650488 650488 650488 650488 650489 650489 650489 650490 650490 650490 650490 650490 650490 650491 650491 650492 650493 650493 650495 650500 650512 650512 650533 650533 650533 650542 650542 650545 650549 650550 650569 650569 650569 650579 650584 650588 650630 650648 650650 650706 650706

Page No. 45 53 61 133 39 45 58 69 121 29 07 31 45 47 49 69 57 69 51 119 121 123 135 49 51 67 23 75 119 119 121 131 08 29 205 121 125 135 201 41 43 23 119 121 55 67 29 119 59 51 53 205 65 67 17 23 45 203 31 59

Item No. 13 05 12 10 12 06 06 14 03 03 26 13 09 02 01 13 08 25 14 25 19 07 21 08 04 27 18 05 22 26 15 14 06 08 21 12 03 29 07 11 18 21 32 22 11 01 24 07 03 19 07 12 05 20 17 03 12 18 14 02

Part No. 650706 650730 650731 650733 650784 650784 650833 650835 650835 650863 650863 650936 650965 651089 651148 651151 651195 651269 651271 651395 651457 651517 651543 651625 651625 651625 651625 651635 651636 651638 651639 651639 651640 651640 651640 651640 651640 651640 651641 651641 651641 651643 651668 651695 651695 651695 651698 651699 651702 651705 651706 651706 651706 651706 651707 651707 651720 651732 651759 651796

215

Page No. 205 17 57 205 131 133 137 59 61 11 55 09 77 27 135 08 67 55 119 65 47 65 99 25 121 123 203 17 17 17 11 15 07 07 11 23 43 45 11 15 17 17 55 41 63 75 67 75 65 55 41 65 73 75 29 67 73 41 55 65

Item No. 05 11 03 16 07 04 25 01 13 — 07 — 23 05 28 02 21 14 07 12 10 15 15 09 07 28 07 21 21 05 02 07 04 35 03 16 11 05 06 06 06 10 02 22 15 12 10 14 02 19 23 14 07 09 11 24 06 24 18 19

Part No.

Page No.

653002 653010 653098 654002 654002 654002 654002 654002 654004 654004 654006 654006 654006 654006 654006 654006 654009 654014 654022 654024 654026 654026 654026 654026 654026 654026 654026 654026 654026 654028 654030 654030 654046 654049 654049 655001 655001 655006 656007 656009 656049 656103 656133 L10057 L277944 L400398 L400425 L400425 L400425 L400929 L40805 L41261 L41854 L441010 L445014 L44859 L46865 L46865 L47263 L47265

09 29 55 11 59 133 135 167 23 29 09 23 51 71 75 119 29 57 169 133 77 119 119 121 121 123 131 203 205 17 119 205 17 49 65 119 123 29 77 29 29 65 65 127 51 205 199 201 203 197 71 25 53 51 135 29 135 166 197 197

Item No. — 12 15 — 02 11 07 — 08 02 02 19 05 06 04 39 19 15 16 03 23 22 27 20 23 08 13 08 22 22 09 26 22 09 06 10 16 17 02 07 14 11 18 01 06 15 03 03 04 05 09 02 04 24 26 16 27 02 06 07

50960084/AP0914

NUMERICAL INDEX

Part No.

Numerical Index

http://www.minnpartelehandlerparts.com/

NUMERICAL INDEX

Numerical Index Part No. L48868A L49327 L49327 L500001 L500004 L500019 L500020 L500021 L500021 L500021 L500021 L500022 L500022 L500024 L500025 L500027 L500028 L500036 L500038 L500038 L500038 L500042 L500042 L500042 L500057 L500099 L500111 L500127 L500129 L500130 L500132 L500134 L500135 L500163 L500215 L500222 L500225 L500273 L500273 L500274 L500294 L500300 L500367 L500367 L500370 L500371 L500373 L500407 L500407 L500408 L500408 L500408 L500409 L500410 L500411 L500412 L500413 L500414 L500451 L500451

Page No. 193 05 51 13 13 11 07 07 11 15 17 07 17 11 11 11 11 17 11 15 17 11 15 17 07 13 11 169 169 169 169 169 169 35 201 205 55 93 95 88 83 169 194 195 194 181 205 85 93 85 93 93 85 93 93 93 93 93 106 107

50960084/AP0914

Item No. 11 11 22 15 17 16 16 17 05 04 08 15 21 08 14 18 17 16 01 02 09 04 05 07 12 23 07 19 17 05 05 04 15 08 01 00 05 03 03 01 08 22 05 10 07 02 28 07 23 08 22 24 16 01 02 04 19 20 02 02

Part No. L500452 L500453 L500454 L500454 L500455 L500455 L500457 L500457 L500459 L500459 L500460 L500460 L500461 L500461 L500463 L500463 L500464 L500464 L500465 L500465 L500466 L500466 L500467 L500467 L500468 L500468 L500470 L500471 L500471 L500472 L500472 L500474 L500474 L500475 L500476 L500476 L500477 L500477 L500478 L500478 L500480 L500480 L500481 L500481 L500483 L500483 L500484 L500484 L500485 L500486 L500487 L500488 L500488 L500489 L500489 L500490 L500490 L500491 L500492 L500492

RS6-34 Telescopic Handler Page No. 107 107 106 107 107 115 113 117 113 117 113 117 113 117 113 117 113 117 113 117 113 117 113 117 113 117 117 113 117 113 117 113 117 113 113 117 113 117 113 117 113 117 113 117 111 115 111 115 115 115 111 111 115 111 115 111 115 115 111 115

Item No. 03 04 05 05 06 38 01 01 02 02 02 02 02 02 03 03 05 05 06 06 07 07 08 08 09 09 11 12 12 13 13 15 15 16 17 17 17 17 18 18 23 23 24 24 01 01 02 02 03 04 05 10 05 14 06 15 09 10 19 11

Part No. L500493 L500494 L500494 L500495 L500496 L500496 L500496 L500496 L500496 L500497 L500498 L500498 L500499 L500499 L500500 L500500 L500501 L500501 L500504 L500504 L500505 L500505 L500507 L500508 L500508 L500509 L500509 L50051 L50051 L500510 L500510 L500516 L500517 L500517 L500518 L500518 L500519 L500519 L500522 L500522 L500523 L500523 L500524 L500524 L500525 L500525 L500527 L500527 L500528 L500529 L500531 L500532 L500533 L500534 L500535 L500536 L500536 L500537 L500538 L500539

216

Page No. 115 111 115 115 99 108 109 111 115 115 111 115 111 115 111 115 111 115 111 115 111 115 115 111 115 111 115 07 07 111 115 115 111 115 111 115 111 115 111 115 111 115 111 115 111 115 108 109 109 109 109 109 109 109 109 108 109 109 109 104

Item No. 12 34 13 14 19 23 12 23 15 17 32 18 29 19 33 20 30 21 31 26 35 27 29 38 30 41 32 05 14 42 33 40 51 41 50 42 40 43 43 46 26 49 26 49 26 49 14 01 02 03 05 06 07 08 09 15 10 13 14 02

Part No.

Page No.

L500539 L500542 L500543 L500544 L500555 L50056 L50056 L50056 L50056 L50056 L500594 L500595 L500595 L500596 L500607 L500652 L500653 L500656 L500668 L500668 L500688 L500689 L500690 L500691 L500692 L500695 L500696 L500697 L500700 L500701 L500706 L500708 L500709 L500718 L500745 L500746 L500747 L500747 L500748 L500761 L500762 L500763 L500771 L50084 L50084 L50086 L50086 L500952 L500953 L500954 L500955 L500956 L500957 L500958 L500959 L500960 L500961 L500968 L50101 L50139

105 99 99 99 115 23 119 123 129 133 43 39 43 43 15 181 181 181 189 193 181 181 181 181 181 13 13 13 13 13 13 13 13 13 174 174 21 49 49 194 194 194 117 57 99 119 123 169 169 169 169 169 169 169 169 169 169 172 25 07

Item No. 02 20 16 17 48 09 44 29 12 12 10 01 07 05 00 07 12 05 08 08 04 06 09 10 08 22 13 19 06 20 05 21 18 14 02 07 13 21 20 04 03 02 16 16 13 35 21 07 08 03 12 09 13 18 14 21 16 02 06 22

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

L50139 L50139 L50139 L50196 L50201 L50202 L50202 L50202 L50202 L50202 L50202 L50202 L50202 L50202 L50205 L50206 L50207 L50217 L50217 L50226 L50242 L50253 L50333 L50333 L50380 L50380 L50417 L50442 L50462 L50468 L50491 L50517 L50519 L50538 L50562 L50628 L50646 L50655 L50704 L50712 L50712 L50741 L50745 L50823 L50877 L50877 L50877 L50877 L50979 L51035 L51035 L51035 L51035 L51143 L51762 L51762 L51762 L51968 L520003 L520003

Page No. 59 135 167 23 99 07 07 07 11 17 29 33 35 37 203 41 121 135 167 119 201 99 49 201 119 205 07 49 119 77 21 23 201 21 201 29 125 59 77 57 99 141 143 23 123 129 129 133 17 119 123 129 133 58 143 161 165 203 17 27

PRINTED IN U.S.A.

Item No. 02 08 — 04 09 07 21 34 — 21 04 03 12 16 06 21 04 09 — 14 10 02 16 04 08 25 03 12 21 18 05 05 02 08 17 22 12 03 08 14 10 16 16 11 23 11 17 17 22 45 30 16 16 06 19 15 15 13 21 05

Part No. L520004 L520004 L52022 L52024 L52024 L52048 L530004 L530004 L530004 L54002 L561004 L570017 L60253 L60253 L60451 L60587 L60961 L61001 L61017 L61287 L61411 L61620 L61699 L61699 L61708 L61708 L61709 L61709 L61709 L61709 L61867 L62583 L62715 L62715 L62715 L62731 L62732 L62733 L62733 L62734 L62734 L62761 L62761 L62840 L630004 L63005 L63006 L63012 L63012 L63013 L63013 L63014 L63014 L63015 L63015 L63016 L63016 L63018 L63018 L63018

Page No. 121 123 33 07 33 119 45 47 49 07 29 135 57 137 205 49 197 197 197 203 205 51 121 123 119 121 119 121 123 203 53 209 119 121 123 121 121 119 121 121 123 141 181 167 55 123 121 131 193 129 191 129 189 57 185 57 185 125 189 191

Item No. 05 26 10 18 09 05 04 04 03 — 18 23 17 17 23 18 08 02 03 06 24 23 26 04 23 27 28 21 09 09 03 08 24 16 11 28 29 29 18 17 10 — 03 08 27 02 02 01 01 04 01 27 01 01 01 11 03 07 03 03

Part No. L63018 L63099 L63131 L63143 L63143 L63153 L63156 L63156 L63157 L63158 L63166 L63166 L63167 L63167 L63168 L63169 L63173 L63199 L63199 L63222 L63230 L63239 L63272 L63272 L63272 L63273 L63273 L63274 L63274 L63276 L63309 L63309 L63311 L63319 L63319 L63320 L63320 L63334 L63344 L63381 L63381 L63383 L63387 L63387 L63387 L63402 L63402 L63406 L63406 L63407 L63407 L63474 L63545 L63545 L63593 L63594 L63594 L63631 L63632 L63634

217

Page No. 193 119 119 201 203 121 123 123 121 121 119 123 119 123 123 119 119 127 187 99 29 121 125 129 131 129 131 125 127 57 51 135 210 199 203 199 203 55 203 135 151 27 27 101 103 27 135 51 137 127 127 209 35 37 195 195 203 210 210 07

Item No. 03 21 13 18 11 11 15 18 10 09 34 19 33 20 17 11 12 06 01 01 27 25 06 06 12 23 03 04 03 04 25 24 14 02 02 02 02 22 12 16 12 12 13 20 03 03 01 07 16 08 09 12 02 15 03 01 17 09 08 08

Part No. L63694 L63694 L63715 L63715 L63715 L63715 L63715 L63715 L63715 L63716 L63716 L63716 L63716 L63756 L63813 L63813 L63876 L63876 L63887 L63894 L63952 L63957 L63968 L63969 L64143 L64175 L64175 L64197 L64197 L64275 L64294 L64367 L64367 L64367 L64524 L64524 L64673 L64764 L65097 L65098 L65142 L65144 L65273 L65273 L65273 L65273 L65338 L65348 L65638 L65640 L65926 L65927 L65927 L65927 L65928 L65928 L65930 L65932 L65932 L65933

Page No. 119 131 57 123 129 129 133 133 201 123 129 133 201 51 07 08 09 25 07 21 203 125 203 203 119 187 195 63 77 139 205 57 185 203 27 135 45 75 125 125 51 51 133 201 203 205 205 206 119 119 210 206 207 209 207 209 210 207 209 209

Item No. 22 15 09 25 09 19 05 19 09 24 10 06 11 10 33 — —11 09 10 20 15 15 18 31 10 11 10 10 09 03 02 09 21 16 04 14 02 13 14 16 17 09 13 10 07 19 00 06 03 03 00 02 02 07 14 02 05 11 03

50960084/AP0914

NUMERICAL INDEX

Part No.

Numerical Index

http://www.minnpartelehandlerparts.com/

NUMERICAL INDEX

Numerical Index Part No. L65937 L65942 L66011 L66042 L66139 L66139 L66406 L66456 L66563 L66613 L66613 L66780 L66782 L66783 L66918 L66919 L66921 L66931 L66946 L66948 L66949 L66950 L66965 L67455 L67455 L67455 L67455 L67504 L67718 L67719 L67720 L67721 L67722 L67723 L68003 L68003 L68006 L68039 L68039 L68295 L68331 L68337 L68337 L68348 L68350 L68351 L68351 L68358 L68374 L68374 L68376 L68376 L68496 L68694 L68694 L68694 L68695 L68696 L68697 L68744

Page No. 209 207 07 206 101 103 197 125 135 125 207 123 123 123 201 201 201 201 205 201 201 201 77 69 77 135 137 99 209 209 209 209 209 209 119 123 119 129 133 210 197 194 201 131 119 129 133 131 129 129 133 133 23 137 139 169 121 121 121 121

50960084/AP0914

Item No. 05 11 03 00 04 11 04 09 12 — 08 14 13 12 15 05 08 06 20 08 20 19 12 04 16 20 02 01 09 09 09 09 09 09 16 22 15 18 18 04 09 01 16 09 01 28 21 08 01 02 01 02 22 24 08 01 14 24 08 01

Part No. L68762 L68772 L68778 L68794 L68804 L68805 L68805 L68808 L68808 L68809 L68809 L68809 L68810 L68810 L68811 L68817 L68817 L68831 L68849 L68866 L68875 L69264 L69297 L69402 L69595 L69596 L69734 L69734 L69747 L69747 L69747 L69747 L69756 L69902 L69903 L69903 L69904 L69904 L69905 L69905 L69928 L69928 L69928 L70039 L70040 L70045 L70069 L70069 L70075 L70075 L70146 L70200 L70201 L70212 L70241 L70242 L70305 L70305 L70306 L70307

RS6-34 Telescopic Handler Page No. 123 25 169 57 145 27 51 27 135 57 137 137 139 139 139 129 137 205 99 45 99 63 07 07 25 25 99 115 27 101 103 171 33 145 141 143 141 143 145 157 101 101 103 09 119 45 17 17 21 21 55 49 23 23 09 119 207 209 210 210

Item No. 01 04 — 06 01 15 28 14 05 07 01 03 06 07 05 21 08 28 22 03 01 14 02 08 03 01 12 37 05 13 05 01 12 08 08 08 13 13 02 10 06 08 13 01 38 07 21 — 20 21 16 07 07 06 — 02 01 01 01 12

Part No. L70428 L70428 L70428 L70462 L70495 L70495 L70634 L70701 L71074 L71075 L71076 L71076 L71077 L71082 L71083 L71084 L71086 L71088 L71305 L71346 L71346 L71346 L71346 L71346 L71346 L71346 L71346 L71350 L71378 L71554 L71555 L71595 L71691 L71691 L71700 L71725 L71726 L71729 L71732 L71748 L71748 L71750 L71751 L71752 L75990 L82358 L94824 L96053 L96580 L96838 L97489 L97489 L97525 L97526 L97889 L97889 L97889 L97889 L98176 L98184

218

Page No. 31 101 103 119 185 191 23 49 19 19 19 19 19 19 19 19 19 19 07 33 141 143 159 161 163 165 181 197 210 211 211 49 19 59 211 58 58 58 58 119 123 58 59 59 69 205 81 88 169 193 05 51 83 83 185 187 191 195 81 81

Item No. 07 18 18 00 12 11 02 04 06 03 11 12 09 07 10 08 04 14 — 01 01 01 01 01 01 01 01 01 00 01 02 05 13 — 03 04 03 01 06 36 03 05 05 04 19 10 02 05 17 11 10 03 10 11 12 10 11 11 09 22

Part No.

Page No.

L98185 L98189 L98191 L98194 L98196 L98197 L98198 L98199 L98200 L98201 L98202 L98203 L98204 L98205 L98211 L98212 L98214 L98215 L98216 L98217 L98218 L98219 L98220 L98224 L98226 L98228 L98229 L98230 L98231 L98232 L98233 L98235 L98235 L98236 L98236 L98237 L98237 L98237 L98238 L98238 L98238 L98239 L98239 L98239 L98239 L98240 L98240 L98240 L98240 L98241 L98241 L98241 L98242 L98242 L98242 L98244 L98244 L98244 L98246 L98246

81 83 83 83 83 83 83 83 83 83 83 83 83 83 86 86 87 87 87 81 81 87 87 87 81 89 89 89 89 89 89 91 95 91 95 91 93 95 91 93 95 91 93 95 95 91 93 95 95 91 93 95 91 93 95 91 93 95 91 93

Item No. 08 09 13 07 16 03 15 12 06 04 05 01 02 14 05 07 10 08 09 15 14 12 01 06 13 02 01 04 03 05 08 17 16 16 15 09 14 09 08 13 08 15 12 21 23 14 11 20 22 13 18 14 12 17 13 10 15 10 06 09

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

L98246 L98247 L98247 L98247 L98248 L98249 L98250 L98250 L98250 L98251 L98252 L98253 L98253 L98253 L98254 L98254 L98254 L98255 L98257 L98257 L98258 L98260 L98264 L98266 L98268 L98272 L98274 L98275 L98276 L98276 L98277 L98277 L98278 L98279 L98281 L98282 L98284 L98291 L98292 L98293 L98294 L98295 L98298 L98300 L98301 L98302 L98303 L98304 L98307 L98316 L98317 L98318 L98318 L98355 L98355 L98355 L98368 L98371 L98371 L98372

Page No. 95 91 93 95 91 91 91 93 95 91 91 85 85 95 85 85 91 91 93 95 93 95 88 88 88 95 95 95 85 95 85 95 88 88 88 88 85 96 96 96 96 96 96 96 96 96 96 96 96 78 78 107 115 99 111 115 108 111 115 111

PRINTED IN U.S.A.

Item No. 06 07 10 07 01 18 04 07 04 02 03 02 05 24 03 06 20 22 06 19 05 17 06 07 04 18 01 02 11 26 13 27 09 08 03 02 14 01 02 08 03 04 06 11 13 12 09 05 07 03 06 07 25 18 24 16 08 13 07 11

Part No. L98372 L98373 L98373 L98373 L98380 L98380 L98394 L98395 L98395 L98396 L98396 L98404 L98404 L98406 L98406 L98414 L98414 L98415 L98417 L98417 L98417 L98417 L98503 L98506 L98507 L98509 L98511 L98513 L98513 L98515 L98516 L98516 L98517 L98518 L98519 L98520 L98521 L98522 L98523 L98524 L98527 L98528 L98545 L98547 L98547 L98548 L98550 L98550 L98551 L98558 L98700 L98734 L98735 L98887 L98891 L98895 L98895 L98896 L98897 L98898

Page No. 115 106 111 115 113 117 117 113 117 113 117 113 117 113 117 113 117 117 106 107 111 115 185 185 185 185 193 189 193 193 189 193 193 187 187 187 187 187 187 189 189 189 191 185 191 191 185 191 191 193 125 81 81 169 169 169 169 169 169 169

Item No. 07 09 12 47 04 04 21 20 20 19 19 17 17 17 17 02 02 02 01 01 39 31 02 13 06 11 02 05 05 06 07 07 12 02 09 03 11 05 06 02 11 06 02 04 05 12 07 07 13 13 01 27 28 19 02 06 20 10 10 10

Part No. L98899 L98926 L98927 L98932 L98935 L98938 L98942 L98943 L98944 L98945 L98947 L98948 L98949 L98950 L98951 L98953 L98954 L98955 L98956 L98957 L98958 L98961 L98961 L98961 L98962 L98967 L98968 L98968 L99013 L99018 L99020 L99023 L99025 L99027 L99029 L99029 L99029 L99029 L99030 L99031 L99032 L99038 L99045 L99163 L99168 L99170 L99174 L99175 L99182 L99184 L99184 L99184 L99192 L99193 L99224 L99225 L99237 L99246 L99246

219

Page No. 169 81 81 81 81 79 86 86 86 86 86 87 87 87 87 87 87 85 96 96 96 91 93 95 91 95 85 95 81 81 87 87 87 87 79 79 81 87 78 89 89 95 81 51 195 195 195 195 77 05 77 87 199 199 203 203 205 79 81

Item No. 11 07 06 12 11 14 06 04 03 01 02 11 07 04 05 03 — 15 14 15 10 11 16 11 21 12 09 25 04 19 15 14 13 16 11 13 21 17 05 06 07 05 20 09 02 13 07 08 17 08 15 02 01 01 01 01 01 04 16

Part No.

Page No.

L99246 L99249 L99251 L99253 L99260 L99260 L99261 L99262 L99262 L99274 L99278 L99279 L99284 L99284 L99284 L99285 L99285 L99286 L99287 L99288 L99294 L99295 L99296 L99312 L99405 L99405 L99405 L99425 L99696 L99785 L99857 L99857 L99857 L99857 L99857 L99857 L99866 L99908 L99908 L99909 L99910 L99910 L99911 L99911 L99911 L99911 L99917 L99924 L99925 L99927 L99951 P471997 TBD TBD

81 79 81 81 79 79 79 79 81 81 91 93 79 79 81 79 81 79 81 81 81 81 81 81 185 187 191 25 93 78 185 187 189 191 193 195 191 167 170 170 167 170 167 170 170 174 174 174 167 167 99 167 63 63

Item No. 24 15 03 05 09 12 10 07 25 23 05 08 03 06 18 08 32 01 29 31 33 34 35 30 08 07 08 05 21 04 05 04 04 04 04 05 06 06 03 04 07 05 07 04 05 02 08 07 03 03 03 08 02 19

50960084/AP0914

NUMERICAL INDEX

Part No.

Numerical Index

http://www.minnpartelehandlerparts.com/

Subject Index

RS6-34 Telescopic Handler PAGE

A A/C Dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39 Adapter Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205 Adhesive Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 Air Cleaner Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73 Alternator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 Alternator Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55 Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99, 111, 115

B Backup Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49 Bellows, Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Belt Tensioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65 Belt, A/C Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05, 65 Belt, Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05, 63 Bevel Gear Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113, 117 Bleed Screw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108, 109 Blower Motor, Hvac . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 Boom Chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123 Boom Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .210 Boom Extend Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131, 193 Boom, Outer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119 Bottle, Dual -Pump Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Brake Cylinder Single Tandem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29, 31, 101, 103 Brake Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108, 109 Brake Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109 Brake Lever Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 Brake Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173 Breather, Air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81 Bucket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205 Bumper, Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Button, Radio E-Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

SUBJECT INDEX

C Cab Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07, 17 Cable, Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55 Cam Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Can, Terminate Receptacle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Cap, Oil Fill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 Cap, Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53 Cap, Hydraulic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51 Cap, Radiator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71 Cap, Steering Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Cap, Washer Bottle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Carriage, Standard Fork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .199 Chain, Boom Leaf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123 Charge Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87

50960084/AP0914

220

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Subject Index PAGE

Cold Control Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Column, Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Compressor, A/C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39, 43, 65 Connector, 12v Power Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Control, Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 Controller, Auxiliary Hydraulics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139, 149, 153, 157, 183 Controller, Frame Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141, 143, 159, 161, 163, 165 Controller, Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 Controller, Lift/Extend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139, 147, 149, 151, 153, 157 Controller, Tilt/Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139, 147, 149, 151, 153, 155, 157 Controller, Tri-Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141, 143, 159, 161, 163, 165 Cooler Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69 Cooler Section, Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71 Cooler, Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67 Coupler, Exhaust Pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75 Cover Wiper Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Cover, 12v Power Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Cover, A/C Hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43 Cover, Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 Cover, Condenser Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43 Cover, Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47 Cover, Frame Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 Cover, Fuse Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07, 21 Cover, Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47, 49 Cover, Relay Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Cover, Throttle Pedal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 Cutting Edge, Bucket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205 Cylinder, Boom Extend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131, 193 Cylinder, Fork-Shift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .194, 201 Cylinder, Frame Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .185 Cylinder, Lift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127, 187 Cylinder, Rotating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195, 203 Cylinder, Slave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .129, 189 Cylinder, Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .129, 191

Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .206 Differential Carrier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113, 117 Diodes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21, 49, 61 Dipstick, Engine Oil Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 Display, Can & Instruments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Door, Engine Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47 Door Tool Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Driveshaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77 Dust Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169 Dust Evacuator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73 Dynattach Weldment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125

PRINTED IN U.S.A.

221

50960084/AP0914

SUBJECT INDEX

D

http://www.minnpartelehandlerparts.com/

Subject Index

RS6-34 Telescopic Handler PAGE

E Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 Evaporator, Heater Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Expansion Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

F Fan Assembly, Hvac . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Fan Shroud . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69, 73 Fan, Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 Fender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99 Fender Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99 Filter, Air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05, 73 Filter, Cab Air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Filter, Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05, 63 Filter, Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05, 67 Filter, Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05, 51 Filter, Recirculating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05, 37 Filter, Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05, 77, 87 Filter, Water Separator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05, 67 Flow Divider . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135, 167 Fork Shaft Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .199, 203 Fork, Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .197 Fork-Shift Carriage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .201 Fork-Shift Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .201 Frame Level Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57 Frame Level Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57, 99 Fuel Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67 Fuel Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53 Fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21, 55 Fuse Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

SUBJECT INDEX

G Glass, Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Glass, Left Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 Glass, Lower Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Glass, Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07, 11 Glass, Right Hand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07 Glass, Top . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 Glass, Upper Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Grill, Defroster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 Grill, Vent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Ground Strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55 Guard, Exhaust Doc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

H Handle, Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 Head Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .09

50960084/AP0914

222

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Subject Index PAGE

Heater Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 Heater Core . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 Heater Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41 Heater, Hydraulic Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51 Heater, Oil Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 Hood, Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 Hood, Main . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47 Hood, Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49 Horn W/Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 Hose Assembly, Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67 Hose Tray, Inner Boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123 Hose, A/C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39 Hose, Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41, 69 Hose, Overflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37, 69 Hose, Radiator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69 HVAC Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37, 39, 41 Hydraulic Control Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139, 169, 177, 179, 183 Hydraulic Filter Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51 Hydraulic Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135, 166 Hydraulic Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51 Hydraulic Winch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205

I Inclinometer-Angle Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119 Indicator, Frame Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07 Indicator, Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73 Inner Boom Weldment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123 Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

K Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17, 19, 23 Kit, Valve Section (Auxiliary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169

L

M Magnetic Manifold, Manifold, Manifold,

Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106, 111, 115 Brake Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31, 101, 103 Flow Divider . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101 Joystick Relief . . . . . . . . . . . . . . . . . . . . . .147, 149, 151, 153, 155, 157, 159, 161, 163, 165

PRINTED IN U.S.A.

223

50960084/AP0914

SUBJECT INDEX

Lanyard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61 Level Sensor, Pwp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59, 61 Lift Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127, 187 Light, Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49 Light, Tail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49 Lube Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .209

http://www.minnpartelehandlerparts.com/

Subject Index

RS6-34 Telescopic Handler PAGE

Manifold, Pilot Apply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141, 143, 159, 161, 163, 165, 174 Manifold, Pwp Joystick . . . . . . . . . . . . . . . . . . . . . . . .59, 151, 153, 155, 157, 159 161, 163, 165, 170 Manifold, Radio Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .145, 147 Mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07, 51 Module, A/C Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Module, Brake Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Module, F-N-R Shifter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Module, Pwp Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59 Motor, Steer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Mount, A/C Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65 Mount, Brake Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31 Mount, Condenser Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43 Mount, Doc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75 Mount, Dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39 Mount, Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 Mount, Engine Cushion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 Mount, Fuel Cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67 Mount, Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47 Mount, Radio Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .145 Mount, Seat Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Mount, Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

O Outer Boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119

SUBJECT INDEX

P Pad, Arm Rest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 Pad, Brake Pedal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 Paint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .206 Panel, Dash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07, 19 Panel, Hvac Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Pilot Apply Manifold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141, 143, 159, 161, 163, 165, 174 Pintle Hook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205 Poppet, Safety Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81 Pressure Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174 Pressure Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31 Proportional Pressure Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175 Pulley, A/C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65 Pump, T12000 Charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87

Q Quick Coupler Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .133

R Radiator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71 Radio Remote, System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

50960084/AP0914

224

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Subject Index PAGE

Receiver, Radio Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61 Rectifier Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21, 37, 43 Remote Stop Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58 Remote Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61 Resistor Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 Rotate Carriage, Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .203 Rotate Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .203

S

PRINTED IN U.S.A.

225

50960084/AP0914

SUBJECT INDEX

Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Seat Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Seat Riser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Sender, Fuel Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53 Sender, Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77 Sensor, Coolant Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69 Sensor, Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63, 67 Shifter, Fnr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Shock, Suspension Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Sight Glass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71 Skid Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07 Starter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 Steer Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104, 105 Steer Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27, 101, 103, 135, 172 Steer Select Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .171 Steering Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Strainer, Hydraulic Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51 Strainer, Oil Suction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05 Striker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Strobe Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .09 Switch, Binary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39 Switch, Clutch Cut-Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Switch, Engine Fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Switch, Hazard Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Switch, Ignition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Switch, Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Switch, Park Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Switch, Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101, 103 Switch, PWP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59 Switch, Steer Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Switch, Strobe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Switch, Toggle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61 Switch, Turn Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Switch, Variable Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35, 37 Switch, Wiper/Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Switch, Work Platform . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

http://www.minnpartelehandlerparts.com/

Subject Index

RS6-34 Telescopic Handler PAGE

T Tailpipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75 Test Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167 Throttle Pedal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 Tie Rod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104, 105 Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77 Transmission Dipstick . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81 Transmission Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77 Tray, Intermediate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121 Tri-Function Wire Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33, 141, 143, 159, 161, 163, 165 Turn Signal Flasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

U Universal Joint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

V Valve Stem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99 Valve, 2-Way . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174 Valve, Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Valve, Coolant Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71 Valve, Heater-A/C Solenoid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41 Valve, Hydraulic Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .137 Valve, Steer Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27, 101, 103 Valve, Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 Vent, Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106, 107

SUBJECT INDEX

W Water Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05 Water Separator Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67 Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99 Wheel Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111, 115 Wiper Arm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Wire Harness, A/C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39 Wire Harness, Canopy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Wire Harness, Cervis Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61 Wire Harness, Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Wire Harness, Front Wiper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Wire Harness, Head Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .09 Wire Harness, Light Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49 Wire Harness, Pwp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59 Wire Harness, Radio Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61 Wire Harness, Rear Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49 Wire Harness, Strobe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .09 Wire Harness, Tilt Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174 Wire Harness, Top Wiper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Wire Harness, Washer Bottle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Wire Harness, Work Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119

50960084/AP0914

226

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

RS6-34 Telescopic Handler

Subject Index PAGE

Work Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119 Work Section (Auxiliary Hydraulic) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169 Work Section 1 (Frame Level) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169 Work Section 2 (Boom Lift) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169 Work Section 3 (Boom Extend) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169 Work Section 4 (Fork Tilt) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169 Wrap, Battery Thermal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55 Wrap, Reflective Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

SUBJECT INDEX

PRINTED IN U.S.A.

227

50960084/AP0914

http://www.minnpartelehandlerparts.com/

REFERENCE METRIC BOLT TORQUE GUIDE Use these torque values when tightening hardware—excluding: lock nuts, thread-forming, self-tapping, and metal screws—unless otherwise specified.

Grade 8.8

Metric Coarse-Pitch Thread M5 M6 M8 M10 M12 M14 M16 M18 M20 M22 M24 M27 M30

Grade 12.9

Grade 10.9

All torque values are in Foot-Pounds and Newton Meters (Nm).

DIN 912, DIN 931, DIN 933, etc...

8.8

10.9

12.9

4.1 (5.5) 6 (8) 7 (10) 7 (10) 10 (14) 13 (17) 18 ( 25) 26 (35) 31 (42) 33 (45) 48 (65) 59 (80) 64 (87) 81 (110) 108 (147) 100 (135) 133 (180) 170 (230) 155 (210) 203 (275) 258 (350) 207 (280) 302 (410) 354 (480) 302 (410) 420 (570) 509 (690) 406 (550) 575 (780) 686 (930) 524 (710) 738 (1000) 878 (1190) 767 (1040) 1092 (1480) 1305 (1770) 1047 (1420) 1482 (2010) 1770 (2400)

Metric Fine-Pitch Thread M8X1.0 M10X1.0 M10X1.25 M12X1.25 M12X1.5 M14X1.5 M16X1.5 M18X1.5 M20X1.5 M22X1.5 M24X2.0 M27X2.0 M30X2.0

50960084/AP0914

DIN 7984 8.8

10.9

4 (5) 6.3 (8.5) 15 (20) 30 (40) 51 (69) 81 (110) 125 (170) 181 (245) 251 (340) 339 (460) 435 (590) 642 (870) 885 (1200)

5 (7) 9 (12) 22 (30) 44 (59) 74 (100) 118 (160) 184 (250) 254 (345) 361 (490) 487 (660) 620 (840) 922 (1250) 1254 (1700)

All torque values are in Foot-Pounds and Newton Meters (Nm).

DIN 912, DIN 931, DIN 933, etc...

8.8

10.9

12.9

18 (25) 27 (37) 32 (43) 37 (50) 55 (75) 65 (88) 36 (49) 52 (71) 61 (83) 64 (87) 96 (130) 111 (150) 61 (83) 92 (125) 107 (145) 100 (135) 148 (200) 173 (235) 155 (210) 229 (310) 266 (360) 232 (315) 332 (450) 391 (530) 325 (440) 465 (630) 538 (730) 435 (590) 620 (840) 723 (980) 546 (740) 789 (1070) 922 (1250) 811 (1100) 1143 (1550) 1328 (1800) 1106 (1500) 1586 (2150) 1844 (2500)

228

DIN 7984 8.8

10.9

16 (22) 32 (43) 31 (42) 55 (75) 53 (72) 89 (120) 133 (180) 199 (270) 277 (375) 369 (500) 465 (630) 679 (920) 959 (1300)

24 (32) 48 (65) 46 (62) 81 (110) 77 (105) 129 (175) 195 (265) 284 (385) 391 (530) 524 (710) 664 (900) 959 (1300) 1364 (1850)

PRINTED IN U.S.A.

http://www.minnpartelehandlerparts.com/

REFERENCE SAE BOLT TORQUE GUIDE Use these torque values when tightening hardware—excluding: lock nuts, thread-forming, self-tapping, and metal screws—unless otherwise specified.

NOTE: All torque values are in foot-pounds (lb.-ft.), except those marked with asterisks (*), which are in inch-pounds (lb.-in.). To convert lb.-ft. to Newton Meter (Nm)—metric—torque values, multiply the lb.-ft. value by 1.355, or for inch pounds, multiply the lb.-in. value by 0.113.

Unified National Thread 8-32 8-36 10-24 10-32 1/4-20 1/4-28 5/16-18 5/16/24 3/8-16 3/8-24 7/16-14 7/16-20 1/2-13 1/2-20 9/16-12 9/16-18 5/8-11 5/8-18 3/4-10 3/4-16 7/8-9 7/8-14 1-8 1-14

Grade 2

Grade 5

Grade 8

Dry

Oiled

Dry

Oiled

Dry

Oiled

19* 20* 27* 31* 66* 76* 11 12 20 23 32 36 35 40 55 60 75 85 130 150 125 140 190 210

14* 15* 21* 23* 50* 56* 9 9 15 17 24 27 35 40 55 60 75 85 130 150 125 140 190 210

30* 31* 43* 49* 9 10 17 19 30 35 50 55 75 90 110 120 150 180 260 300 430 470 640 710

22* 23* 32* 36* 75* 86* 13 14 23 25 35 40 55 65 80 90 110 130 200 220 320 630 480 530

41* 43* 60* 68* 12 14 25 25 45 50 70 80 110 120 150 170 220 240 380 420 600 660 900 1000

31* 32* 45* 51* 9 10 18 20 35 35 55 60 80 90 110 130 170 180 280 320 460 500 680 740

* Value shown is in pound-force inch (lb.-in.)—inch pounds.

PRINTED IN U.S.A.

229

50960084/AP0914

http://www.minnpartelehandlerparts.com/

Manitou Americas, Inc. One Gehl Way P. O. Box 179 West Bend, WI 53095-0179 U.S.A www.gehl.com

50960084/AP0914

© 2014 Manitou Americas, Inc. All rights reserved.

PRINTED IN U.S.A.
